Extracted text from Kenwood KRFV 5050 D Owners Manual (Ocr-read)
Page 1
2
Preparations
WARNING :
TO PREVENT FIRE OR ELECTRIC SHOCK, DO NOT
EXPOSE THIS APPLIANCE TO RAIN OR MOISTURE.
CAUTION: TO REDUCE THE RISK OF ELECTRIC SHOCK, DO NOT
REMOVE COVER (OR BACK). NO USER-SERVICEABLE PARTS IN-
SIDE, REFER SERVICING TO QUALIFIED SERVICE PERSONNEL.
THE LIGHTNING FLASH WITH ARROWHEAD SYMBOL,
WITHIN AN EQUILATERAL TRIANGLE, IS INTENDED TO
ALERT THE USER TO THE PRESENCE OF UNINSULATED
ÒDANGEROUS VOLTAGEÓ WITHIN THE PRODUCTÕS EN-
CLOSURE THAT MAY BE OF SUFFICIENT MAGNITUDE TO
CONSTITUTE A RISK OF ELECTRIC SHOCK TO PERSONS.
CAUTIONRISK OF ELECTRIC SHOCK
DO NOT OPEN
Unpack the unit carefully and make sure that all accessories are put aside
so they will not be lost.
Examine the unit for any possibility of shipping damage. If your unit is
damaged or fails to operate, notify your dealer immediately. If your unit
was shipped to you directly, notify the shipping company without delay.
Only the consignee (the person or company receiving the unit) can file a
claim against the carrier for shipping damage.
We recommend that you retain the original carton and packing materials
for use should you transport or ship the unit in the future.
Keep this manual handy for future reference.
Before applying the power Caution : Read this page carefully to ensure safe
operation.
Safety precautionsUnpacking
Accessories
FM indoor antenna (1)AM loop antenna (1)
THE EXCLAMATION POINT WITHIN AN EQUILATERAL TRI-
ANGLE IS INTENDED TO ALERT THE USER TO THE PRES-
ENCE OF IMPORTANT OPERATING AND MAINTENANCE
(SERVICING) INSTRUCTIONS IN THE LITERATURE ACCOM-
PANYING THE APPLIANCE.
For KRF-V6050D
Batteries (R6/AA) (2)
Remote control unit (1)
RC-R0616
Units are designed for operation as follows.
Europe and U.K. ............................................... AC 230 V only
Other countries ............................... AC 110-120 / 220 - 240 V
Remote control unit (1)
RC-R0512For KRF-V5050D Batteries (R6/AA) (2)
Microcomputer malfunction
If operation is not possible or an erroneous display appears, even
though all connections have been made properly, reset the microcom-
puter referring to ÒIn case of difficultyÓ.¡
Maintenance of the unit
When the front panel or case becomes dirty, wipe with a soft, dry
cloth. Do not use thinner, benzine, alcohol, etc. for these agents may
cause discoloration.
In regard to contact cleaner
Do not use contact cleaners because it could cause a malfunction.
Be specially careful not to use contact cleaners containing oil, for
they may deform the plastic component.
Page 2
3
Operations
Preparations
Other
Remote Control
Before applying the power
Contents
Before applying the power ................... 2
Safety precautions .............................................. 2
Unpacking.......................................................... 2
How to use this manual ...................................... 4
Special features .................................................. 4
Names and functions of parts ................ 5
Remote control unit (RC-R0616)
(KRF-V6050D) ..................................................... 6
Remote control unit (RC-R0512)
(KRF-V5050D) ..................................................... 7
Setting up the system ......................... 8
Connecting audio components ........................... 9
Connecting video components ......................... 10
Connecting a DVD player (6 channel input) ...... 11
Digital connections ........................................... 12
Connecting to the AV AUX jacks
(KRF-V6050D only) ........................................... 13
Connecting the antennas .................................. 13
Connecting the system control ......................... 14
Connecting the speakers .................................. 15
Preparing the remote control ............................ 17
Preparing for surround sound ............... 18
Speaker settings ............................................... 18
Caution : Read the pages marked carefully to ensure safe operation.
