Page 1
Lexicon, Inc.
3 Oak Park
Bedford, MA 01730-1441 USA
Tel 781-280-0300
Fax 781-280-0490
www.lexicon.com
Customer Support
Tel 781-280-0300
Fax 781-280-0495 (Sales)
Fax 781-280-0499 (Service)
Lexicon Part No. 070-14710 | Rev 2 | 10/02
Manufactured under license from Dolby Laboratories. "Dolby," "Pro Logic," "Surround EX," and the double-D symbol are trademarks of
Dolby Laboratories.
Manufactured under license from Lucasfilm Ltd. U.S. Patent Nos. 5,043,970; 5,189,703; and/or 5,222,059. European Patent No.
0323830. Other U.S. and foreign patents pending. Lucasfilm and THX are trademarks or registered trademarks of Lucasfilm Ltd.
Surround EX is a trademark of Dolby Laboratories. Used under authorization.
Manufactured under license from Digital Theater Systems, Inc. U.S. Patent Nos. 5,451,942; 5,956,674; 5,974,380; 5,978,762 and other
worldwide patents issued and pending. "DTS," "DTS-ES Extended Surround," and "Neo:6" are trademarks of Digital Theater Systems,
Inc. © 1996, 2000 Digital Theater Systems, Inc. All rights reserved.
"Lexicon," "LOGIC7," and the L7 logo are registered trademarks of Harman International Industries, Inc. U.S. Patent Nos. D454,553;
D454,860; 5,796,844; 5,870,480 and other worldwide patents issued and pending. © 2002 Lexicon, Inc. All rights reserved.
This document should not be construed as a commitment on the part of Lexicon, Inc. The information it contains is subject to change without notice. Lexicon, Inc.
assumes no responsibility for errors that may appear within this document.
Page 2
DOCUMENTATION CONVENTIONS This document is a supplement to the MC-12 User Guide (Rev 1). It contains release notes that provide information about the new and
enhanced features of Software Version 2.0. It also includes release notes for Software Version 1.1 and errata notes for the MC-12 User
Guide (Rev 1). Refer to the user guide for general safety, installation, and operating instructions.
This document uses the term "MC-12" to refer to the MC-12 Digital Controller and the MC-12 Balanced Digital Controller
unless otherwise specified.
The following symbols are used in this document:
Calls attention to a procedure, practice, condition or the like that, if not correctly performed or adhered to, could result
in damage or destruction to part or all of the product. Note:
Calls attention to information that is essential to highlight.
Calls attention to features that were introduced or modified in Software Version 1.1.
Calls attention to features that were introduced or modified in Software Version 2.0.
Represents a menu path. Select the menu items identified in grey boxes to reach the menu or parameter identified
in the black box. In the example shown above, the SETUP option, INPUTS option, DVD1 input, and NAME parameter
must be selected to reach the INPUT NAME menu.
The DVD1 input and the DVD1 INPUT SETUP menu are used as examples throughout this document. Whenever the
DVD1 input appears as a selection in a menu path, any other input may be substituted. Likewise, whenever the DVD1
INPUT SETUP menu is shown in a figure, any other INPUT SETUP menu may be substituted.
DVD1 INPUT NAME
NAME
DVD1
INPUTS
SETUP CAUTION v1.1 v2.0
