IMPORTANT SAFETY INSTRUCTIONS
1. READ these instructions.
2. KEEP these instructions.
3. HEED all warnings.
4. FOLLOW all instructions.
5. DO NOT use this apparatus near water.
6. CLEAN ONLY with dry cloth.
7. DO NOT block any ventilation openings. Install in accordance with the ma\
nufacturer's instructions.
8. DO NOT install near any heat sources such as radiators, heat registers, stoves,\
or otherapparatus (including amplifiers) that produce heat.
9 . DO NOT defeat the safety purpose of the polarized or grounding type plug. A polarized plug has two blades with one wider
than the other. A grounding type plug has two blades and a t hird grounding prong. The wider blade or the third prong are
provided for your safety. If the provided plug does not fit into your outlet, consult an electrician for replacement of the
obsolete outlet.
10. PROTECT the power cord from being walked on or pinched, particularly at \
plugs, convenience receptacles, and thepoint where they exit from the apparatus.
11. ONLY USE attachments/accessories specified by the manufacturer.
12. USE only with a cart, stand, tripod, bracket, or table specified by the \
manufacturer, or sold with the apparatus. When a cart is used, use caution when moving the cart/apparatus combinat\
ion to avoid injur y from tip-over.
13. UNPLUG this apparatus during lightning sto ms or when unused for long periods of time.
14. REFER all servicing to qualified service personnel. Servicing is required when the apparatus has been damaged in any way, such as power-supply cord or plug is damaged, liquid has been spilled \
or objects have fallen into the apparatus,
the apparatus has been exposed to rain or moisture, does not operate nor\
mally, or has been dropped.
This symbol indicates that there are important operating and maintenance\
instructions in the literature accom-
panying this unit.
This symbol indicates that dangerous voltage constituting a risk of elec\
tric shock is present within this unit.
W
W ARNING: To reduce the risk of fire or electrical shock, do not expose this appara\
tus
to rain or moisture.
CAUTION: Changes or modifications not expressly approved by the manufacturer coul\
d void the users authority to operate
this device.
POSITIONING YOUR SYNERGY SERIES SPEAKERS
Before You Start - Some Klipsch speakers have feet and other accessories that\
may need to be installed prior to use.
Please refer to Diagrams 1, 2, 3, 4 and 5 for installation.
Left and Right Main Channel Speakers - For optimum performance, Klips\
ch suggests placing your speakers six to 15
feet (2 to 4.5m) apart and at least 24 inches (60.8cm) from the back\
and side walls. They may also be toed-in
slightly for better stereo imaging. The listening position should be abo\
ut 1 to 1.5 times the distance separating the
speakers. Refer to Figures 1, 2 and 4 for connection and placement.
Center Channel Speakers - Center channel speakers are designed to pla\
ce dialogue and primar y sounds so that they
appear to come from the video screen. The speakers should therefore be p\
laced as close to the screen as possible,
preferably directly on top of or below the screen. Refer to Figures 2, 3\
and 4 for connection and placement.
Rear Surround Channel Speakers - Klipsch WDST-„¢ surround speakers s\
hould be placed on the walls directly adja-
cent to or on the wall behind the listening position. They are designed \
to recreate the sense of space and ambience
that many of todays surround sound technologies provide. Refer to Di\
agram 5 and Figures 2 and 4 for connection
and placement.
CONNECTING YOUR SYNERGY SERIES SPEAKERS TO YOUR AMPLIFIER
Conventional Connection - Using 16-gauge or larger speaker wire, connect the RED "positive" (+) te minal of the
LEFT speaker to the RED "positive" (+) terminal of your amplifiers\
LEFT channel. Connect the BLACK "negative"
(-“) terminal of the LEFT speaker to the BLACK "negative" (-“) te minal of your amplifiers LEFT channel. Repeat
this procedure for connecting all remaining speakers to the appropriate \
amplifier channels. Refer to Figure 4. Make
sure that no bare wires from any of the connections touch any other term\
inals as this could cause a short and dam-
age your equipment.
Amplifier Requirements - Klipsch speakers are highly efficient and will operate easily on a wide \
variety of ampli-
fiers. All Klipsch speakers are 8-ohm compatible and can be driven to ve\
ry high levels with low distortion. Due to the
high output levels Klipsch speakers are capable of reproducing, exercise\
caution with the volume control. Excessive
volume over long periods can permanently damage your hearing. Overdrivin\
g your amplifier could also damage your
speakers. Check with your dealer to make sure your particular amplifier \
is best suited to your application. We want
you listening for a lifetime.
CARE AND CLEANING OF YOUR SYNERGY SERIES SPEAKERS
The only thing you should ever need to do to your speakers is dust them \
occasionally. Never apply any abrasive or solvent-
based cleaner or any harsh detergent. You can clean the grilles with the brush attachment of a vacuum cleaner.
