IMPORTANT SAFETY INSTRUCTIONS
1. READ these instructions.
2. KEEP these instructions.3.
HEED all warnings.
4. FOLLOW all instructions.
5. DO NOT use this apparatus near water.
6. CLEAN ONLY with dry cloth.
7.
DO NOT block any ventilation openings. Install in accordance with the manufacturer's instructions.
8. DO NOT install near any heat sources such as radiators, heat registers, stoves, or other
apparatus (including amplifiers) that produce heat.
9. DO NOT defeat the safety purpose of the polarized or grounding type plug. A polarized plug has two
blades with one wider than the other. A grounding type plug has two blades and a third grounding
prong. The wider blade or the third prong are provided for your safety. If the provided plug does not fit
into your outlet, consult an electrician for replacement of the obsolete outlet.
10.PROTECT the power cord from being walked on or pinched, particularly at plugs, convenience
receptacles, and the point where it exits from the apparatus.
11.
ONLY USE attachments/accessories specified by the manufacturer.
12. USE only with a cart, stand, tripod, bracket, or table specified by the manufacturer, or sold with the
apparatus. When a cart is used, use caution when moving the cart/apparatus combination toavoid injury from tip over.
13. UNPLUG this apparatus during lightning storms or when unused for long periods of time.
14.REFER all servicing to qualified service personnel.Servicing is required when the apparatus has
been damaged in any way, such as power supply cord or plug is damaged, liquid has been spilled
or objects have fallen into the apparatus, the apparatus has been exposed to rain or moisture, does
not operate normally, or has been dropped.
This symbol indicates that there are important operating and maintenance instructions in the
literature accompanying this unit.
This symbol indicates that dangerous voltage constituting a risk of electric shock is present
within this unit.
WARNING: To reduce the risk of fire or electrical shock, do not expose this apparatus to rain or
moisture. The product must not be exposed to dripping and splashing and no object filled with fluids -
such as a vase of flowers - should be placed on the product.
WARNING : Voltages in this equipment are hazardous to life. There are no user serviceable parts inside.
Refer all servicing to qualified service personnel.
CAUTION: Changes or modifications not expressly approved by the manufacturer could void the users
authority to operate this device.
POSITIONING YOUR SYNERGY SERIES SUBWOOFER
Klipsch powered subwoofers are designed to reproduce deep bass and deliver the impact that
makes your movies and music come alive. For optimum performance, place your subwoofer in a
corner of the room on the same wall as your front channel speakers. (refer to Figures 1 and 2).
Please note that room placement can have a dramatic effect upon the performance of your
powered subwoofer. Corner placement, as suggested above, will increase the amount of bass
output, while placing the subwoofer along the middle of a wall, or out in the room will decrease the
amount of bass output.Experiment with a number of different placement options and control
settings to find the one that best suits your particular room and taste. When choosing your
subwoofers location, keep in mind that you will need to connect the subwoofers built in amplifier
to an AC power outlet.
CONNECTIONS AND CONTROLS
Optimal Connections - Klipsch Synergy Powered subwoofers can be connected to the subwoofer
output of your electronics via the RCA jack inputs (LINE IN) on the subwoofers rear panel (refer
to Figure 3).This can be in place of the conventional speaker wire connections (HIGHLEVEL IN).
For more information on the controls mentioned in this manual and on bass management, see
your dealer or visit www.klipsch.com.Conventional Speaker Wire Connections - Using 16 gauge or larger speaker wire, connect the
RED positive (+) terminal of your amplifiers LEFT channel to the RED (+) terminal of your
subwoofers LEFT channel input (HIGH LEVEL IN). Connect the BLACK negative ( ) terminal of
your amplifiers LEFT channel to the BLACK negative ( ) terminal of your subwoofers LEFT
channel input (HIGH LEVEL IN). Repeat this procedure for connecting your amplifiers RIGHT
channel to your subwoofers RIGHT channel input (refer to Figure 4). Take care to make sure that
no bare wires from any of the connections touch any other terminals as this could cause a short
and damage your equipment.
