Specifications
System Compact Disc Digital Audio (CD DA)
Number of Channels 2 (stereo)
Applicable DiscsCD, CD R, CD RW
Power Requirement AC 120V 60 Hz
Power Consumption20 W
Allowable Operating Temperature +5 to +35 °C
Allowable Operating Humidity 5 ~ 90 % (No Condensation)
Dimensions (Maximum)Width 19" (483 mm)
Height3 15/16" (100 mm)
Depth 13 7/16" (340 mm)
Net Weight 11.7 lbs (5.3 kg)
CD RecorderRecording (Analog)
Frequency Response 20Hz ~ 20kHz +0/ 2 dB
Signal to Noise Ratio (IEC A) 86 dB
Total Harmonic Distortion (1kHz) 0.015%
Channel Separation (1kHz) 75 dB
Dynamic Range86 dB
PlaybackFrequency Response 20Hz ~ 20kHz +0/ 1 dB
Signal to Noise Ratio (IEC A) 100 dB
Total Harmonic Distortion (1kHz) 0.01%
Channel Separation (1kHz) 78 dB
Dynamic Range 86 dB
Input/OutputAnalog Input Sensitivity/Impedance
Balanced (XLR) 0 ~ +20 dBu /47 kΩ
(Default Setting: +16 dBu)
Unbalanced (RCA) 500 mV rms /47 kΩ
Analog Output (RCA) 2 V rms /200Ω
Coaxial Digital In/Out (RCA) 0.5 Vp p /75 Ω
Optical Digital Input 19 dBm
Digital Input Frequency32/44.1/48kHz(11 ~ 56 kHz)
MP3/CD PlayerApplicable DiscsCD, CD R, CD RW, MP3 Disc
Frequency Response 20Hz ~ 20kHz +0/ 0.5 dB
Signal to Noise Ratio (IEC A) 100 dB
Total Harmonic Distortion (1kHz) 0.003%
Channel Separation (1kHz) 96 dB
Dynamic Range 96 dB
Analog Output (RCA) 2 V rms /200 Ω
Coaxial Digital Output (RCA) 0.5 Vp p /75Ω
Pitch Control ±12.0%, 0.1% Step
Headphone 0 ~ 5V rms /8 ~ 2000 Ω
RS232C Remote D Sub 9 Pin, Female
RC5 Remote In/OutRCA w/Loop Out
CDR510
