Klipsch CS 500 Owners Manual

This is the 32 pages manual for Klipsch CS 500 Owners Manual.
Read or download the pdf for free. If you want to contribute, please mail your pdfs to info@audioservicemanuals.com.

Page: 1 / 32
left right
Klipsch CS 500 Owners Manual

Extracted text from Klipsch CS 500 Owners Manual (Ocr-read)


Page 1

Chapter 1: Connecting Your System Reading this Manual ......................................................................1 Step-by-Step Connections .............................................................1 Step 1: Unpack the box ..................................................................2 Step 2: Put the batteries in the remote control .............................2 Step 3A : Set-top box connection ...................................................3 Step 3B: T V audio connection ........................................................4 Step 4: Connect Klipsch System to the T V's Input .........................5 Step 5: Connect the speakers ........................................................6 Speaker Setup Considerations ................................................6 Step 6 : Connect other components (OPTIONAL) ...........................7 Step 7: Connect AM and FM antennas ...........................................8 Step 8: Turn on the T V and the Klipsch system ..............................8 Step 9: Complete the on-screen setup ..........................................9 Your Klipsch Controller .................................................................11 Buttons .................................................................................11 Display ..................................................................................11 The basics ................................................................................... 12 Switching between media .................................................... 12 Chapter 2: Remote Control Buttons ........................................................................................ 13 Programming your remote control ............................................... 14 Chapter 3: Operation Compatible discs ........................................................................ 15 Incompatible discs ...................................................................... 15 Regional coding ........................................................................... 15 Playing a disc .............................................................................. 15 DVD and VCD playback.................................................................16 Transpor t ...............................................................................16 Navigating info banners ...............................................................17 Playing CDs ................................................................................. 18 Playing CDs with mp3 or JPEG files ............................................. 18 Playing content from a USB drive ................................................ 18 Listening to the tuner .................................................................. 19 Setting tuner presets ........................................................... 19 Chapter 4: Menu System On screen menu system .............................................................. 20 Navigating menus ........................................................................ 20 On-screen menus .........................................................................21 Audio .....................................................................................21 Setup ....................................................................................21 Languages .............................................................................21 Parental control ................................................................... 22 Remote control .................................................................... 22 Chapter 5: Troubleshooting General problems ................................................................. 23 Video problems .................................................................... 23 Audio problems .................................................................... 23 Remote control problems ..................................................... 23 Playback problems ............................................................... 23 Radio problems .................................................................... 23 Chapter 6: Care and Maintenance Klipsch System..................................................................... 24 Cleaning ............................................................................... 24 Handling and Caring for Discs .............................................. 24 Remote Control Codes ......................................................... 25 Warranty ............................................................................... 27 FCC Information ................................................................... 27 Appendix I Connection Over view ................................................................... 28 Input jacks ........................................................................... 28 Output jacks ......................................................................... 28 Audio connection options .................................................... 28 Video connection options .................................................... 28 Table of Contents

