Page 2

CONTROLS & CONNECTORS

1.

Selector Switch

This switch selects AM or FM reception. On "AM"
position AM reception can be obtained. When FM
reception is desired, set this switch to FM stereo
auto" position, by which automatic switch-over be-
tween FM stereo and FM monaural is possible.
"Mono" position may be used for reception in case
such a weak signal unpractical for stereo reception
is available, or in case stereo signal is desired com-
pulsorily to be obtained through monaural reception.
AM/FM Dial

Turn the tuning knob according to frequency printed
on dial and a desired signal can be received. Receiv-
able frequency range for FM section is from 88MHz
to 108MHz, and that for AM is from 525KHZ to
1605KH2.

Stereo Indicator Lamp

When FM on reception changes from monaural to
stereo, this beacon lights up and indicates stereo
reception. When selector switch (1) is set to "FM
stereo auto", sterco indicator lamp lights up and
stereo reception is automatically obtained. When it
is set to "mono", the lamp does not light up, and
needless to say stereo reception cannot be obtained.
Tuning Knob

Use this knob for tuning on any desired FM or AM

stations.

lUXMAh I 1.:

Signal Indicator (tuning/signal strength)

This indicator offers 3 operations; AM Signal Strength
Meter, FM Centre Tuning Meter and FM Signal
Strength Indicator.

AM Signal Strength Meter

The accurate tuning point is obtained by the maxi-
mum swing of the needle of this meter. The needle
movement may be dependent on the strength of
receiving signals. Even if the needle swings to the
extreme right, it does not impair the meter. Such
wave that can be received when muting switch is at
the on" position is effective as a programme source.
The needle moves from the centre position towards
the right direction.

FM Centre Tuning Meter

When no signal is on reception, this meter remains at
the centre position. As the tuning knob is turned,
the needle of this meter comes out of the centre, and
when the accurate tuning point is very near, the
needle comes again closer to the centre position.
Therefore, an accurate tuning point is obtained when
the needle comes to the real centre position.

FM Signal Strength Indicator

The accurate tuning point is obtained when the
indicator lamp of Light Emitting Diode lights up.
Such wave that cannot be cut off when muting switch
is at the on position is effective as stereo reception.

l_3.

-6.
L-7.

L- 5. Signal Indicator

-8. Power Switch

Stereo Indicator
AM/FM Dial

FM Noise Filter
FM Muting Switch

- 2.

TUNING

Lamp

-4. Tuning Knob

L- I. Selector Switch
