Lexicon LXP1

Page 2

Precautions

The LXP-1 is a rugged device with extensive electronic protection. However,
you should observe the same reasonable precautions that apply to any
piece at audio equipment:

V
I/

V

Always use the correct line voltage and power pack.

Don't install the LXP-1 in a closed, unventilated rack, or directly above
heat-producing equipment such as power amplifiers.

Never attach audio power amplifier outputs (speakeroutputs) directly to
any of the LXP-ls connectors.

To prevent fire or shock hazard, do not expose the LXP-1 to rain or
moisture.

Copyright © 1988 Lexicon, inc.

100 Beaver Street
Waltham, MA 02154 USA
617/891-6790

Telex 923 468

All Rights Reserved

This publication is protected by copyright and all rights are reserved. No part
of it may be reproduced ortransmitted by any means or in any form, without
express prior consent in writing from Lexicon.

Printed in Hong Kong

LXP-1

Owner's Manual

Lexicon Part # 07006023
Revision 1.2

Table of contents

Precautions
FCC Notice
Introduction .......
Specifications...

Installing the LXP-1 .
Unpacking .....
Mounting
Power .........

LXP-1 front panel controls ..........
LXP-t rear panel connections
Audio connections ....................

Operating the LXP-1 .
Setting audio levels
DEFEAT switch operation
Selecting LXP~1 preset programs
Changing parameters ........................
Descriptions of programs and parameters
Program table: Reverbs ...............................
Program table: Reverb and delay effects .................................... 210

MIDl operations .....
introduction
Accessing LXP- regis ers
Using Dynamic MlDle ......
The LXP-1 and MIDl System Exclusive data

MIDI implementation data .......................................................... 4-1

M