Page 2

CAUTION : Place the equipment near a main power supply outlet and make sure that you can easily access the power breaker switch. WARNING: This product is intended to be operated ONLY from the AC Voltages listed on the back panel or included power supply of the product. Operation from voltages other than those indicated may cause irreversible damage to the product and void the product's warranty. The use of AC Plug Adapters is cautioned because it can allow the product to be plugged into voltages in which the product was not designed to operate. If the product is equipped with a detachable power cord, use only the type provided with your product or by your local distributor and /or retailer. If you are unsure of the correct operational voltage, please contact your local distributor and /or retailer. NOTE: If a DVD is present, the following laser safety statement applies: L ASER SAFET Y: This unit employs a laser. Due to possible eye injury, only a qualified service person should remove the cover or attempt to service this device. CAUTION : Use of controls or adjustments or performance of procedures other than those specified herein may result in hazardous radiation exposure. This device is protected by U.S. patent numbers 4,631,603 and 4,577,216 and 4,819,098 and 4,907,093 and other intellectual property rights. DVD Safety Information This DVD player is designed and manufactured to respond to the Region Management Information. If the region number of a DVD disc does not correspond to the region number of this DVD player, this player cannot play the disc. The region number for this DVD player is Region No 1. DVD Copy Protection In accordance with the DVD standard, your DVD player is equipped with a Copy Protection System, which can be switched on and off by the DVD disc itself, in order to make any recording of the relevant DVD disc onto a videotape of very poor picture quality, or even impossible. This product incorporates copyright protection technology that is protected by method claims of certain U.S. patents and other intellectual property rights owned by Macrovision Corporation and other rights owners. Use of this copyright protection technology must be authorized by Macrovision Corporation, and is intended for home use only unless otherwise authorized by Macrovision Corporation. Reverse engineering or disassembly is prohibited. This DVD player does not play discs that are pirated. The unauthorized use and recording of copyright and patented material is considered piracy. Important Safety Information For Your Safety: The AC power plug is polarized (one blade is wider than the other) and only fits into an AC power outlet one way. If the plug wont go into the outlet completely, turn the plug over and try to insert it the other way. If it still wont fit, contact a qualified electrician to change the outlet, or use a different one. Do not attempt to bypass this safety feature. WARNING RISK OF ELECTRIC SHOCK. DO NOT OPEN. WARNING : Do Not Open! Risk of Electrical Shock. Voltages in this equipment are hazardous to life. No user-serviceable parts inside. Refer all servicing to qualified service personnel. The exclamation point, within an equilateral triangle, is intended to alert the user to the presence of important operating and maintenance (servicing) instructions in the literature accompanying the product. The lightning flash with arrowhead symbol within an equilateral triangle, is intended to alert the user to the presence of uninsulated dangerous voltage within the products enclosure that may be of sufficient magnitude to constitute a risk of electrical shock to persons. WARNING: To reduce the risk of fire or electrical shock, do not expose this apparatus to rain or moisture. WARNING: Batteries (battery pack or batteries installed) shall not be exposed to excessive heat such as sunshine, re or the like. WARNING: No naked ame sources -“ such as candles -“ should be placed on the product. READ these instructions. KEEP these instructions. HEED all warnings. FOLLOW all instructions. DO NOT use this apparatus near water. CLEAN ONLY with dry cloth. DO NOT block any ventilation openings. Install in accordance with the manufacturers instructions. DO NOT install near any heat sources such as radiators, heat registers, stoves, or other apparatus (including ampli ers) that produce heat. DO NOT defeat the safety purpose of the polarized or grounding type plug. A polarized plug has two blades with one wider than the other. A grounding type plug has two blades and a third grounding prong. The w ider blade or the third prong is provided for your safety. If the provided plug does not t into your outlet, consult an electrician for replacement of the obsolete outlet. PROTECT the power cord from being walked on or pinched, particularly at plugs, convenience receptacles, and the point where they exit from the apparatus. ONLY USE attachments /accessories speci ed by the manufacturer. USE only with a cart, stand, tripod, bracket, or table speci ed by the manufacturer, or sold with the apparatus. When a cart is used, use caution when moving the cart /apparatus combination to avoid injury from tip-over. UNPLUG this apparatus during lightning storms or when unused for long periods of time. REFER all servicing to quali ed service personnel. Servicing is required when the apparatus has been damaged in any way, such as power-supply cord or plug is damaged, liquid has been spilled, objects have fallen into the apparatus, the apparatus has been exposed to rain or moisture, does not operate normally, or has been dropped. 1. 2. 3. 4. 5. 6. 7. 8. 9. 10. 11. 12. 13 . 14 . DO NOT expose this apparatus to dripping or splashing and ensure that no objects lled with liquids, such as vases, are placed on the apparatus. To completely disconnect this apparatus from the AC Mains, disconnect the power supply cord plug from the AC receptacle. The mains plug of the power supply cord shall remain readily operable. 15. 16. 17. INDEX page i/ii
