PERFORMANCE SPECIFICATIONS
Audio Specifications
Number of Channels
2 and 5.1
Output Level
2.0Vrms Balanced (2 Channel Output)
2.0Vrms Unbalanced (2 Channel Output and 5.1 Channels)
Output Impedance
600 ohms Balanced (2 Channel Output)
600 ohms Unbalanced (2 Channel Output and 5.1 Channels)
Audio Frequency Response (DVD-Video)
4Hz to 22,000Hz (48kHz Sampling, Linear Audio)
4Hz to 44,000Hz (96kHz Sampling, Linear Audio)
Audio Frequency Response (DVD-Audio)
4Hz to 88,000Hz (192kHz Sampling)
CD Frequency Response
4Hz to 20,000Hz
CD Signal to Noise Ratio
Better than 100dB (A-weighted)
Dynamic Range (DVD)
Better than 100dB (Linear Audio)
Dynamic Range (CD)
Better than 98dB
Harmonic Distortion
0.003% (1,000Hz)
Channel Separation
Better than 110dB (1,000Hz)
Video Specifications
Signal System
NTSC
Component Video Output Level
Y Output Level 1.0Vp-p (75 ohm)
P
B Output Level 0.7Vp-p (75 ohm)
P
R Output Level 0.7Vp-p (75 ohm)
S-Video Y Output Level
1Vp-p (75 ohm)
S-Video C Output Level
0.286Vp-p (75 ohm) (NTSC)
Video Output Level
1Vp-p (75 ohm)
General Specifications
Digital Output
Optical: -15dbm to -“21dbm
Coaxial:0.5V p-p/75 ohm
Digital Signal Format
Sampling Frequencies: 44,100Hz, 48,000Hz and 96,000Hz
Transport
Laser Beam Wavelength: 658nm/790nm
Laser Power: CLASS IIa/ CLASS I
Power Requirements
100 Volts, 50/60Hz at 30 watts
110 Volts, 50/60Hz at 30 watts
120 Volts, 50/60Hz at 30 watts
220 Volts, 50/60Hz at 30 watts
230 Volts, 50/60Hz at 30 watts
240 Volts, 50/60Hz at 30 watts
Note: Refer to the rear panel of the MVP851 for the correct voltage.
Overall Dimensions
Front Panel: 17-1/2 inches (44.5cm) wide, 5-3/8 inches (13.7cm)
high. Depth behind front mounting panel is 15 inches (38.1cm)
including clearance for connectors. Panel clearance required in
front of mounting panel is 3/4 inch (1.9cm).
Note: When the DVD/CD tray is opened, the panel clearance
required in front of mounting panel is 6-3/4 inches (17.2cm).
Weight
20 pounds (9.1kg) net, 34 pounds (15.4kg) in shipping carton
2
Page 2
1. The heavy notes on the schematic denote the primary
signal path.
2. Unless otherwise noted, all voltages indicated on the
schematics are measured under the following conditions:
a. AC input at 120 volts, 50/60Hz.
b. All voltages are +/-10% with respect to ground. A
high impedance (10 megaohm) voltmeter must be used.
3. Unless otherwise specified:
a. Resistor values are in ohms.
b. Capacitor values are microfarads (uF).
c. Inductor values are in microhenries (uH).4. On PC board drawings, Square pad indicates:
a. Polarized Capacitors - Positive
b. Diodes - Cathode
c. Others - Pin 1
5.WARNING
Parts marked with the symbol have critical
characteristics. Use only replacement parts recom-
mended by the manufacturer.
6. Use McIntosh Remote Control Model HR040 with the
MVP851.
NOTES
SAFETY INFORMATION
CAUTION: The use of optical instruments with this
product will increase eye hazard.
This product utilizes a Class I laser. Invisible laser
radiation is emitted from the optical pickup lens when the
unit is turned on.
1. Do not look directly into the pickup lens.
2. Do not use optical instruments to look at the pickup
lens.
3. Do not adjust the preset variable resistor on the
optical pickup.
4. Do not disassemble the optical pickup unit.
5. Use of controls or adjustment or performance of
procedures other than those specified herein may
result in hazardous radiation exposure.
6. Replace optical pickup only with manufacturers
specified type.
Laser output: CLASS IIa / CLASS I
Wavelength:658nm / 790nm
LUOKAN 1 LASERLAITE
KLASS 1 LASER APPARAT
VAROITUS!
Laitteen kayttaminen muulla kuin tassa
kayttoohjeessa mainitulla tavalla saattaa altistaa
kayttajan turvallisuusluokan 1 ylittavalle
nakymattomalle lasersateiiylle.
VARNING! Om apparaten anvands pa annat satt an
i denna bruksanvisning specificerats, kan anvandaren
utsattas for osynbg laserstraining, som overskrider
gransen for laserklass 1. This product utilizes an embedded Class IIa laser (IEC825).
3
MVP851