Preparations
Operations
Remote Control
Normal playback .............................. 19
Preparing for playback ...................................... 19
Listening to a source component ..................... 20
Adjusting the sound .......................................... 20
Recording ...................................... 21
Recording audio (analog sources) .................... 21
Recording video ................................................ 22
Recording audio (digital sources) ...................... 22
Listening to radio broadcasts ............... 23
Tuning (non-RDS) radio stations ....................... 23
Using RDS (Radio Data System) ....................... 23
Using the RDS DISP. (Display) key ................... 24
Presetting RDS stations
(RDS AUTO MEMORY) ..................................... 24
Presetting radio stations manually .................... 25
Receiving preset stations .................................. 25
Receiving preset stations in order (P.CALL) ...... 25
Tuning by program type (PTY search) .............. 26
Ambience effects .............................. 27
Surround modes ............................................... 27
Surround play ................................................... 29
DVD 6-channel playback .................................. 30
Convenient functions ........................................ 30
Basic remote control operations for other
components (For KRF-V6050D) ............. 32
Registering setup codes for other
components ...................................................... 32
Operating other components ............................ 32
Setup code chart (KRF-V6050D)
(For RC-R0616) ................................................ 33
DVD player operations (For KRF-V5050D) ........ 34
Cassette deck, CD player & MD recorder
operations (For KRF-V5050D) ........................... 35
Cassette deck, CD player & MD recorder
operations (For KRF-V6050D) ........................... 36
Other components' operations
(For KRF-V6050D) ............................................ 37
Additional Information
Remote Control
Additional
Information In case of difficulty ........................... 38
Specifications ................................. 40
Page 3
4
Preparations
Special features How to use this manual
This manual is divided into four sections, Preparations, Operations,
Remote Control, and Additional Information.
PreparationsShows you how to connect your audio and video components to the
receiver and prepare the surround processor.
We will guide you to make setting up your system as easy as possible.
However, since this receiver works with all of your audio and video
components, connecting the system can be fairly complex.
OperationsShows you how to operate the various functions available from the
receiver.
Remote Control (KRF-V6050D only)Shows you how to operate other components using the remote control,
as well as a detailed explanation of all remote control operations. Once
you have registered your components with the proper setup codes, youÕll
be able to operate both this receiver and your other AV components (TV,
VCR, DVD player, CD player, etc.) using the remote control supplied with
this receiver.
Additional InformationShows you additional information such as ÒIn case of difficultyÓ (trouble-
shooting) and ÒSpecificationsÓ.
Before applying the power
The manual covers the KRF-V6050D and KRF-V5050D. Items such as
functions, number of jacks, and remote control details differ somewhat
between these models. To confirm the functions available on the model
you have purchased, refer to the table below.
Memory back up function
Please note that the following items will be deleted from the unit's
memory if the power cord is disconnected from the AC outlet for
approximately 2 days.
Â¥ Power mode.
Â¥ Input selector settings.
Â¥ Device preset.
Â¥ Picture output.
Â¥ Speaker ON/OFF
Â¥ Volume level.
Â¥ BASS, TREBLE, INPUT level.
Â¥ Subwoofer ON/OFF.
Â¥ Dimmer level.
Â¥ Monitor ON/OFF.
Â¥ MD/TAPE settings.Â¥ 6ch/2ch input setting.
Â¥ Listen mode setting.
Â¥ Speaker settings.
Â¥ Input mode setting.
Â¥ Midnight mode setting.
Â¥ Broadcast band.
Â¥ Frequency setting.
Â¥ Preset stations.
Â¥ Tuning mode.
Â¥ CINEMA EQ.
Â¥ Source Direct.
True home theater soundThis receiver incorporates a wide variety of surround modes to bring you
maximum enjoyment from your video software. Select a surround mode
according to your equipment or the software you are going to play and
enjoy! ¦
Dolby Pro Logic & Dolby 3 StereoThis surround system reproduces theater-like surround sound from
video software marked .
The PRO LOGIC mode uses the built-in adaptive matrix circuit to steer
the Left, Center, Right and Surround channel audio signals.
The 3 STEREO mode will redirect the Surround signal to the front left and
right speakers when only the front and center speakers are used.
Dolby DigitalThe DOLBY DIGITAL mode lets you enjoy full digital surround from
software processed in the Dolby Digital format. Dolby Digital provides up
to 5.1 channels of independent digital audio for better sound quality and
more powerful presence than conventional Dolby Surround.
DTSDTS (Digital Theater System) is a 5.1 channel digital audio format that
provides five full-spectrum channels and one low-frequency (subwoofer)
channel for unprecedented clarity, optimum channel separation and a
(wide) dynamic range.
