-™Introduced 2005
-™Dimensions H 80 mm x W 381 mm x D 368 mm
H 3
1-„8inches x W 15 1-„16inches x
D 14 9-„16inches
-™Weight 6.4 kg / 14.2 lbs
-™Power consumption 17 W standby
120 W rated power
-™Main supply fuse T10 AL 250 V (internal)
-™Main supply range Switching power supply with auto-ranging
(100 - 120 V ac @ 50 - 60 Hz)
(220 - 240 V ac @ 50 - 60 Hz)
-™CD / DVD engine Dual beam laser pick up
-™Audio decoding Dolby Digital, Dolby Pro Logic II, DTS
-™Video standards PAL and NTSC signal operation
-™Compatible disc types DVD-Video, CD, VCD, DVD+R/-R/+RW/-RW,
CD-R/-RW
-™Compatible formats MPEG-2 (DVD-Video), MPEG-1 (VCD), JPEG
(picture discs), LPCM (CD), DTS CD, MP3
-™Video inputs (SCART) SCART (RGB, YPrPb, Composite)
S-video on 4 pin DIN
-™Audio inputs (SCART) 2 RCA phono inputs
1 optical digital input &
1 coaxial digital input
SCART (analogue stereo audio inputs)
-™Video outputs (SCART) SCART (RGB, YPrPb, Composite)
S-video on 4 pin DIN
-™Audio outputs (SCART) 5 speaker level safety compliant outputs
5.1 line level RCA phono outputs
Line level record output
Optical digital output
SCART (analogue stereo audio outputs)
-™Video inputs (Phono) YPrPb, S-video, Composite
-™Audio inputs (Phono) TV and Aux AV inputs
2 RCA phono inputs
1 optical digital input &
1 coaxial digital input
-™Video outputs (Phono) YPrPb, S-video, Composite
-™Audio outputs (Phono) 5 speaker level safety compliant outputs
5.1 line level RCA phono outputs
Line level record output
Optical digital output
-™Power amplifier 75 W RMS per channel into 4 -„¦
-™Tuner FM aerial terminal
AM aerial terminal-™Tuner range USA: FM 87.5 MHz to 108.5 MHz
AM 530 kHz to 1730 kHz
Japan: FM 75.5 MHz to 108.5 MHz
AM 522 kHz to 1629 kHz
Europe: FM 87.5 MHz to 108.5 MHz
AM 522 kHz to 1611 kHz
-™Tuning resolution FM TUNE mode: 50 kHz,
FM SCAN mode: 100kHz,
AM TUNE mode: 1kHz,
AM SCAN mode: 10kHz USA,
9 kHz Japan and Europe
-™Presets 200 user definable presets
-™Headphones Output impedance - 5 -„¦
-™Load impedance 8 -„¦to 4 -„¦
-™Multi-room 4 RJ45 sockets
Accessory socket: Allows connection of a
Linn Room Controller Unit.
Room In: allows connection of balanced audio
and communication with the Linn KNEKT system.
IR Flasher 1 and 2: Allows connection of an IR
diode to allow control of other equipment.
6 mA constant current output.
Modulation frequency can be varied from
20 kHz to 450 kHz
CLASSIK MOVIE
TECHNICAL SPECIFICATION
An innovative, high-performance total entertainment solution for movies,
music and multi-room
