1. READ these instructions.
2. KEEP these instructions.
3. HEED all warnings.
4. FOLLOW all instructions.
5. DO NOT use this apparatus near water.
6. CLEAN ONLY with dry cloth.
7. DO NOT block any ventilation openings. Install in
accordance with the manufacturers instructions.
8. DO NOT install near any heat sources such as ra -
diators, heat registers, stoves, or other apparatus
(including amplifiers) that produce heat.
9. ONLY USE attachments/accessories specified by
the manufacturer.
10. USE only with a cart, stand, tripod, bracket, or
table specified by the manufacturer, or
sold with the apparatus. When a cart
is used, use caution when moving the
cart/apparatus combination to avoid
injury from tip-over.
11. UNPLUG this apparatus during lightning storms
or when unused for long periods of time.
12. REFER all servicing to qualified service person -
nel. Servicing is required when the apparatus
has been damaged in any way, such as power-
supply cord or plug is damaged, liquid has been
spilled or objects have fallen into the apparatus,
the apparatus has been exposed to rain or
moisture, does not operate normally, or has
been dropped.
Important Safety Instructions
General Cautions
This symbol indicates that there are
important operating and maintenance
instructions in the literature accompany-
ing this unit.
This symbol indicates that dangerous
voltage constituting a risk of electric
shock is present within this unit.
WARNING: To reduce the risk of fire or
electrical shock, do not expose this ap -
paratus to rain or moisture.
WARNING: Voltages in this equipment are hazard-
ous to life.
No user-serviceable parts inside. Refer all servicing to
qualified service personnel.
CAUTION: Changes or modifications not expressly
approved by the manufacturer could void the users
authority to operate.
CAUTION!
Risk of electRic shock do not open
- When making or changing any connections to
your system, switch all the electronics OFF.
-
Do NOT listen to music for long periods at
extreme volume settings. Doing so can perma-
nently damage your hearing.
-
When running loudspeaker cables, do not trail
them over open floor spaces where they could
cause an accident. Cover them or route them
around potential troublespots.
-
Before switching on your sound system, turn
the volume level down. After switching the
system on, turn the level up gradually.
-
Do not use extreme settings of Treble, Bass or
EQ. Ideally set the tone controls flat and turn
any EQ off. -
These loudspeakers are extremely heavy. Do not
move them by yourself. Always get help.
If you are using the floor spikes:
-
Spikes are sharp! Exercise extreme caution when
using spikes.
-
Do not drag the loudspeaker. Lift the speakers
off the floor and set them down carefully when
changing their location.
-
Be especially careful not to place a spiked
loudspeaker in areas where there may be hidden
obstacles that could get damaged.
-
Some floor surfaces can be damaged by spikes.
If you are unsure, consult your flooring contrac-
tor for advice before using spikes, or use the
spike seats.
Introduction
For over 60 years, our engineers have sought the ultimate: a loudspeaker that could reproduce recorded music
with all the passion of a live performance. The Palladium-„¢ Series approaches aural perfection, while making a
visual statement that is every bit as elegant and passionate as the sound.
The Palladium Series represents the epitome of loudspeaker technology, with remarkable clarity throughout
the dynamic range and bold styling. Today, Klipsch Group, Inc. is a global force, and this loudspeaker range
reflects that leadership status; design and engineering teams from the United States collaborated with col -
leagues from Germany and China to plan and execute the Palladium project.
In designing the Palladium cabinetry, we first considered the Klipsch heritage and unique approach to acoustic
design. Trends in home interior and furniture were also factored in, as was the current audio market landscape.
The result is a speaker range that flawlessly melds classic Klipsch® audio with
the latest in home furniture trends. The striking design hints at the power
and performance inside, while maintaining a high degree of sophistication
and beauty. More importantly, the arched shape of the loudspeaker actu -
ally contributes to its remarkable sound by breaking up standing waves at
higher frequencies.
Power. Detail. Emotion. Combined, these qualities are the embodiment of
our core philosophy. And all are expressed-beautifully-in the brilliant
Palladium loudspeakers. We invite you, our customer, to share with us the
pride of ownership in this extraordinary product for many gratifying years.
Page 2
Page 4 Page 5
Preparing the Loudspeaker
Getting Started
Unpacking (P-38F / P-37F)
Please follow the unpacking instructions fully and in the order shown below. These loudspeakers are
heavy! Do not lift or move these speakers by yourself. Always have someone help you.
1
3
5 4 2 Open the carton flaps
Lightly tape each flap to the box
with short pieces of tape
Remove the top packing piece
Carefully invert the carton Lift off the carton
Lift off the center and base packing pieces
The loudspeaker is
ready for connection
- The grille box contains: one upper grille; one lower grille, (P-38F / P-37F) or one single-piece grille
(P-17B, P-27C and P-27S).
- The Accessories box for P-38F and P-37F contain: four long spikes; four short spikes; four spike col-
lars; four spike seats; one Allen wrench.
- The Accessories box for P-27C contains: two short front spikes; one short-barrel rear spike; one
long-barrel rear spike; three spike collars; three spike seats; one Allen wrench.
- The P-17B and P-27S do not have an accessory box , but do include an Allen wrench with the
owners manual packet.
- There is a pair of gloves located in a pocket in the side of the packing carton under the owners manual.
Identify all the components. If any item is missing or damaged, report this immediately to your Klipsch
dealer and the transport contractor for action.
Connection Procedure:
There is a specific procedure to be followed:
- Switch off and unplug the amplifier/s and all source electronics from the mains power.
- Place both loudspeakers in the general area where you want them.
- Connect each loudspeaker following the instructions under the connecting the loudspeakers section of
this manual.
- Attach the spikes, following the instructions under the finalizing the assembly section of this manual.
- Run both sets of loudspeaker cables to the amplifier.
- Connect the amplifier.
- Finalize the position of the loudspeakers.
- Finally, fit the grilles (if desired).
TAKE CARE NOT TO TOUCH THE DRIVE UNITS WHEN YOU MOVE THE LOUDSPEAKERS AROUND.
TO PRESERVE THE FINISH, WHEN HANDLING YOUR SPEAKERS, USE THE GLOVES THAT ARE PROVIDED.
Fitting and Removing the Grilles
The grilles are magnetically attached to the cabinet. Specially designed magnets
are housed inside the front wall of the loudspeaker, so that if you wish to operate
the loudspeaker with the grilles removed, no grille mounting hardware is visible.
This preserves the smooth lines of the loudspeaker.
To fit the grilles: Fit the top grille first and line it up with the top and sides of the
cabinet. For the P-38F, P-37F and P-17B there is a small lip on the top of the grille
that should rest on the top of the cabinet. Now, fit the lower grille, lining up the
top of the lower grille with the bottom of the upper grille. You may now remove
the top grille if you wish. ( The P-17B, P-27C and P-27S have a single one-piece
grille only.)
Although operating the loudspeakers with the grilles on or off is a matter
of personal taste, moving or connecting the loudspeakers should always be done
with the grilles removed. Be especially careful not to touch the drive units.
Whats in the box?
Remove the Grille box
Remove the Accessories box
Remove the Owners manual
and gloves
