FOLDER 8
SET 453
MC INTOSH
MODEL MR-55
'mAOE nun
PHOTO FACT* Folder
MC INTOSH
MODEL MR-55
TRADE NAME McIntosh Model MR-55
MANUFACTURER
TYPE SET AC Operated 18 Tube FM-AM Tuner
POWER SUPPLY 110-120 Volts AC, 60 Cycles
TUNING RANGE BROADCAST 540 =- 1620KC
McIntosh Laboratory, Inc., 2 ChambersKSt. , Blnghamton, N. Y.
RATING 69 Watts, .65 Amp. (3) 117 Volts AC
FREQ. MOD. 88 -108MC
DIAL CORD STRINGING
@
s
GA NG FULLY CLOSED
HOWARD W. SAMS & CO.,INC.
The listing of any available replacement part herein does
not constitute in any case a recommendation, warranty or
guaranty by Howard W. Sams & Co. , Inc. , as to the quality
and suitability of such replacement part. The numbers of
these parts have been compiled from information furnished
to Howard W. Sams & Co. , Inc. , by the manufacturers of
H938
DATE
3 1/2 TURNS /
ON TUNING SHAFT
Indianapolis 6. Indiana
the particular type of replacement part listed. Repro-
duction or use, without express permission, of editorial or
pictorial content, in any manner, is prohibited. No patent
liability is assumed with respect to the use of the informa-
tion contained herein. © 1959 Howard W. Sams & Co. , Inc. _.
Indianapolis 6, Indiana. Printed in U.S. of America
8-59 SET 453
