Lexicon Core2 User Guide 212

This is the 36 pages manual for lexicon Core2 User Guide 212.
Read or download the pdf for free. If you want to contribute, please mail your pdfs to info@audioservicemanuals.com.

Page: 1 / 36
left right
lexicon Core2 User Guide 212

Extracted text from lexicon Core2 User Guide 212 (Ocr-read)


Page 1

Unpacking and Inspection After unpacking the system modules, save all packing materials in case you ever need to ship the units. Thoroughly inspect the modules and packing materials for signs of damage. Report any damage to the carrier at once; report equipment malfunction to your dealer. Lexicon Part # 070-13748 Copyright 1999, Lexicon Inc. All Rights Reserved.Lexicon Inc. 3 Oak Park Bedford MA 01730-1441 Telephone 781-280-0300 Fax 781-280-0490 www.lexicon.com Outdoor Antenna Grounding If an outside antenna is connected to the receiver, be sure the antenna system is grounded so as to provide some protection against voltage surges and built-up static charges. Section 810 of the National Electrical Code, ANSI/NFPA No. 70-1984, provides information with respect to proper grounding of the mast and supporting structure, grounding of the lead-in wire to an antenna-discharge unit, size of grounding conductors, location of antenna-discharge unit, connection to grounding electrodes, and requirements for the grounding electrode. See figure below. Power Lines An outside antenna should be located away from power lines. Power Service Grounding Electrode System (NEC Art 250, Part H)Antenna Lead-in Wire Antenna Discharge Unit (NEC Section 810-20) Grounding Conductors (NEC Section 810-21)Ground Clamps NEC - National Electrical CodeElectric Service EquipmentGround Clamp Le présent appareil numérique n'émet pas de bruits radioélectriques dépassant les limites applicables aux appareils numériques de la class B prescrites dans le Règlement sur le brouillage radioélectrique édicté par le ministère des Communications du Canada. This equipment generates and uses radio frequency energy and if not installed and used properly, that is, in strict accordance with the manufacturer's instructions, may cause interference to radio and television reception. It has been type tested and found to comply with the limits for a Class B computing device in accordance with the specifications in Subpart B of Part 15 of FCC Rules, which are designated to provide reasonable protection against such interference in a residential installation. However, there is no guarantee that interference will not occur in a particular installation. If this equipment does cause interference to radio or television reception, which can be determined by turning the equipment OFF and ON, the user is encouraged to try to correct the interference by one or more of the following measures: Reorient the receiving antenna Relocate the computer with respect to the receiver Move the computer away from the receiver Plug the computer into a different outlet so that the computer and receiver are on different branch circuits. If necessary, the user should consult the dealer or an experienced radio/television technician for additional suggestions. The user may find the following booklet prepared by the Federal Communications Commission helpful: "How to identify and Resolve Radio/TV Interference Problems." This booklet is available from the U.S. Government Printing Office, Washington, DC 20402, Stock No. 004-000-00345-4. Communications Notice "ADAT" is a trademark of the Alesis Corporation. "Cool Edit Pro" is a trademark of Syntrillium. "Type IV is a trademark of dbx Corporation.

Page 2

Table of Contents 1 Getting Started Introduction ................................................................................................ 1 System Requirements ................................................................................. 2 2 Installation Precautions ................................................................................................ 3 Hardware Installation ................................................................................... 3 Setup - Install the Card - Cables/Connections Software Installation .................................................................................... 6 Install Supported Third Party Software - Install the Lexicon Studio Driver for Windows - Running the Setup.exe Program Updating Drivers .......................................................................................... 7 Remove the Old Software - Update Studio Driver - Reinstall Setup.exe 3 Using the LexPanel Core2 Tab .............................................................................................. 11 Analog Input - dbx Type IV-„¢ Punch Tab .............................................................................................. 16 Configuring the Punch Tab - The MIX Level Control - The Monitor Buttons Clock Source Tab ...................................................................................... 18 4 Using Cool Edit Pro Installing Cool Edit Pro .............................................................................. 19 Assigning I/O in Cool Edit Pro ................................................................... 20 Optimizing Multitrack Performance in Cool Edit Pro ................................. 21 5 Troubleshooting Common Problems and Solutions ............................................................. 23 Optimizing Windows for Audio Applications .............................................. 26 6 Specifications
