Extracted text from Marantz DR 700 Service Bulletin (Ocr-read)
Page 1
Approved by H. TamuraWritten by K. Ono Date:16-Mar-01Model:DR4050Page:1/1REF.NB
MZ01-009SERVICE BULLETIN
Subject:Circulation:Application:Parts code number correction (003B).xfor information
customer complaint in
case of service
mandatory
...................ALL
Int.ref:[
PHENOMENON]
The parts WINDOW (003B) is not replaceable.
003BWINDOW 9965 000 07447 (PCS NO.) / 435W158010 (MJI NO.)
[
CORRECTION]
The window should be replaced together with the FRONT PANEL (002B).
Following front panels are including the window part.
003BFRONT PANEL
(BLACK)9965 000 07436
(PCS NO.) / 435W248010
(MJI NO.)
003BFRONT PANEL
(GOLD)9965 000 07435
(PCS NO.) / 435W248110
(MJI NO.)
Page 2
Approved by C. Miyayama Written by H. Tamura
Date: 28-May-99 Model: DR700
Page: 1/1 REF.NB MZ99-015
Subject:
Circulation:Application:
Int.ref:
[
INFORMATION]
The EPROM (
7322) has been updated to the
Version 1.8 since AH04. Updated functions are
follows;
1. Playable DISC
Before : Only Consumer CD-R/RW DISC is playable.
V.1.8 : Consumer CD-R/RW DISC and Professional CD-R/RW DISC both are playable.
(Professional CD-R/RW DISC is not recordable.)
REMAEK: This update had done with EPROM
V.1.4. The error indication for professional
DISC
NO AUDIO is not shown after this update.
2. STOP condition while recording Digital source
(Auto Track increment and Auto Stop)
Before : Recording will automatically to STOP after silent sound signal less than -50dB
continued 20sec.. (Detect the analogue signal level out put from the DAC.)
V.1.8 :
In case of CD and MD;
Recording will automatically to STOP approx. 3sec passed after the source DISC
stop. (Detect the VALIDITY FLAG standard in IEC958.)
In case of DAT;
Recording will automatically to STOP after silent sound signal less than -50dB
continued 20sec.. (no modification)
( In case of last Track playback for source: 1 Track recording)
Before : Recording will automatically to STOP after silent sound signal less than -50dB
continued 20sec.. (Detect the analogue signal level out put from the DAC.)
V.1.8 :
In case of CD and MD;
Recording will automatically to STOP approx. 3sec passed after the source DISC
stop.
In case of DAT;
Recording will automatically to STOP after silent sound signal less than -50dB
continued 20sec.. (no modification)
3. CD-RW erase
Before : Finalized DISC is recordable after DISC ERASE (ALL ERASE) only.
V.1.8 : Finalized DISC is recordable after DISC ERASE or TOC ERASE (Unfinalize).
In case of TOC ERASE, additional recording and last track ERASE are available.
4. Emphasis bit
Before : Emphasis bit will record to the DISC, in case of categories are
CD,
MD,
DAT and
DCC.
V.1.8 : Emphasis bit will record to the DISC, in case of categories are
CD,
MD,
DAT,
DCC,
Japanese digital audio broadcast and
General.
[
REMARK]
Service code numbers
4822 900 11271 of that EPROM is not changed by this modification.
The latest version of the EPROM is supplied always by same service code number.
SERVICE BULLETIN
EPROM (7322
) version up: V.1.8 x for information
customer complaint
in case of service
mandatory
...................
AH03
or
earlier
