Marantz ER 2500 Service Manual 2

Extracted text from Marantz ER 2500 Service Manual 2 (Ocr-read)

Page 1

Approved by N.Sensui Written by S.NAGAO WQ-19 2 817 /additional rule 3 (1st Issue 2003-03-19) ER2500 Service Bulletin REF.NBR: MZ05-009 page 2/3 MAIN PCB C537 100uF/16V is changed to 33uF/16V C531 100uF/16V is changed to 33uF/16V Remove R525 Remove R530

Page 2

Approved by N.Sensui Written by S.NAGAO WQ-19 2 817 /additional rule 3 (1st Issue 2003-03-19) ER2500 Service Bulletin REF.NBR: MZ05-009 page 3/3 MAIN PCB Pattern side Add Resister 75 ohm (2pcs)
