General user instructions
1. Water and Moisture. Do not use the appliance near water, for example near a bathtub,
washbowl, kitchen sink, laundry tub, in a wet basement, or near a swimming pool and the
like.
2. Heat. Site the appliance away from heat sources such as radiators, heaters, stoves, or
other appliances (including amplifiers) that produce heat.
3. Cleaning. The product should be cleaned only as recommended by the manufacturer.
4. Objects and liquid entry. Take care not to let objects or liquids fall onto the product.
5. Damage requiring service. The product should be serviced by qualified personnel if :
a. Objects or liquid have fallen into the product.
b. The product has been exposed to rain.
c. The product does not appear to operate normally or exhibits a
marked change in operation.
d. The product has been dropped or the enclosure damaged.
6. Servicing. Dont attempt to service the product beyond that described in the operating
instructions. All other servicing should be referred to qualified service personnel.
Battery types and replacement
Four AAA or LR03 cells, or equivalent.
Copyright and acknowledgements
Copyright © Linn Products Limited.
Linn Products Limited, Floors Road, Waterfoot, Glasgow, G76 0EP, Scotland, United
Kingdom.
All rights reserved. No part of this publication may be reproduced, stored in a retrieval
system, or transmitted, in any form or by any means, electronic, mechanical, photocopying,
recording, or otherwise, without the prior written permission of the publisher.
Printed in the United Kingdom.
AV 5101, AV 5103, AV 5105, AV 5110, AV 5120, AV 5140, and AV 5150 are trademarks of
Linn Products Limited.
The information in this manual is furnished for informational use only, is subject to change
without notice, and should not be construed as a commitment by Linn Products Limited.
Linn Products Limited assumes no responsibility or liability for any errors or inaccuracies
that may appear in this manual.
Part no: PACK 258
This manual was produced by Human-Computer Interface Ltd, Cambridge, England.
