Page 1
Installation Manual
Applicable for the Installation and assembly of the following products:
Screen Systems
KPT-MCM Grand
KPT-Jubilee® Stage System
KPT-941-T (THX® -“ Approved)
KPT-941
KPT-535
KPT-904
KPT-325
Surround Systems
KPT-250
KPT-200 (THX® -“ Approved)
KPT-100 (THX® -“ Approved)
KPT-110
SU B W O O F E R S
KPT-684 (THX® -“ Approved)
KPT-484
Klipsch Professional Theater Speaker Systems
Page 2
Welcome to the Klipsch line of Professional Theater Speaker Systems!
Since the earliest days of amplified sound systems, Klipsch has utilized the
latest concepts in loudspeaker design, surpassing the expectations of
concurrent fidelity. Today, by combining our design excellence with a solid
tradition of sonic reproduction quality, Klipsch provides a comprehensiv e
family of professional theater speakers, ranging from compact systems perfect
for small auditoriums, mixing suites and viewing rooms, to large four-way
horn-loaded systems applicable for installation in the largest cinema venues.
In Klipsch designs, you will find technical updates on traditional high quality
cinema sound systems, taking into consideration the digital sound sources of
today. Thanks to the Klipsch Tractrix® Horns used on high frequency and
mid-bass components, the Klipsch Professional Theater Speaker Systems offer
wider dynamics, controlled coverage, smoother power transfer functions, lower
distortion and superior efficiency, all in a broad range of available systems.
Included in the following pages are installation instructions for the Klipsch
family of professional theater sound products. If you have any questions or
need more information, please contact Klipsch directly at 1-800-KLIPSCH.
Our technical support staff will be happy to assist you.
Sincerely
