ARCHITECTURAL SPEAKERS
IMPORTANT SAFETY INSTRUCTIONS1. READ these instructions.
2. KEEP these instructions.
3. HEED all warnings.
4. FOLLOW all instructions.
5. DO NOT use this apparatus near water.
6. CLEAN ONLY with dry cloth.
7. DO NOT block any ventilation openings. Install in accordance
with the manufacturer's instructions.
8. Do NOT install near any heat sources such as radiators, heat
registers, stoves, or other apparatus (including amplifiers) that
produce heat.
9. DO NOT defeat the safety purpose of the polarized or grounding
type plug. A polarized plug has two blades with one wider than
the other. A grounding type plug has two blades and a third
grounding prong. The wider blade or the third prong are provided
for your safety. If the provided plug does not fit into your outlet,
consult an electrician for replacement of the obsolete outlet.
10. PROTECT the power cord from being walked on or pinched,
particularly at plugs, convenience receptacles, and the point
where they exit from the apparatus.
11. ONLY USE attachments/accessories specified by the
manufacturer.
12. USE only with a cart, stand, tripod, bracket, or table specified
by the manufacturer, or sold with the apparatus.
When a cart is used, use caution when moving
the cart/apparatus combination to avoid injury
from tip over.
13. UNPLUG this apparatus during lightning storms or when unused
for long periods of time.
14. REFER all servicing to qualified service personnel. Servicing is
required when the apparatus has been damaged in any way,
such as power supply cord or plug is damaged, liquid has been
spilled or objects have fallen into the apparatus, the apparatus
has been exposed to rain or moisture, does not operate
normally, or has been dropped.
This symbol indicates that there are important
operating and maintenance instructions in the
literature accompanying this unit.
This symbol indicates that dangerous voltage
constituting a risk of electric shock is present withinthis unit.
WARNING : To reduce the risk of fire or electrical shock, do not
expose this apparatus to rain or moisture.
WARNING : Voltages in this equipment are hazardous to life. No
user serviceable parts inside. Refer all servicing to qualified
service personnel.
CAUTION : Changes or modifications not expressly approved by the
manufacturer could void the users authority to operate this device.
ABOUT YOUR KLIPSCH PURCHASEYour new Klipsch architectural speakers have been designed to
deliver great sound while remaining unobtrusive wherever you
install them. For optimum performance, please use the models
ending with a W for in wall installations. Models ending in C
should be used for in ceiling applications. Either type is suitable
for use as front, center or surround channels in audio or home
theater applications, or as part of a distributed sound system.
Minimum Tools Required
#2 Phillips Screwdriver
Wire strippersLevelStud finderSaw
IN WALL SPEAKER PLACEMENTDesigned to function in any standard wall, ceiling or drop ceiling,
Klipsch in wall speakers are engineered for years of perform
ance. Minimum construction requirements call for drywall or
other mounting surfaces to be at least 3/8" thick (figure1).
To maximize performance, speakers should be placed at an
equal distance from the listener and along a common wall
to ensure the best stereo effect. For background listening
environments (or when the listening position may vary widely),
speaker placement may be wherever is most convenient,
although in these cases stereo imaging may be lost.
IN CEILING SPEAKER PLACEMENTDesigned to function in any drywall or drop ceiling, Klipsch in
ceiling speakers are engineered for years of performance.
Minimum construction requirements call for drywall or other
mounting surfaces to be at least 3/8" thick. In drop ceiling
installations, typical "drop in" 2 x 4 and 2 x 2 ceiling tiles are
composed of low density materials which have the potential over
time to sag and vibrate audibly. To maximize the acoustic per
formance of your in ceiling speakers, Klipsch recommends you
replace the original mounting panel with 1/2" to 3/4" plywood ormedium density fiberboard (MDF) (figure 2).
English
Figure 1
Page 2
SPEAKER INSTALLATION (for New Construction, skip to step #3)
1. Cut the appropriate size opening in the wall or ceiling using
the template provided. If the template is not available, cutout dimensions are provided on the Klipsch website,
www.klipsch.com. Sizes listed are minimum. If accuracy of cut
cannot be achieved, you may add 1/4" to each dimension. Be
careful not to cut through any existing wiring or plumbing.
Avoid compromising any fire stops between studs.
2. Run speaker wiring (18 gauge minimum) to the openings. Be
sure to comply with all building codes in your area.
3. Attach the wire to the speaker using the wires color coding or
markings as a guide to maintain proper polarity.
4. Insert the speaker assembly into the opening and attach by
tightening the four Phillips screws (figure 3). The frames
dog legs will swivel out and sandwich the wall and frame
together. (Klipsch new construction brackets make this simple
if used prior to drywall installation.)
5. At this point, you may paint the speaker grilles before
inserting them into the speakers. Klipsch grilles are designed
to accept most types of paint. You may wish to remove the
scrim material before painting. It may be reinserted after the
paint is dry. Care should be taken to avoid excessive paint
build up in the grille perforations.
6. Press the grille into place.
See back page for more illustrations.
OPERATING CONTROLSMid Bass and Tweeter Attenuator Switch
(3000 and 5000 Series)
Some models feature a Tweeter switch (3000 series) or both a
Mid Bass and a Tweeter switch (5000 series) located on the
front baffle. The switch allows a setting of either 0dB (normal) or
-“3dB in the respective frequency range. If installing in an
acoustically bright room, such as a bathroom or kitchen, you
may want to adjust the Tweeter level switch. If the speaker is
located in a corner and produces too much bass, you may need
to adjust the Mid Bass level switch. The position of the switch
should always be checked prior to attaching the grille.
Pivoting Horn (In Wall Models)
The 3000 and 5000 series feature a pivoting horn that allows
the horn to be toed in. Before the grille is installed, carefully aimthe horn toward the listening area.
Swiveling Horn Tweeter (In Ceiling Models)
Klipsch Reference in ceiling models (3000 and 5000 Series)
feature a swiveling tweeter to aim the high frequencies. To aim
sound directly at the listening area, gently adjust the horn to the
desired angle before the grille is installed.
Do not attempt to turn the tweeter stem while adjusting the
swivel tweeter.
Infrared Sensor Mount
(In Wall Models)
All Reference model in wall speakers feature a 1/2 infrared
sensor locator on the baffle.
WARRANTY-“U.S. AND CANADA ONLYThe Warranty below is valid only for sales to consumers in the
United States or Canada.
Figure 2
Figure 3
