Page 1
Krell S-2751
Introduction
Thank you for your purchase of the Krell S-275 Stereo Power
Amplifier. This configurable power amplifier has a discrete signal
path from input to output and employs a wide bandwidth design
with low negative feedback for sonic accuracy throughout the fre-
quency spectrum. All circuits up to the driver stage are balanced
and pure Class A.
Krells new surface mount technology (SMT) means that the S-275
is a power amplifier with big power 275 Watts per channel that
does not require big space. SMT allows individual circuit elements
to be placed very closely together. This shortens signal paths and
allows circuit elements to operate at the same temperature, result-
ing in more accurate signal transfer and enhanced reliablilty.
The S-275 is a slim line design allowing two amplifiers to fit into a
space normally occupied by one. For systems requiring higher
power, the S-275 can be configured for monaural operation by set-
ting a switch on the rear panel. Power output increases to 550
Watts into 8 Ohms. A 6 dB gain switch provides a channel balanc-
ing tool for systems using a combination of balanced and RCA
style connections.This owners reference contains important infor-
mation on the placement, installation, and operation of the S-275.
Please read this information carefully. A thorough understanding of
these details will help ensure satisfactory operation and long life
for your S-275 and related system components.
Page 2
Definition of Terms
Following are the definitions of key terms used in your owners ref-
erence manual.
Monaural Operation
Monaural operation combines the output of the left and right chan-
nels to create a more powerful single channel. In the case of the
S-275, the output increases to 550 Watts.
Balanced
A symmetrical input or output circuit that has equal impedance
from both input terminals to a common ground reference point.
The industry standard for professional and sound recording instal-
lations, balanced connections have 6 dB more gain than single-
ended connections and allow the use of long interconnect cables.
Balanced connections are completely immune to induced noise
from the system or the environment.
Single-ended
A two-wire input or output circuit. Use care when using single-
ended connections as the ground connection is made last and
broken first. Turn the system off prior to making or breaking single-
ended connections. Single-ended connections are not recom-
mended for connections requiring long cable runs. CONFIGURATIONS
INPUT AND OUTPUT
CONNECTIONS
2Krell S-275
