PMD671
D&M Professional Europe
Kingsbridge House, Padbury Oaks, 575-583 Bath Road, Longford, Middlesex, UB7 0EH, UK
Tel: +44 (0)1753 680023 Fax: +44 (0)1753 686020 www.d-mpro.eu.com
Specifications are based on measurement conditions and proper care for the machines,
and are subject to change without notice.
Specifications
General
System Solid-state recorder
Number of Channels 2 (stereo), 1 (mono)
Usable Media CF memory cards, microdrives
Recording and Media Methods
.mp2 MPEG1 layer II compression
.mp3 MPEG1 layer III compression
.mp3 MPEG2 layer III compression*
*for all half sample rates PCM 16/24 bit linear PCM
Power Consumption
Recording/Playback 5.2 W
Charging 12 W
Standby (Battery Driven) 2.2 mW
Headphone Output Power 20 mW/32 ohms
Speaker Output Power 100 mW
Phantom Power +48 V, 10 mA
Dimensions (Maximum)
Width 264 mm
Height 55 mm
Depth 185 mm
Weight 1.3 Kg
Audio
Recording Bit rate (Selectable)
MP2 Stereo 284, 256, 192, 128, 96, 64 kbps
MP2 Mono 192, 128, 96, 64, 48, 32 kbps
MP3 Stereo 320, 256, 160, 128, 80, 64 kbps
MP3 Mono 160, 128, 80, 64, 40, 32 kbps
Sampling Frequency Analog
Analog -“ 16 bit48, 44.1, 32, 24, 22.05, 16, 12, 11.025, 8 kHz (PCM)
48, 44.1, 32, 24, 22.05, 16 kHz (MP3)
48, 44.1, 32 kHz (MP2)
-“ 24 bit 96, 88.2, 48, 44.1 kHz (PCM)
Digital 48, 44.1 kHz
Frequency Response (PCM 44.1 kHz) 20,000 Hz (-0.5 dB)
Signal-to-Noise Ratio IEC-A Weighted LINE 86 dB
MIC 65 dB
Total Harmonic Distortion at
0 VU (PCM) LINE 0.03%
MIC 0.08%
Dynamic Range 86 dB
Inputs/Outputs
MIC IN L/R Type XLR (1:GND, 2:HOT, 3:COLD)
Input Sensitivity 1.2 m Vrms/6.5 k ohms
LINE IN L/R Type RCA jack
Input Sensitivity 300 m Vrms/20 k ohms
LINE OUT L/R Type RCA jack
Standard Level 2 Vrms max./2 k ohms
DIGITAL IN/OUT Type RCA jack
Impedance 75 ohms
Standard Level 0.5 Vp-p
Sampling Frequency 44.1/48 kHz
Format SPDIF (IEC-958 type II)
