Page 1
2
Always Heed the Following
Examples of Symbols
Ignoring this indication and improper handling could be the cause of per-
sonal injury such as a serious injury or death. WARNING
CAUTION
Ignoring this indication and improper handling could cause injury to a per-
son or damage to the surrounding household belongings.
Before Use...
Symbols
Various symbols are used in this Handling Instructions for the safe and proper use of the product as well as
preventing any injury or damage to persons or property. These symbols and their meanings are described
below. Please have a good understanding of these matters before reading the main text of the manual.
This symbol informs that there are contents that demand caution (including warnings).
Concrete details of the caution are written within the diagram.
This symbol indicates a prohibited matter.
Concrete details of the prohibition are written within the diagram.
This symbol indicates something that must be done.
Concrete details of the prohibition are written within the diagram.
- To ensure safety, tighten bolts and screws securely.
Failure to do so could cause the Plasma Display to tip over, resulting in injury.
- Do not modify parts.
Doing so could cause the Plasma Display to tip over, resulting in injury.
- Do not use damaged parts. Doing so could cause the Plasma Display to tip over, resulting in injury.
If a part should be damaged, contact the store of purchase.
- Each unit is designed specifically for use with MARANTZ 61-inch plasma displays. Please do not mount any other
equipment with these items. Doing so may cause the item to fall over and result in injury.
- Do not set on shaky stands, tilted surfaces or other unstable places. Doing so could cause the Plasma Display to tip
over or fall, resulting in injury. Moreover, Do not install into a vehicle. - Be sure to have the Plasma Display installed by your store of purchase following the instructions in this manual.
If installed incorrectly, the Plasma Display could tip over, resulting in injury.
WARNING
Page 2
3
50mm/1.97inch
50mm/1.97inch 50mm/
1.97inch50mm/
1.97inch
50mm wall
Always Heed the Following
NOTES
CAUTIONS
- Do not obstruct the Plasma Displays ventilation holes.
If the ventilation holes are covered, the heat will build up inside, and this could lead to fire.
For example, do not install the Plasma Display in narrow spaces where ventilation is poor, do not place covers over it, etc.
- Do not install the Plasma Display near air conditioner air outlets or in places where vibrations are strong.
Doing so could lead to fire or electric shock.
- Do not install the Plasma Display in humid or dusty places or places exposed to soot or vapor (such as in kitchens,
near humidifiers, etc.). Doing so could lead to fire.
Do not install the Plasma Display outdoors. Doing so could lead to fire or electric shock.
Avoid dusty or humid rooms and rooms filled with soot or cigarette smoke.
The Plasma Displays screen could get dirty, resulting in poor picture quality.
Avoid places where the screen is exposed to direct sunlight or strong artificial light.
If surrounding light should shine on the screen, the screen will appear white and be hard to see.
Do not install in places where the temperature is high or low.
Doing so could result in damage.
- Hold the Plasma Display securely when mounting the units on it. Failure to do so could cause the Plasma Display to
fall, resulting in injury.
- When installing the Plasma Display on a stand with casters, be sure to block the casters. If the stand should move,
the Plasma Display could fall, resulting in injury.
- The Plasma Display is heavy, so be sure to install in a stable place and take measures to prevent it from tipping over
and causing injury.
The Plasma Display has a high center of gravity. It should be unpacked and moved by a minimum of two people,
holding it at the top and bottom. Failure to do so could cause the Plasma Display to fall, resulting in injury.
- When installing the Plasma Display, leave sufficient space around it, as shown
in the diagram. Failure to do so could cause heat to build up inside, leading
to fire.
Additional fall prevention measures
- Either use the tip prevention fitting included with the display to fix the
plasma display to a wall, pillar or other strong place or use the holes on
the back on the stand to fix to a table, etc..(Do no use with the separately
sold ceiling mount unit or wall mount unit.)
- Pay attention to the rope when moving the Plasma Display.
- The screws for fastening the display to the wall, a pillar or a stand are not
included. Please obtain screws suited for the surface on which the display is
to be mounted.
