F 30FRONT PANEL
CHANNEL 1CHANNEL 2
Control FunctionTypeMesa Part#Control FunctionTypeMesa Part#
GainPot591842GainPot593739
Knob408115Knob408115
TreblePot593148TreblePot592738
Knob408115Knob408115
MiddlePot593736MiddlePot593737
Knob408115Knob408115
BassPot593148BassPot593739
Knob408115Knob408115
ReverbPot593150ReverbPot593150
Knob408115Knob408115
MasterPot592738MasterPot592794
Knob408115Knob408115
REAR PANEL
MISC PARTSMISC PARTS
Control FunctionTypeMesa Part#Control FunctionTypeMesa Part#
InputJack610120Fuse Holder
Channel SelectSwitch607303DomesticCap/Holder790347
Pilot LightFuse790200
Light703047ExportCap/Holder790346
Lens703782Fuse795101
Light Holder703850Record/PhonesJack618100
StandbySwitch601073FX Loop
PowerSwitch601073Mix LevelPot593737
Knob408004
SendJack618100
ReturnJack618100
Speaker MuteSwitch600115
Speaker Outs(3)Jack618100
ACJack613713
FootswitchJack613615