HIGH
LEVEL OUT - This passes the HIGH LEVEL IN signal out to your left and right speakers
with frequencies below 100Hz removed.
LINE IN/LFE
- This input is filtered by the built in LOW PASS (LP) crossover and is designed as
a general purpose input f
or the subwoofer. It accepts the LFE signal output of your digital
surround electronics.
LOW P
ASS (LP) CROSSOVER - The crossover allows the user to select the upper frequency
cutoff of the subwoofer
. The frequency is selectable from 40 120Hz. Frequencies above the set
level are filtered out,
allowing you to blend the subwoofers output with that of your main speakers.
GAIN
- This control serves as an overall volume control for the subwoofer. It is used to match the
output level of the subwoofer to the main speakers.
PHASE 0/180 - This control is used to acoustically match the subwoofers output to your main
speakers. Select the position, either 0Λ or 180Λ, in which your subwoofer has more output at the
listening position.
POWER ON/OFF- In the ON position, the subwoofer will remain on constantly or can turn
on and off automatically when the AUTO/ON circuit is engaged (see AUTO/ON). In the
OFF position, the subwoofer will remain off until the switch is manually turned back to the
ENGLISH
RISK OF ELECTRIC SHOCK
DONOT OPEN
Page 2
1 800 KLIPSCH to confirm that you have an unaltered serial number and/or you purchased from a
KLIPSCH authorized dealer.
This Warranty is only valid for the original purchaser and will automatically terminate prior to
expiration if this product is sold or otherwise transferred to another party.
This Warranty does not cover cosmetic damage or damage due to misuse, abuse, negligence,
acts of God, accident, commercial use or modification of, or to any part of, the product. This
Warranty does not cover damage due to improper operation, maintenance or installation, or
attempted repair by anyone other than KLIPSCH or a KLIPSCH dealer which is authorized to do
KLIPSCH warranty work. Any unauthorized repairs will void this Warranty. This Warranty does not
cover product sold AS IS or WITH ALL FAULTS.
REPAIRS OR REPLACEMENTS AS PROVIDED UNDER THIS WARRANTY ARE THE EXCLUSIVE
REMEDY OF THE CONSUMER. KLIPSCH SHALL NOT BE LIABLE FOR ANY INCIDENTAL ORCONSEQUENTIAL DAMAGES FOR BREACH OF
ANY EXPRESS OR IMPLIED WARRANTY ON THIS
PRODUCT. EXCEPT TO THE EXTENT PROHIBITED BY LAW, THIS WARRANTY IS EXCLUSIVE AND IN
LIEU OF ALL OTHER EXPRESS AND IMPLIED WARRANTIES WHATSOEVER, INCLUDING BUT NOT
LIMITED TO, THE WARRANTY OF MERCHANTABILITY AND FITNESS FOR A PRACTICAL PURPOSE.
Some states do not allow the exclusion or limitation of incidental or consequential damages
or implied warranties so the above exclusions may not apply to you. This Warranty gives you
specific legal rights, and you may have other rights, which vary from state to state.
WARRANTY OUTSIDE THE UNITED STATES AND CANADA
The Warranty on this product if it is sold to a consumer outside of the United States or Canada
shall comply with applicable law and shall be the sole responsibility of the distributor that
supplied this product. To obtain any applicable warranty service, please contact the dealer from
which you purchased this product, or the distributor that supplied this product.
FIGURE 2
STEREO PLACEMENT SURROUNDLCR AND REARS
FIGURE 1 Sub
Angle Inward
*Less distance will increase bass,
but worsen sound quality.S+Optional
SubS+ Optional
SubS 6' 15'SS
LRCTVY
X
Z+Optional
SubS+ Optional
Sub SubX=Y=ZAlternate
rear placementAA
BB
