P R E F A C E
iii
c) Fit a new 5 Amp BS1362 approved fuse into the carrier and push the carrier back into
the plug.
Always ensure the fuse cover is fitted. If the fuse cover is missing do not use the
plug. Contact your Linn retailer to obtain a replacement fuse cover. Fuses are for fire
protection and do not protect against electric shock.
F U S E R A T I N G S
220V/230V/240V setting: 3.15A anti-surge.
115V/100V setting 6.3A anti-surge.
R E P L A C I N G T H E F U S E
Should the mains fuse blow replace it only with an equivalent part. The fuse holder is
located just below the mains inlet socket. To replace the fuse disconnect the product
from the mains supply. Using a flat blade screwdriver remove and replace the fuse. If
the fuse blows a second time there is a fault in the product. Contact your local retailer.
M A I N S V O L T A G E O P E R A T I N G R A N G E
115V, 230V +/- 10%, 50-60Hz.
SETTING THE MAINS OPERATING VOLTAGE
Please check the setting of the voltage selector switch at the mains input socket before
connecting the product to a mains supply.
The AV5105 Stereo Power Amplifier is supplied set for 230v operation for use in
Europe. To set it for 115V operation disconnect it from the mains and slide the voltage
selector switch to the appropriate position.
Warning!! The power supply may be destroyed if it is connected to 240V when set for
120V.
POWER CONSUMPTION
Operate mode 25W-850W
Standby mode 5W
11. Power Cord Protection. Route power cords so that they are not likely to be walked
on or pinched by items placed upon or against them, paying particular attention to
cords at plugs, power sockets and at the point where they exit from the appliance.
12. Protective Attachment Plug. As a safety feature the product is equipped with
an attachment plug containing overload protection. See the instruction manual
about resetting or replacing the plug. Should the plug need replacing ensure that a
replacement is used which has the same overload protection as the original.
13. Cleaning. The product should be cleaned only as recommended by the
manufacturer.
14. Non use periods. Unplug the power cord from the outlet if the product will be
unused for a long period of time.
15. Objects and liquid entry. Take care not to let objects or liquids fall into the product.
16. Damage requiring Service. The product should be serviced by qualified personnel if :
a. The power cord or plug has been damaged.
b. Objects or liquid have fallen into the product.
c. The product has been exposed to rain.
d. The product does not appear to operate normally or exhibits a marked
change in operation.
e. the product has been dropped or the enclosure damaged.
17. Servicing. Do not attempt to service this product. All servicing should be referred to
qualified service personnel.
UK USERS PLEASE READ THIS IMPORTANT SAFETY INFORMATION
The AV 5105 Stereo Power Amplifier is fitted with a non-rewireable 13 Amp mains
plug. The plug contains a 5 Amp fuse.
If the fuse has blown it can be replaced :
a) Pull out the red fuse cover/carrier.
b) Remove and dispose of the blown fuse.
