PMD620
Continued from previous page Specifications
Digital Audio System
System Solid State Recorder
Usable Media SD/SDHC Cards
Recording Format
MP3 MPEG1 Layer III Compression
WAV 16/24 Bit Linear PCM
Recording MP3 Bit-rate
Stereo 192/128/64 kbps
Mono 96/64/32 kbps
Sample Rate 44.1/48 kHz
Number of Channels 2 (Stereo) / 1 (Mono)
Audio Performance
Frequency Response 20 Hz ~ 20 kHz (±1 dB)
Signal-to-noise Ratio, IEC-A Weighted
MIC 68 dB
LINE 80 dB
Total Harmonic Distortion at 0 VU
MIC 0.06%
LINE 0.02%
Dynamic Range 81 dB
Inputs
External MIC
Type 1/8" stereo jack
Input Sensitivity 6 mVrms/30 kohms
LINE
Type 1/8" stereo jack
Input Sensitivity 500 mVrms/20 kohms
Outputs
LINE
Type 1/8" stereo jack
Standard Level 1.0 Vrms/10 kohms
Headphone
Type 1/8" stereo jack
Standard Level 16 mW/16 ohms
Speaker
Standard Level 150 mW/8 ohms
General
Power Consumption
Recording/Playback 1.5 W (DC)
Battery Life (Alkaline) 5 hours (Typical)
Phantom Power 5V, 1mA (Max.)
Environmental Conditions
Operational Temperature 0 ~ 40°C (32 ~ 104°F)
Operational Humidity 25 ~ 85% (No condensation)
Storage Temperature -“20 ~ 60°C (-“4 ~ 140°F)
Dimensions
Width 62 mm (2.5")
Height 102 mm (4")
Depth 25 mm (1")
Weight (Excluding Batteries) 110 g (4 oz)
Included Accessories
Audio Cable
USB Cable
AC Adapter
User Guide
CD-ROM
Handy Strap
Customer Registration Document (U.S. Only)
Tripod/Belt Clip Adapter
SD Card
* Specifications are subject to change without notice.
