DJs: While one well is playing at a certain pitch the
other well can be heard through the headphone output
and be cued up at a different pitch and then mixed with
the first. This is possible because each well offers
separate pitch control, inputs and outputs, and transport
controls; and the headphone select allows monitoring of
either well or a combination of the signal coming out of
both wells. APPLICATIONS
Houses of Worship: Sound tracks can be played on
one well, mixed with live vocals and instruments, and
recorded on the other well. In addition, one well can
record an entire service while the other well records just
the sermon. Regardless of the situation, the PMD510
saves space and money by not having to buy two
separate cassette decks.
Recording Studios and Mastering Facilities: The
professional appearance and sound quality enhance any
studio environment. The fact that the PMD510 is two
independent cassette decks in one 3U rackmount
chassis means that rack space is saved and
convenience is gained by having only one source for all
analog cassette recording needs.
Dance and Aerobics Studios: Each well has a
playback pitch/speed control to allow the music to be
slowed down or sped up. The linear time-based counter
on each well gives an accurate reading of the elapsed
time so that the workout times can be monitored.
Audio Logging: The cascading feature of the PMD510
allows it to work alone or be connected to multiple units
for continuous recording. After each well is finished
recording it triggers the next well, be it the next well in
that deck or the first well in another unit. All transfers
are optically sensing for minimal loss of audio.
Corporate Installations: The PMD510 is compatible
with Marantz (RC-5), AMX, and Crestron control
systems, to allow easy integration into almost any
system. It also allows two different sources to be
controlled independently so space is saved and greater
control is gained.
TECHNICAL SPECIFICATIONS
OVERALL
Number of Heads per Deck.............................................2
Head Type..................................Hard Metal Alloy (Rotary)
Numbers of Motors per Deck...........................................2
Motor Type........................................................DC Servo
Wow and Flutter (JIS weighted)..................less than 0.07%
Output Level............................................500mV / 1k ohm
Input Level.............................................100mV / 47k ohm
Power Requirements........................120VAC, 60HzPower
Consumption............................................................30W
FREQUENCY RESPONSE
Metal (Type IV) Tape................................20-18kHz (±
3dB)
CrO
2 (
Type II) Tape..................................20-17kHz (±
3dB)
Normal (Type I) Tape................................20-16kHz (±
3dB)
SIGNAL TO NOISE RATIO ('A' WEIGHTED)
No Noise Reduction.................................................56dB
Dolby B..................................................................66dB
Dolby C..................................................................72dB
DIMENSIONS/WEIGHT
Panel Height (3U).......................................5.2" (133mm)
Panel Width..............................................19.0" (480mm)
Depth.......................................................13.2" (334mm)
Weight.....................................................15lbs. (6.8kg)
Specifications are based on measurement conditions and proper care
for the machine, and are subject to change without notice.
Superscope Technologies, Inc. 2640 White Oak Circle
Aurora, Illinois 60504Telephone: (630) 820-4800
Fax: (630) 820-8103
