Extracted text from Kenwood TS 530 SP Owners Manual (Ocr-read)
Page 1
AFTER UNPACKING
Save the original boxes packing in the event your unit WARNING:
needs to be transported for remote operation, mainten- Personal injury may occur - do not disregard. ance, or service.
The following explicit definitions apply in this manual. Be CAUTIoN:
.@__-
sure to read these definitions:
NOTE:
lf disregarded, inconvenience only - no damage or person- WARNINC alinjury.
Read Operating Manual Section 4. before placing trd|3rnrner ,n
servrce.
HIGH VOLTAGES PRESENT.
CAUTION:
Equipment damage may occur. but not personal injury.
SPEC|FICAT|ONS........... 3 4.3 Transmission (t)
SECTION 1. INTRODUCTION AND FEATURES........ 4 (1) SSB Operation
SECTfON 2. f NSTALIAT|ON........... 5 4.4 Transmission (il)
2.1 Unpacking (1) Speech processor
2.2 Operating Location (2) VOX (Voice Operated Transmit) Operatron 2.3 Cabling (3) XIT (Transmitter Incremental Tuning) 2.4 Microphone (4) CW Operation
2.5 Key 4.5 Digital Display Calibration
2.6 External speaker and Headphones 4.6 Analog Dial calibration
2.7 Ground sEcrtoN 5. oprtoNAL AccEssoRtEs............ ....... 20 2.8 Antenna 5.1 Optional Accessories
SECTION 3. CONTROLS AND THEIR FUNCTIONS. 8 5.2 Installation of Accessories
3.1 FrontPanel SECTION6. MAINTENANcEANDALIGNMENT....2S
3.2 Rear Panel 6.1 General
SECTION 4. OPERATION ............. ......... 14 6.2 Service Position
4.1 Reception (l) 6.3 Receiver Adjustments (1) Basic Procedures for Receive Operation 6.4 Transmitter Adjustments
(2) WWV Reception 6.5 Transmitting on WARC BANDS
4.2 Reception(ll) 6.6 Operation on22OY ACoT24OVAC(USA)
(1) NOTCH CONTROL SECTTON 7. TROUELESHOOTTNG ........ 28 (2) RFATTSwitch BLOCKDIAGRAM... ...........29
(3) RFGainControl |NTERNALV|EW............. ........................ 30 (4) AGC (Automatic Gain Control) SCHEMATIC DIAGRAM ........................ 31 (5) RrT/XrT
(6) rF Shift
(7) NARROW Switch
(8) Noise Blanker (NB)
CONTENTS
el
Page 2
TS-53O SPECIFICATIONS
[GENERAL]
Frequency Range.......... 160 m Band 1.8 '- 2.0 MHz
8O m Band 3.5 - 4.0 MHz
40 m Band 7.0 - 7.3 MHz
30 m Band 10.1 - 10.1 5 MHz
(1O.0 MHzWWV)
20 m Band 14.O - 14.35 MHz
17 m Band 18.068 - 18.168 MHz
1 5 m Band 21 .O - 21 .45 MHz
12 m Band 24.89 - 24.99 MHz
1O m Band 28.O - 29.7 MHz
SSB/CW
Within 'l kHz during the first hour after 1 minute of warmup.
Within 100 Hz during any 30 minute period thereafter.
1 1 0VAC/1 20VAC|240VAC, 50/60 Hz
Transmit: 295 watts
Receive: 27 watts (with heaters off)
333 (13.3)x 133 (5.3)x 333 (13.3) mm (inch)
12.8 kg (28.2 lbs)
Modes.........
Frequency Stability ......
Power Requirement ...................
Power Consumption ..................
Dimensions
Weight........
[TRANSMITTER]
* FinalPower Input.........
Audio Input lmpedance ............
RF Output lmpedance..
Carrier Suppression
Sideband Suppression
Spurious Radiation....
Harmonic Radiation
Audio Freq. Response..............
ALC Input
Linear Amp Relay Contact Ratin9..........
IRECETVERI
Receiver Sensitivity
lmage Ratio............
lF Rejection
Receiver Selectivity
ssB/cw.....
Notch-filter Attenuation
Audio Output lmpedance
Audio Output
NOTE: The circuit and ratings
technology.
TS-53OD
160W PEP for SSB operation
13OW DC for CW operation
500p - 50 kjz
50Q - 75r/
Better than 40 dB
Better than 50 dB
Better than 60 dB
Better than 40 dB
4OO to 2,600 Hz. within -6 dB
-1OV DC Max
100v Dc 1A
O.25 uV at 10 dB S + N/N
Better than 6O dB
Better than 70 dB
2.4kHz (-6 dB), 4.2kHz (-60 dB)
CW Optional Filter
YK-88C 5OO Hz (-6 dB), 1.5 kHz (-60 dB)
YK-88CN 27O Hz (-6 dB), 1.1 kHz (-60 dB)
SSB Optional Filter
YK-88SN 1.8 kHz (-6 dB),3.3 kHz (-60 dB)
Better than 20 dB (1 .5 kHz)
8 - 16(2
1.5W (8l2)
may be changed without notice due to developments
TS_530SP __
22OW PEP for SSB operation
18OW DC for CW operation
