Page 1
CD-224M/DPF-J5010 (En)
2
Introduction
Before applying power Caution : Read this section carefully to ensure safe operation.
Units are designed for operation as follows.
U.S.A. and Canada .................................. AC 120 V only
Australia .................................................. AC 240 V only Europe and U.K. ............................................... AC 230 V only
*Other countries ............. AC 110-120 / 220-240 V switchable
The marking is located on the rear panel and says that the component
uses laser beams that have been classified as Class 1. It means that
the unit is utilizing laser beams that are of a weaker class. There is n\
o
danger of hazardous radiation outside the unit.
CLASS 1
LASER PRODUCT
The marking of products using lasers
(Except for some areas)
REQUIREMENT BY NEDERLAND GAZETTE
Batteries are supplied with this product. When
they empty, you should not throw away. In-
stead, hand them in as small chemical waste.
Introduction
*AC voltage selection
The AC voltage selector switch on the rear panel is set to the voltage
that prevails in the area to which the unit is shipped. Before
connecting the power cord to your AC outlet, make sure that the
setting position of this switch matches your line voltage. If not, it m\
ust
be set to your voltage in accordance with the following direction.
Move switch lever to match your line voltage with a
small screwdriver or other pointed tool.
Note:Our warranty does not cover damage caused by excessive line
voltage due to improper setting of the AC voltage selector switch.
For the United Kingdom
Factory fitted moulded mains plug
1. The mains plug contains a fuse. For replacement, use only a 13-Amp ASTA-\
approved (BS1362) fuse.
2. The fuse cover must be refitted when replacing the fuse in the moulded p\
lug.
3. Do not cut off the mains plug from this equipment. If the plug fitted is\
not suitable for the power points in your home or the cable is too short to reacha power point, then obtain an appropriate safety approved extension lead\
or adapter, or consult your dealer.
If nonetheless the mains plug is cut off, remove the fuse and dispose of\
the plug immediately, to avoid a possible shock hazard by inadvertent
connection to the mains supply.
IMPORTANTThe wires in the mains lead are coloured in accordance with the followin\
g code:
Blue : Neutral
Brown : Live
Do not connect those leads to the earth terminal of a three-pin plug.
WARNING : TO PREVENT FIRE OR ELECTRIC SHOCK, DO NOT EXPOSE THIS
APPLIANCE TO RAIN OR MOISTURE.
Safety precautions
THE LIGHTNING FLASH WITH ARROWHEAD SYMBOL, WITHIN AN EQUILATERAL TRIANGL\
E, IS INTENDED TO ALERT THE
USER TO THE PRESENCE OF UNINSULATED ÒDANGEROUS VOLTAGEÓ WITHIN THE\
PRODUCTÕS ENCLOSURE THAT MAY
BE OF SUFFICIENT MAGNITUDE TO CONSTITUTE A RISK OF ELECTRIC SHOCK TO PER\
SONS.
Caution : Read this section carefully to ensure safe operation.
THE EXCLAMATION POINT WITHIN AN EQUILATERAL TRIANGLE IS INTENDED TO ALER\
T THE USER TO THE PRESENCE
OF IMPORTANT OPERATING AND MAINTENANCE (SERVICING) INSTRUCTIONS IN THE\
LITERATURE ACCOMPANYING
THE APPLIANCE.
CAUTION
RISK OF ELECTRIC SHOCK
DO NOT OPEN
CAUTION: TO REDUCE THE RISK OF ELECTRIC SHOCK, DO NOT REMOVE COVER (OR
BACK). NO USER-SERVICEABLE PARTS INSIDE. REFER SERVICING TO QUALIFIED S\
ER-
VICE PERSONNEL.
AC voltage selector switch
AC110-“
120V AC220-“
240V
LROUTPUT
DIGITAL
OUT
SYSTEM
CONTROL
OPTICAL SL16 XS 8
AC220-“
240V AC110-“
120V
Page 2
3
CD-224M/DPF-J5010 (En)
Introduction
Special features
CD player with 200-disc changer
CD-TEXT support
Title name registrable
Programmed playback
Filing functions suitable for a 200-disc changer This unit can accommodate up to 200 discs and can be used like a
home jukebox.
The text information (disc title, track titles, names of the artists,
songwriters, composers, etc.) recorded on the CDs can be easily
called and displayed in alphanumerics. (Some Japanese words and
text may not be displayed.)
%
In case of a disc not corresponding to CD-TEXT, you can register a
disc title or other information yourself. )
Desired tracks from up to 200 discs can be selected and programmed
in the desired order. (Maximum 32 tracks) ^
An enhanced filing function is provided to handle the large disc
capacity.
Music type: Discs are filed by 26 music genres.
¢ Best selection: Only favorite tracks can be registered from 200discs and played. ¦
Contents
Introduction .................................................................. 2
Before applying power ................................................ 2
Safety precautions ........................................................ 2
Special features ............................................................. 3
System connections ..................................................... 6
Connection to digital amplifier or MD ........................ 7
Connection to a general-use amplifier ........................ 7
Controls and indicators ............................................... 8
Operation of remote control unit ............................... 9
Loading batteries ........................................................... 9
Operation ........................................................................\
9
Preparation .................................................................. 10
Loading discs in the carousel ..................................... 10
In regard to ALL DATA READ mode .......................... 11
Normal play (TRACK mode) ............................................ 12
Playing tracks in order from track No.1 .................... 12
Direct disc selection .................................................... 13
Playback from desired track ....................................... 14
Skipping tracks ............................................................ 14
Searching ...................................................................... 14
Displays ........................................................................\
15
Programming tracks in desired order
(PGM mode) ....... 16
To check the programmed tracks .............................. 17
To add a track to the program ................................... 17
To change a track in the program ............................. 17
To clear tracks from the program .............................. 17
Repeated playback (REPEAT mode) .............................. 18
To repeat only the desired tracks .............................. 18
To repeat one selected disc ........................................ 18
Playback in a random order (RANDOM mode) ............ 19
To select another track in the middle of playing one .... 19
To cancel random playback ........................................ 19
Registration of Title Name ........................................ 20
Assigning Title Names ................................................ 20
To change the character type ..................................... 21
To change or delete a title name ............................... 22
To switch between insert and overwrite mode ....... 23
To enter a space ........................................................... 23
Listening to music by genre (MUSIC TYPE mode) ............ 24
Registration of music type files ................................. 24
To delete the registered music type .......................... 25
Playing the music type file ......................................... 26
Listening to your favorite titles
(BEST SELECTION mode) ..................................................... 27
Registration of best selection file .............................. 27
Playing the best selection file .................................... 28
To delete the registered best selection .................... 28
Timer operation ........................................................... 29
Important items ........................................................... 30
In case of difficulty .................................................... 31
Specifications ............................................................. 32
