CAUTION

RISK OF ELECTRIC SHOCK
DO NOT OPEN

CAUTION: TO REDUCE THE RISK OF ELECTRIC SHOCK,
DO NOT REMOVE COVER (OR BACK)
NO USER-SERVICEABLE PARTS INSIDE
REFER SERVICING TO QUALIFIED SERVICE PERSONNEL

The lightning flash with arrowhead symbol within an equilateral triangle is

intended to alert the user to the presence of uninsulated dangerous voltage

within the products enclosure that may be of sufficient magnitude to constitute a

risk of electric shock to persons.

The exclamation point within an equilateral triangle is intended to alert the user
to the presence of important operating and maintenance (servicing) instructions
in the literature accompanying the product.

WARNING

TO REDUCE THE RISK OF FIRE OR ELECTRIC SHOCK,
DO NOT EXPOSE THIS PRODUCT TO RAIN OR MOISTURE.

CAUTION: TO PREVENT ELECTRIC SHOCK, MATCH WIDE BLADE OF
PLUG TO WIDE SLOT, FULLY INSERT.

ATTENTION: POUR EVITER LES CHOC ELECTRIQUES, INTRODUIRE
LA LAME LA PLUS LARGE DE LA FICHE DANS LA BORNE
CORRESPONDANTE DE LA PRISE ET POUSSER JUSOUAU FOND.

NOTE:

This equipment has been tested and found to
comply with the limits for a Class B digital device,
pursuant to Part 15 of the FCC Rules. These limits
are designed to provide reasonable protection
against harmful interference in a residential
installation. This equipment generates, uses and can
radiate radio frequency energy and, if not installed
and used in accordance with the instructions, may
cause harmful interference to radio communications.
However, there is no guarantee that interference will
not occur in a particular installation. if this equipment
does cause harmful interference to radio or
television reception, which can be determined by
turning the equipment off and on, the user is
encouraged to try to correct the interference by one
or more of the following measures:

- Reorient or relocate the receiving antenna.

-|ncrease the separation between the
equipment and receiver.

- Connect the equipment into an outlet on a
circuit different from that to which the receiver
is connected.

- Consult the dealer or an experienced radio/TV
technician for help.

NOTE:

Changes or modifications not expressly approved
by the party responsible for compliance could void
the user's authority to operate the equipment.

This Class B digital apparatus complies with
Canadian ICES-003.

Cet appareil numérique de la Classe B est
conforme a la norme NMB-003 du Canada.

IMPORTANT SAFETY
INSTRUCTIONS

READ BEFORE OPERATING EQUIPMENT

This product was designed and manufactured to
meet strict quality and safety standards. There are,
however, some installation and operation precautions
which you should be particularly aware of.

1. Read these instructions.

Keep these instructions.

Heed all warnings.

Follow all instructions.

Do not use this apparatus near water.

Clean only with dry cloth.

N9W¥WN

Do not block any ventilation openings. Install
in accordance with the manufacture's
instructions.

8. Do not install near any heat sources such as
radiators, heat registers, stoves, or other
apparatus (including amplifiers) that produce
heat.

9. Do not defeat the safety purpose of the
polarized or grounding-type plug. A polarized
plug has two blades with one wider than the
other. A grounding type plug has two blades
and a third grounding prong. The wide blade
or the third prong are provided for your
safety. If the provided plug does not fit into
your outlet, consult an electrician for
replacement of the obsolete outlet.

10. Protect the power cord from being walked on
or pinched particularly at plugs, convenience
receptacles, and the point where they exit
from the apparatus.

11. Only use attachments/accessories specified
by the manufacturer.

12. Use only with the cart, stand, tripod, bracket,
or table specified by the manufacturer, or
sold with the apparatus. When a cart is used,
use caution when moving the cart/apparatus
combination to avoid injury from tip-over.

9b

13. Unplug this apparatus during lightning
storms or when unused for long periods of
time.

14. Refer all servicing to qualified service
personnel. Servicing is required when the
apparatus has been damaged in any way,
such as power-supply cord or plug is
damaged, liquid has been spilled or objects
have fallen into the apparatus, the apparatus
has been exposed to rain or moisture, does
not operate normally, or has been dropped.

Additional Safety Information!

- This product should not be placed in a
built-in installation such as a bookcase or
rack unless proper ventilation is provided
or the manufacturer's instructions have
been adhered to.

- Apparatus shall not be exposed to
dripping or splashing and that no objects
filled as vases, shall be placed on the
apparatus.

- When the switch is in the OFF position,
the apparatus isn't completely switched-off
from the MAINS.

DECLARATION OF CONFORMITY

This device complies with Part 15 of the FCC rules.
Operation is subject to the following conditions: (1) This
device may not cause harmful interference, and (2) this
device must accept any interference received, including
interference that may cause undesired operation.

U.$. Responsible Party: Marantz America, Inc.
100 Corporate Drive,
Mahwah, NJ, 07430, U.S.A.
TEL: 630-741-0300

Type of Product: DLP Projector
Model: VP71182

Page 23

V'P-llSZ_UgOlgENG 07.8.27 10:47AM /\°--~j20

The Screen Images in a 4:3 screen

0
50

Press the ZOOM button, the NORMAL button or the FULL button on the remote controller for the 4:3
aspect ratio video source.

Press the FULL button on the remote controller for 16:9 aspect ratio video source, such as 1080i,
1035i, and 720p video systems.

Use Zoom mode when projecting a 480i, 480p, 576i, or 576p squeezed image with a 2.35: 1 aspect
ratio.

Use V-Stretch mode when projecting a 720p, 1080i, or 1080p squeezed image with a 2.35: 1 aspect
ratio.

Original Source Image

o
9

The 16:9 squeezed image is displayed with the

16 : 9 video source j j 4 :3 video source

O O O 0
GOO GOO

Full mode
The 4:3 image is enlarged horizontally.

correct aspect.

o
9.9

The picture in normal ratio 4:3 is displayed.

Zoom mode

A 2.35:1 image is displayed in the entire screen.
This function is best used when a 480i, 480p,
576i, or 576p squeezed image is input.

O O

2 V-Stretch mode

The 2.35:1 image is shown across the entire screen. This function is best used when a 720p, 1080i, or

1080p squeezed image is input.

2' Through mode
Images are shown at the same resolution as FIGB/video signals.

Turn off the Power

1. Press the STANDBY button on the remote controller or the Q) /| button on the projector.

The fan continues running for about 1 minute to internally cool the projector. In the meantime, the ON
indicator on the projector flashes a blue color and buttons on the projector and remote control are
irresponsive to touch. Once the fan stops, the ON indicator goes out and the STANDBY indicator
lights up a green color to indicate the projector is on standby.

/" Q1)
/

- Do not pull out the AC power cord until the projector turns in standby mode.

- Do not pull out the power cord suddenly in the state of POWER ON." It can cause a breakdown.

- If the WARNING indicator lights up or blinks a yellow color, check that the fan has stopped then
unplug the AC power cord from its outlet.

- The projector will not be turned on H the ON button on the remote controller or the C) /| button on
the projector ls pressed immediately after turning ofl. Press the ON button on the remote controller
or (I) / I button on the projector after the projector turns into standby mode.

- When on standby, power to the projector is not OFF completely. It not planning to use the projector
for an extended period of time, unplug the AC power cord from AC power outlet as explained above.

Notes :
