KAF-3010R/1010 (En)
Before applying power
Units are designed for operation as follows.
Europe and U.K...................................................................... AC 230 V only
*Other countries............................. AC 110-120 /220-240 V switchable
For the United Kingdom
Factory fitted moulded mains plug
1. The mains plug contains a fuse. For replacement, use only a
13-Amp ASTA-approved (BS1362) fuse.
2. The fuse cover must be refitted when replacing the fuse in
the moulded plug.
3. Do not cut off the mains plug from this equipment. If the plug
fitted is not suitable for the power points in your home or the
cable is too short to reach a power point, then obtain an
appropriate safety approved extension lead or adapter, or
consult your dealer.
If nonetheless the mains plug is cut off, remove the fuse and
dispose of the plug immediately, to avoid a possible shock
hazard by inadvertent connection to the mains supply.
IMPORTANT
The wires in the mains lead are coloured in accordance
with the following code.
Blue : Neutral
Brown : Live
Do not connect those leads to the earth terminal of a
three-pin plug.
Safety precautions
CAUTIONRISK OF ELECTRIC SHOCK
DO NOT OPEN
WARNING :TO PREVENT FIRE OR ELECTRIC SHOCK, DO NOT EXPOSE THIS APPLIANCE TO RAIN
OR MOISTURE.
CAUTION: TO REDUCE THE RISK OF ELECTRIC SHOCK, DO NOT REMOVE COVER
(OR BACK). NO USER-SERVICEABLE PARTS INSIDE, REFER SERVICING TO
QUALIFIED SERVICE PERSONNEL.
THE LIGHTNING FLASH WITH ARROWHEAD SYMBOL, WITHIN AN EQUILATERAL TRIANGLE, IS
INTENDED TO ALERT THE USER TO THE PRESENCE OF UNINSULATED ÒDANGEROUS VOLTAGEÓ
WITHIN THE PRODUCTÕS ENCLOSURE THAT MAY BE OF SUFFICIENT MAGNITUDE TO CONSTITUTE
A RISK OF ELECTRIC SHOCK TO PERSONS.
THE EXCLAMATION POINT WITHIN AN EQUILATERAL TRIANGLE IS INTENDED TO ALERT THE USER
TO THE PRESENCE OF IMPORTANT OPERATING AND MAINTENANCE (SERVICING) INSTRUCTIONS
IN THE LITERATURE ACCOMPANYING THE APPLIANCE.
Unpacking
Unpack the unit carefully and make sure that all accessories are put aside so they will not be lost.
Examine the unit for any possibility of shipping damage. If your unit is damaged or fails to operate, notify your dealer immediately. If your unit
was shipped to you directly, notify the shipping company without delay. Only the consignee (the person or company receiving the unit) can file
a claim against the carrier for shipping damage.
We recommend that you retain the original carton and packing materials for use should you transport or ship the unit in the future.
Caution : Read this page carefully to ensure safe operation.
*For other countries
This unit operates on 110-120 or 220-240 volts AC . The AC voltage
selector switch on the rear panel is set to the voltage that prevails in
the area to which the unit is shipped. Before connecting the power
cord to your AC outlet, make sure that the setting position of this
switch matches your line voltage. If not, it must be set to your voltage
in accordance with the following direction.
AC voltage selection
AC voltage selector switch
Move switch lever to match
your line voltage with a small
screwdriver or other pointed
tool.
Note:
Our warranty does not cover damage caused by excessive line voltage
due to improper setting of the AC voltage selector switch.
AC 220-
240V AC 110-
120V
Page 2
3
KAF-3010R/1010 (En)
Special features
SOURCE DIRECT
Lets you enjoy high quality sound from the music source selected by the INPUT SELECTOR.
Caution : Read the pages marked carefully to ensure safe operation. Contents
Before applying power .................................................................................................................................................. 2
Before applying power.................................................................................................................... 2
Safety precautions.......................................................................................................................... 2
Special features .................................................................................................................................................. 3
System connection
.................................................................................................................................................. 4
The system control connections.......................................................................................................... 5
Connection of speakers........................................................................................................................ 6
Controls and indicators .................................................................................................................................................. 7
Main unit................................................................................................................................................ 7
Remote control unit...............................................................................................................................8
Operation of remote control unit .................................................................................................................................................. 9
Playing music
................................................................................................................................................ 10
Normal Playback.................................................................................................................................. 10
Sound adjustment functions ................................................................................................................................................ 11
To mute sound temporarily................................................................................................................ 11
Adjusting the left/right sound balance............................................................................................... 11
Adjusting the tone............................................................................................................................... 11
Emphasizing deep bass (LOUDNESS)............................................................................................... 11
To listen through headphones............................................................................................................ 12
Listening to high quality sound from a music source (SOURCE DIRECT).................................... 12
Recording ................................................................................................................................................ 13
To record a music source................................................................................................................... 13
In case of difficulty ................................................................................................................................................ 14
Specifications ................................................................................................................................................ 15
Accessories
Remote control unit (1)
(KAF-3010R only)Batteries (R6/SUM-3) (2)
(KAF-3010R only) AC plug adaptor (1)
Use to adapt the plug on
the power cord to the
shape of the wall outlet.
(Accessory only for
regions where use is
necessary.)