In the DTS mode, the 5.1 channel digital input from a DTS CD, LD or DVD
disc (carrying the ÒDTSÓ marking) can be played in Digital Surround.
Important:
When a DTS disc is played on a CD, LD or DVD player, noise may be
output from the analog output. It is recommended that you connect the
digital output of the player to the digital input of this unit.
DSP surround modesThe DSP (Digital Signal Processor) used for this receiver incorporates a
variety of high quality adjustable sound fields, like ÒARENAÓ, ÒJAZZ
CLUBÓ, ÒTHEATERÓ, ÒSTADIUMÓ and ÒDISCOÓ . It is compatible with
almost any kind of program source.
DVD 6-channel inputIf you own a DVD player equipped with 6-channel output, this receiver
allows you to obtain the full surround sound impact of DVD source
material featuring multi-channel encoding. Since the source signals are
digital and each channel is input independently, the resulting ambience
is far superior to what can be achieved with conventional surround sound
systems.
Universal IR (InfraRed) remote control (KRF-V6050D only)In addition to the basic receiver, the remote control supplied with this
receiver can also operate almost all of your remote controllable audio and
video components. Just follow the simple setup procedure to register the
components you have connected.
RDS (Radio Data System) tunerThe receiver is equipped with an RDS tuner that provides several conve-
nient tuning functions: RDS Auto Memory, to automatically preset up to 40
RDS stations broadcasting different programs; station name display, to
show you the name of the current broadcast station; and PTY search to let
you tune stations by program type.
PTY (Program TYpe) searchTune the stations by specifying the type of program you want to hear.
Model name Remote Terminal Control Speaker out Front input
KRF-V6050D RC-R0616 2 systems Equipped (A, B)
KRF-V5050D RC-R0512 1 system Not equipped
Page 9
10
Preparations
L VIDEO 1 S VIDEO
RA
LCL R
L RB
PLAY IN REC OUT PLAY IN
MONITOR
OUT
VIDEO 1 DVD
R
VIDEO 2/MONITOR VIDEO 1PLAY IN PLAY IN REC OUT MD / TAPE
AUDIOPLAY INREC OUT
S VIDEO
DVD VIDEO 1 VIDEO 1 MONITOR
OUTPLAY IN REC OUT PLAY IN
VIDEO 2 INVIDEO
MONITOR
OUTVIDEO 1
OUT
VIDEO 1 INCD/DVD
DVDIN
REC OUT CD / DVD
Connecting video components
OUTVideo Inputs
(Yellow RCA pin cord)
Video inputs and outputs
(Yellow RCA pin cords)
Setting up the system
Video deckMonitor TV
OUTIN
Audio inputs and
outputs
A video component with digital audio outputs should be connected to the VIDEO2 jacks.
VIDEO
INS Video jacks
(KRF-V6050D only)
About the S VIDEO
jacks
Use the S VIDEO jacks to
make connections to
video components with S
VIDEO IN/OUT jacks.
ÖIf you use the S VIDEO
jacks to connect your video
playback components, be
sure to use the S VIDEO
jacks when connecting
your monitor and video
recording components.
S VIDEO
DVD player or LD player
IN
OUT
OUT IN
Page 15
16
Preparations
L VIDEO 1 S VIDEO
RA
LCL R
L RB
PLAY IN REC OUT PLAY IN
MONITOR
OUT
VIDEO 1 DVD
R
FRONT SPEAKERS CENTER SPEAKER
SUB WOOFER
PRE OUT
+
+
FRONT SPEAKERS
SURROUND SPEAKERS(6 -“ 16 W)
(6 -“ 16
W)
RED BLUE GREEN
GRAY ORANGE
SURROUND SPEAKERS
(6 -“ 16 W)
GRAY ORANGE
+
-
FRONT SPEAKERS CENTER SPEAKER RED BLUE GREEN
Right Front Speakers A
Left Right
Use the FRONT SPEAKERS B
terminals if you want to connect
a second front speaker system
(for KRF-V6050D only). Left
(Be sure to connect both
surround speakers) Center
Speaker
Surround Speakers Powered
subwooferThe KRF-V5050D is equipped with one-
touch speaker terminals.They are arranged
in the same manner as the speaker
terminals of the KRF-V6050D. Refer to the
instructions on making connections to the
KRF-V6050D when making connections to
the KRF-V5050D.
KRF-V6050D
Setting up the system
Connecting the speakers
KRF-V5050D
KRF-V5050D KRF-V6050D
