Kenwood DP 29 MIDI Service Manual

Page 1

CD PLAYER

DP-29
SERVICE MANUAL
(MIDI M-29/M-49)

KENWOOD

(01995-9 PRINTED IN KOREA
B51 -5107-00( N l2584

Metallic cabinet
(A01733O7708)

From glass
(B10 2214708)

Panel Knob (10 KEY)
(A6010890708) (KN-633008)

Cord wilh connector (15?)
(E30-2673»05]

Sub panel (TRAY) Knob
(A2271719-08)

Foot (FRONT)
(K297633108) ($H1101580798)

F00! (REAR)
(SH1101230060)
In compliance with Federal Regulations, following are repro-
ductions ol labels on, or inside the product relating to laser PRECAUTIONS FOR REPAIR

product salety

KENWOOD-Ccrp. certifies this equipment conforms to DHHS
Regulaions No.21 CFR 1040 10, Chapter 1, Subchapter J.

DANGER : Laser radiation when open and interlock defeated.
AVOID DIRECT EXPOSURE TO BEAMA

DP-29 does not have a power supply
transformer. Use RX-29, RX-49 or PS-
94UA power supply to supply power.
