Page 1
1. FIVE BAND PROGRAM EQUALIZER
Five separate controls allow great flexibility
when compensating for program deficiencies.
2. "LED" POWER OUTPUT INDICATORS
Two columns of seven yellow "LED" indicators
provide an indication of the amount of power be-
ing fed to your speakers.
3. POWER GUARD INDICATOR AND
PROTECTION CIRCUIT
Two red "LED" power guard indicators indicate
when the power amplifier has reached full output.
At this point the power guard circuit begins to
control amplification dynamically so that you will
not hear the harsh distorted sound of square
wave clipping. In addition your speakers are pro-
tected from burnout.
4. ELECTRONIC AUDIO SIGNAL SWITCHING
FET analog switches are used to give smooth swit-
ching transition from one input to another without
clicks and pops.
5. SUPER-TRACKING VOLUME CONTROL
The volume control is a precision stepped at-
tenuator which has left to right tracking accuracy
within 1 dB throughout its entire range. System
balance is maintained at all listening levels.
6. LESS THAN 0.05% TOTAL
HARMONIC DISTORTION
Harmonic distortion does not exceed 0.05% when
measured from the phono input to the speaker
output from 20 Hz to 20 kHz at all power levels
from 250 mW to full rated output.
7. TRUE VARIABLE LOUDNESS
COMPENSATION CONTROL
The loudness control operates independently of
the volume control and its contour is accurately
modeled after the Fletcher Munson family of
"equal loudness" curves.
8. DUAL TAPE MONITOR AND
TAPE COPY SWITCHES
Two tape recorders can record simultaneously
from the program being listened to or you may
record from one to the other without interfering
with the "Listen" program.
Page 2
9. SPEAKER SWITCHES FOR
THREE SETS OF SPEAKERS
Three sets of loudspeakers may be used one at
a time, two together, or all three simultaneously.
10. SPEAKER PROTECTION CIRCUITS
Loudspeakers are protected from burnout by
the Power Guard circuit and also by other cir-
cuits that instantaneously disconnect the
speakers in the event of the presence of DC on
the output.
11. PREAMP OUTPUT - POWER AMP
INPUT CONNECTIONS
Back panel connections provide the ability to
insert room equalizers, reverberation units or
other signal processing devices.
12. LOW NOISE ION-IMPLANTED J-FET OP-AMPS
New technology low noise operational
amplifiers give lower noise and greater band-
width than conventional devices.
13. ELECTRONIC ACTIVE FILTER ELEMENTS
"Active filter" technology is used to generate
the equivalent of the inductors normally used in
equalizer filters. This eliminates the hum
pickup or inductance non linearity that often
occurs from conventional inductors.
14. MOS-FET FM FRONT END
Great signal sensitivity together with freedom
from strong signal overload is made possible
by using MOS Field Effect Transistors in the
FM RF circuits.
15. ULTRA STABLE LINEAR-PHASE
PIEZOELECTRIC FM IF FILTERS
The IF filters are permanently sealed and never
require adjustment. The IF response curve is
extremely selective because of its very steep
slope either side of center and yet it has a
linear phase characteristic.
16. AUTOMATIC FREQUENCY LOCK
Perfect FM tuning is assured by holding off the
tuning lock signal until manual tuning reaches
the center of the FM carrier.
17. WIDE RANGE SIGNAL STRENGTH METER
The signal strength meter pointer responds all
