KDC-9007/7050R

MECHANISM OPERATION DESCRIPTION

3-3. Connection of Slider movement with LOCK PIN

lJcinting condition of MD-Chassis ass'y and Main-Chassis assyl

- This mechanism have 2 main components
MD Chassis assy (1)

This unit have many gears and motor for basrc move-
ment, and Optical ple Signal
Main Chassis assy (2/

This unit conSist of metal body frame and Roller ass'v
for disc Insert and elect movement

MD Chasers ass'y (1) was hung by spring (60) of Main
ChaSSIS ass'y l2)

- Slider base assy was assembled in MD Chassis
Lock plate (1 l, 12) was assembled in Main ChaSSis

Pin of lock plate Will iomt to the hole of slide lock gear,

and it move With the slide lock gear .,®

*At both Slde of Main ChaSSls have lock plate unit

@, @ Left Side lock plate unit move together With

the right Slde through iomed roller ass'y (l 5)

Slider base ass'y

Right side facmg

12
