1. FORWA RD
This docum ent de fin es t he de sig n and perf ormance re qu irem ents for HYUND AI IT
E-SERI ES MO DEL 26 ,32 ,37,42,46 LCD CO LO R TV
It is ca pa ble of displa ying maximum 1366X 768 r esolut ion i mage.
The LCD TV sc ree n comes equipp ed wit h a dedic ated term inal board
which is des ign ed to a A ccommodate an imag e s ign al from a v ariety
of multimedia sou rce su ch as DVD players,VCR s Camcoders a nd set-top box ,CATV
2. G ENE RAL DESC RIPTION
2.1 Features
This digital Terrestrial receiver is suit ed for DVB-T standard reception of
Free digital Terres tria l program and has the foll owing fea ture s;
* Full D VB -T com pliant
* H igh qua lity video and CD qua lity soun d by MPEG- 2 s tandard
* 3 000 pre-prog ramma ble statio n (vid eo :200 0ch,aud io;1 000c h)
* Use r fri en dly an d we ll -�defin ed O n Scree n Displa y
* Paren t lock and favorite select fun ction
* EPG (Electronic Progra m Guide)Func tion
* Full infrar ed remote cont rol
* Automatic scan f or add ed channel
* NIT scan function
* Manu al and auto matic scan pro grammin g
* D ispla y s igna l stren gth me ter on the sc ree n
* Op tica l co nne ctor for SPDI F Outpu t
* Output for Aud io L/R
* PIG (Picture in Graphi c) func tion
* High resol ution g rap hic with 25 6 color s
* Ch annel d elet e, move, edit and ad d fu nction
* Soft ware up grade with RS232 C
< Others>
* There are 7 language s OS D as Englis h, Deu tsch , Fran çais, N ed erland , Italiano,
E spañol, Suo mi
* A choice of W IDE, ZOOM and advanced 4:3 and 14:9
A UTO size aspect ratios
* High luminance and contrast rat io, low refle ction and w ide viewing a ngle
* PIP (Picture-In-Picture)
* Auto Volume Limit
* Noise Reduction
* Sound Mode Se ttin g(7 E qual ize r : 10 0Hz ,320 0Hz,1.0KHz, 3.0KH z,10K Hz)
* Picture Mo de Setting
Marantz Technical Service Ma\Hnual
Page 2
* Fu ll multimedi a ca pabi lity
* TE LETEXT(252pages : on ly A TV )
2.3 Ge ne ral Spe cification
The LCD TV is a Color Active Ma tri x Liqu id Cr ystal Display w ith an integra l
C old Cathode Flourscent Lamp(CCFL) backlight system.
T he matrix employs a-Si Thin Film Transistor as the active elem ent.
I t is a transmissive display type which is operated in the normally black mo de.
I t has a 31.51 inch diagonally measured active display area with WXGA resolu tion.
( 768 vertical by 1366 horizontal pixel array) Each pixel is divided int o
Red, Green and Blue sub-p ixels or dot s which are arran ge d in vertical stripes .
G ray scale or the luminance of the sub-pixel color is determined with
a 8-bit gray scale signal fo r ea ch dot, Therefore it c an pres ent a palette
o f more than 16.7M(true) Colors.
It ha s be en de signed to appl y th e 8Bi t 1 port L VDS interface .
It is intended to sup port LCD T V, PCT V where high bri ghtness ,
s uper wide viewing angle, high color gamut, high color dep th and fas t response
t ime are important
