Page 1
ENGLISH PAGE 2INTRODUCTION
Safety Precautions
WARNING: TO REDUCE THE RISK OF FIRE OR ELECTRIC SHOCK, DO NOT EXPOSE THIS PRODUCT
TO RAIN OR MOISTURE.
CAUTION:THIS DVD PLAYER EMPLOYS A LASER SYSTEM.
TO ENSURE PROPER USE OF THIS PRODUCT, PLEASE READ THIS OWNERS MANUAL CARE-
FULLY AND RETAIN FOR FUTURE REFERENCE, SHOULD THE UNIT REQUIRE MAINTENANCE,
CONTACT AN AUTHORIZED SERVICE LOCATION-SEE SERVICE PROCEDURE.
USE OF CONTROLS, ADJUSTMENTS OR THE PERFORMANCE OF PROCEDURES OTHER
THAN THOSE SPECIFIED MAY RESULT IN HAZARDOUS RADIATION EXPOSURE.
TO PREVENT DIRECT EXPOSURE TO LASER BEAM, DO NOT TRY TO OPEN THE ENCLOSURE.
VISIBLE LASER RADIATION WHEN OPEN THE ENCLOSURE. DO NOT STARE INTO BEAM.
THE APPARATUS SHALL NOT BE EXPOSED TO DRIPPING OR SPLASHING AND THAT NO
OBJECTS FILLED WITH LIQUIDS, SUCH AS VASES, SHALL BE PLACED ON THE APPARATUS.
WARNING: CHANGES OR MODIFICATIONS NOT EXPRESSLY APPROVED BY THE PARTY RESPONSIBLE
FOR COMPLIANCE COULD VOID THE USERS AUTHORITY TO OPERATE THE EQUIPMENT.
The lightning flash with arrowhead symbol, within an
equilateral triangle, is intended to alert the user to the
presence of uninsulated dangerous voltage within the
products enclosure that may be of sufficient magnitude to
constitute a risk of electric shock to persons.
The exclamation point within an equilateral triangle is
intended to alert the user to the presence of important
operating and maintenance (servicing) instructions in the
literature accompanying the appliance.
CAUTION
AVERTISSEMENT
RISK OF ELECTRIC SHOCK
DO NOT OPEN
CAUTION : TO REDUCE THE RISK OF ELECTRIC
SHOCK, DO NOT REMOVE COVER (OR BACK).
NO USER SERVICEABLE PARTS INSIDE. REFER
SERVICING TO QUALIFIED SERVICE PERSONNEL.
RISQUE DE CHOC ELECTRIQUE NE
PAS OUVRIR
This product is manufactured to comply
with the radio interference requirements
of EEC DIRECTIVE 89/336/EEC,
93/68/EEC and 73/23/EEC.
IMPORTANT: (FOR/UK. version only)
This apparatus is fitted with an approved moulded 13 Amp plug. To change a fuse in this type of plug proceed as follows:
1. Remove fuse cover and fuse.
2. Fix new fuse which should be a BS1362 5A, A.S.T.A. or BSI approved type.
3. Refit the fuse cover.
If the fitted plug is not suitable for your socket outlets, it should be cut off and an appropriate plug fitted in its place.
If the mains plug contains a fuse, this should have a value of 5A. If a plug without a fuse is used, the fuse at the
distribution board should not be greater than 5A.
Note :
The severed plug must be destroyed to avoid a possible shock hazard should it be inserted into a 13A socket elsewhere.
HOW TO CONNECT A PLUG
The wires in the mains lead are coloured in accordance with the following code:
BLUE-"NEUTRAL" ("N")
BROWN-"LIVE" ("L")
1. The BLUE wire must be connected to the terminal which is marked with the letter "N" or coloured BLACK.
2. The BROWN wire must be connected to the terminal which is marked with the letter "L" or coloured RED.
3. Do not connect either wires to the earth terminal in the plug which is marked by the letter "E" or by the safety earth
symbol or coloured green or green-and-yellow.
Before replacing the plug cover, make certain that the cord grip is clamped over the sheath of the lead - not simply
over the two wires.
