OVERALL
Frequency response..............................5-20kHz (±0.5dB)
Signal to Noise..................................................> 104dB
Channel Separation............................................> 100dB
Dynamic Range...................................................> 96dB
THD................................................................< 0.004%
Wow and Flutter...............................
Below Measurable Limits
D-A Conversion.....................................1-bit Sigma-Delta
Oversampling............................................................32x
Noise Shaping..................................................4th Order
RCA Analog Output Level.....................2VRMS / 200 ohm
XLR Analog Output Level...................1.2VRMS / 100 ohm
XLR Digital Output Level........................3.5Vp-p / 110 ohm
Coaxial (RCA) Digital Output Level..........0.5Vp-p / 75 ohm
Digital Output Format...........................SPDIF (IEC-958-II)
Power Requirements.................................120VAC, 60Hz
Power Consumption................................................22W
DIMENSIONS
Panel Height (2U).....................................3.5" (89mm)
Panel Width..............................................18.9" (480mm)
Depth.......................................................11.5" (293mm)
Weight.....................................................8.6lbs. (3.9kg)
Specifications are based on measurement conditions and proper care
for the machine, and are subject to change without notice.
Superscope Technologies, Inc. 2640 White Oak Circle
Aurora, Illinois 60504Telephone: (630) 820-4800
Fax: (630) 820-8103
Recording/Duplication Studios, Broadcast and
Mastering Facilities: Exceptional sound quality and a
digital output make the PMD320 and PMD321 extremely
versitile CD sources. The PMD321 gives added advantage by
having XLR outputs for analog and digital and the ability to
adjust the analog output level. Any type of professional
environment can benefit by the extraordinary fit and finish of the
PMD320 and PMD321.
DJs: The PMD320 and PMD321 offer the professional DJ all
the features needed to ensure a smooth and impressive
performance: fader start input, pitch control, cue-to-music,
direct track access, anti-skip mechanism, XLR connections,
and remote control capability.
Houses of Worship: The pitch of a soundtrack can be
altered by ±12% (in increments of 0.1%) to accomodate a
singer or choir's vocal range. The 10 digit keypad insures quick
and direct track access of up to 99 tracks.
A/V Rental: The PMD320 and PMD321 provide exceptional
quality, value, and versatility. Add their user-friendly operation,
and they become ideal for any professional rental scenario.
Dance and Aerobics Studios: Pitch control alters the
tempo of the music to suit a specific workout or choreography.
Additionally, the program function makes it easy to create a
custom track sequence.
Corporate Installations: Both models offer Marantz (RC-
5), AMX, and Crestron remote control compatibility, while
combining unmatched value and overall quality.
APPLICATIONSTECHNICAL SPECIFICATIONS
