Krell SACD Standard Addendum: Mode Notes, v05.02
© 2005 by Krell Industries, Inc. All rights reserved P/N 307776 A
KRELL SACD Standard -“ MODE Navigation Notes, continued
From a multi channel SACD: press the SACD/CD button
THREE (3) times to enable CD.
From two channel SACD: press the SACD/CD button TWO (2)
times to enable CD.
A 30 second delay becomes apparent before the CD play mode
begins with either of the above.
3. To access the SACD layer from the conventional CD layer of the
hybrid disc press the STOP button and wait for the track number
total to appear.
Press the SACD/CD button TWO (2) times to enable the SACD
layer. The disc begins playing the multi channel tracks.
Press the SACD/CD button THREE (3) times to enable the
SACD layer. The disc begins playing the multi channel tracks.
Make sure that a half second interval is used when pressing the
SACD/CD button. Rapid action on any of the front panel buttons caninterrupt playback or alter the direction of the command.
The SACD Standard defaults to CD when a conventional CD or
CD R disc is installed. The display reads CDDA and automatically
starts to play.
A hybrid disc always begins with the multi Ch SACD tracks, never on the
traditional CD layer.
IMPORTANT
Note
Note
PRESS STOP PRESS SACD/CD
DISC TYPEOPERATIONBUTTONBUTTON
HYBRID Multi Ch SACD, Two Ch SACD 1x 2x
HYBRID Multi Ch SACD, Traditional CD 1x 3xHYBRIDTwo Ch SACD, Traditional CD 1x 2x
HYBRID Two Ch SACD, Multi Ch SACD 1x 3x
HYBRID Traditional CD, Multi Ch SACD 1x 2x
HYBRID Traditional CD, Two Ch SACD 1x 3x
2CH / MULTI SACD Multi Ch SACD, Two Ch SACD 1x 2x
2CH / MULTI SACD Two Ch SACD, Multi Ch SACD 1x 2x
Quick
Reference