Page 2
ENGLISH
INTRODUCTION PAGE 3
Table of Contents
Introduction
- Safety Precautions . . . . . . . . . . . . . . . . . . . . . . . . 2
- Table of Contents . . . . . . . . . . . . . . . . . . . . . . . . . 3
- Precautions . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 4
- Notes on Discs . . . . . . . . . . . . . . . . . . . . . . . . . . 5
- Identification of Controls . . . . . . . . . . . . . . . . . . 6-9
Front Panel/Display Window . . . . . . . . . . . . . . . . . . . . 6
Rear Panel . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 7
Remote Control . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 8
Preparing the Remote Control . . . . . . . . . . . . . . . . . . . 9
Operating with the Remote Control . . . . . . . . . . . . . . . 9
Connections
- Connecting to a TV . . . . . . . . . . . . . . . . . . . . . . 10
- Connecting to an Audio System . . . . . . . . . . . . . 11
- Connecting to Optional Audio System . . . . . . 12-14
Enjoying Dolby Digital Sound . . . . . . . . . . . . . . . . . . . 12
Enjoying Dolby Pro Logic Surround Sound . . . . . . . . 13
Enjoying 2 Channel Digital Stereo Sound. . . . . . . . . . 14
Enjoying DTS Sound . . . . . . . . . . . . . . . . . . . . . . . . . 14
Basic Operation
- Basic Playback . . . . . . . . . . . . . . . . . . . . . . . 15-17
Selecting TV System Select Switch . . . . . . . . . . 16
Stopping Play . . . . . . . . . . . . . . . . . . . . . . . . . . 17
Resume Play . . . . . . . . . . . . . . . . . . . . . . . . . . 17
Last Scene Memory . . . . . . . . . . . . . . . . . . . . . 17
Screen Saver . . . . . . . . . . . . . . . . . . . . . . . . . . 17
Dimmer Function . . . . . . . . . . . . . . . . . . . . . . . 17
- Special Playback. . . . . . . . . . . . . . . . . . . . . . 18-19
Still Picture . . . . . . . . . . . . . . . . . . . . . . . . . . . . 18
Frame Advance . . . . . . . . . . . . . . . . . . . . . . . . 18
Skipping Chapters and Tracks Forward or Back . 18
How to Set the Video Mode . . . . . . . . . . . . . . . 18
HDCD Playback . . . . . . . . . . . . . . . . . . . . . . . . 18
To Scan at Fast Forward or Fast Reverse Playback . 19
Playing in Slow-Motion . . . . . . . . . . . . . . . . . . . 19
Operation Using GUI Menu Icons
- General Information about GUI Menu Icons . . . . 20
- Detailed Description of each GUI Menu Icon . . . 21
Advanced Operation
- Using a Title Menu . . . . . . . . . . . . . . . . . . . . . . . 22
- Using a DVD Menu . . . . . . . . . . . . . . . . . . . . . . 22
- Changing Subtitle Language . . . . . . . . . . . . . . . 23
- Changing Audio Soundtrack Language . . . . . . . . 23
- Viewing from another Angle . . . . . . . . . . . . . . . . 24
- Producing a 3D Surround Effect . . . . . . . . . . . . . 24
- Repeat Play . . . . . . . . . . . . . . . . . . . . . . . . . . . . 25
- Storing Markers in Memory to be Viewed
(Listened to) again . . . . . . . . . . . . . . . . . . . . . . . 26
- Zoom Feature . . . . . . . . . . . . . . . . . . . . . . . . . . 27
- Random Play . . . . . . . . . . . . . . . . . . . . . . . . . . . 27
- Program Play . . . . . . . . . . . . . . . . . . . . . . . . . . . 28
- Playback with MP3 . . . . . . . . . . . . . . . . . . . . 29-30
Initial Settings
- Selection of Initial Settings . . . . . . . . . . . . . . . . . 31
- Selecting Disc Languages . . . . . . . . . . . . . . . . . 32
- Selecting Rating Level and Password . . . . . . 33-34
- Selecting TV Aspect . . . . . . . . . . . . . . . . . . . . . . 35
- Selecting Menu Language . . . . . . . . . . . . . . . . . 36
- Setting Remote Control Codes . . . . . . . . . . . . . . 36
- Selecting Digital Audio Output . . . . . . . . . . . . . . 37
- Others . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 38
- Table of Languages and Their Abbreviations . . . 39
Reference
- Disc Requirements/Copyright Information . . . . . . 40
- Before Calling Service Personnel . . . . . . . . . . . . 41
- Specifications. . . . . . . . . . . . . . . . . . . . . . . . . . . 42
