Page 1
20/20
FRONT PANEL
MISC PARTS
Control Function Type Mesa Part# Control Function Type Mesa Part#
Vol A Pot 593151 Power Switch 601073Knob 408111 Standby Switch 601073
Vol B Pot 593151
Fuse Holder
Knob 408111 Domestic Cap/Holder 790347
Presence A Pot 593151 Fuse 790200 Knob 408111 Export Cap/Holder 790346
Presence B Pot 593151 Fuse 795101 Knob 408111
REAR PANEL
MISC PARTS
Control Function Type Mesa Part#
Jacks
All (5) Dual Mono 618357
Ground Switch 600115
