lexicon Reflex User Guide Rev1

Extracted text from lexicon Reflex User Guide Rev1 (Ocr-read)


Page 1

Unpacking and Inspection After unpacking the unit, save all packing materials in case you ever need to re-ship. Thoroughly inspect the unit and packing materials for signs of damage. Report any shipment damage to the carrier at once; report equipment malfunction to your dealer. This equipment generates and uses radio frequency energy and if not installed and used properly, that is, in strict accordance with the manufacturer's instructions, may cause interference to radio and television reception. It has been type tested and found to comply with the limits for a Class B computing device in accordance with the specifications in Subpart J of Part 15 of FCC Rules, which are designated to provide reasonable protection against such interference in a residential installation. However, there is no guarantee that interference will not occur in a particular installation. If this equipment does cause interference to radio or television reception, which can be determined by turning the equipment OFF and ON, the user is encouraged to try to correct the interference by one or more of the following measures: reorient the receiving antenna; relocate the computer with respect to the receiver; move the computer away from the receiver; plug the computer into a different outlet so that the computer and receiver are on different branch circuits. If necessary, the user should consult the dealer or an experienced radio/television technician for additional suggestions. The user may find the following booklet prepared by the Federal Communications Commission helpful: "How to identify and Resolve Radio/TV Interference Problems." This booklet is available from the U.S. Government Printing Office, Washington, DC 20402, Stock No. 004-000-00345-4. Notice Le présent appareil numérique n'émet pas de bruits radioélectriques dépassant les limites applicables aux appareils numériques de la class B prescrites dans le Règlement sur le brouillage radioélectrique édicté par le ministère des Communications du Canada. Lexicon Part 070-10229 Rev 1Printed in the U.S.A. Lexicon Inc. 3 Oak Park Bedford, MA 01730 USA Telephone 781-280-0300 Fax 781-280-0490 Copyright 1994, 1995 Lexicon Inc. All Rights Reserved.

Page 2

Table of Contents Getting Started ......................................................................... 1 Introduction ............................................................................ 1 Front Panel Overview ............................................................ 2 Setting Audio Levels Rear Panel Connections ........................................................ 4 Footswitch Connections - Headphones MIDI Connections - Switching from MIDI OUT to MIDI THRU Front Panel Operation ............................................................. 7 Overview ................................................................................ 7 Presets and Registers ........................................................... 8 More Effects About the Parameters .......................................................... 11 Front Panel Parameter Controls Loading an Effect ................................................................. 13 Editing an Effect .................................................................. 14 Storing an Effect .................................................................. 15 Performing an Edit Compare ............................................... 16 Using Footswitches ............................................................. 17 Bypass - Stepping through the Registers - Clearing Registers - Skipping Registers and Creating Chains Advanced Programming Mode ............................................. 19 Overview .............................................................................. 19 APM Utility Functions .......................................................... 20 Algorithms and Parameters ................................................. 21 Hall ............................................................................... 22 Plate ............................................................................. 23 Flanger ......................................................................... 24 Multi Taps ..................................................................... 25 Resonator ..................................................................... 26 Inverse .......................................................................... 27 Gate .............................................................................. 28 Chorus .......................................................................... 29 More about the Algorithms ........................................... 30 MIDI Operation ........................................................................ 31 MIDI Configurations ............................................................. 32 Learning a MIDI Channel ..................................................... 34 Dynamic MIDI ® Patching ...................................................... 35 Creating a Dynamic MIDI Patch - Multiple Patches to a Parameter - Deleting a Patch - Display of MIDI Parameter Changes - Special Notes on MIDI Programming - MIDI Bypass MIDI Implementation Chart .................................................. 44 Specifications ......................................................................... 46
