Extracted text from Jvc XVD 9000 Owners Manual (Ocr-read)
Page 1
2
Warnings, Cautions and Others
CAUTION: TO REDUCE THE RISK OF ELECTRIC SHOCK
DO NOT REMOVE COVER (OR BACK)
NO USER SERVICEABLE PARTS INSIDE
REFER SERVICING TO QUALIFIED SERVICE PERSONNEL.
(For U.S.A)
CAUTIONRISK OF ELECTRIC
SHOCK
The lightning flash with arrowhead
symbol, within an equilateral triangle is
intended to alert the user to the presence
of uninsulated Òdangerous voltageÓ within
the productÕs enclosure that may be of
sufficient magnitude to constitute a risk
of electric shock to persons.
The exclamation point within an equilateral
triangle is intended to alert the user to the
presence of important operating and
maintenance (servicing) instructions in the
literature accompanying the appliance.
WARNING: TO REDUCE THE RISK OF FIRE
OR ELECTRIC SHOCK, DO NOT EXPOSE THIS
APPLIANCE TO RAIN OR MOISTURE.
INFORMATION
This equipment has been tested and found to comply
with the limits for a Class B digital device, pursuant
to Part 15 of the FCC Rules. These limits are designed
to provide reasonable protection against harmful
interference in a residential installation. This equipment
generates, uses, and can radiate radio frequency
energy and, if not installed and used in accordance with
the instructions, may cause harmful interference to
radio communications. However, there is no guarantee
that interference will not occur in a particular
installation. If this equipment does cause harmful
interference to radio or television reception, which
can be determined by turning the equipment off and on,
the user is encouraged to try to correct the
interference by one or more of the following measures:Ð Reorient or relocate the receiving antenna.
Ð Increase the separation between the equipment and
receiver.
Ð Connect the equipment into an outlet on a circuit
different from that to which the receiver is
connected.
Ð Consult the dealer or an experienced radio/TV
technician for help.
XVD9000_p02-06.p652/27/01, 4:05 PM 2
Page 2
3
1. CLASS 1 LASER PRODUCT
2.DANGER: Invisible laser radiation when open and interlock
failed or defeated. Avoid direct exposure to beam.
3.CAUTION: Do not open the top cover. There are no user
serviceable parts inside the unit; leave all servicing to
qualified service personnel.
Warnings, Cautions and Others
For Canada/pour le Canada
CAUTION: TO PREVENT ELECTRIC SHOCK, MATCH
WIDE BLADE OF PLUG TO WIDE SLOT, FULLY INSERT.
PRECAUTION: POUR EVITER LES CHOCS
ELECTRIQUES, INTRODUIRE LA LAME LA PLUS
LARGE DE LA FICHE DANS LA BORNE
CORRESPONDANTE DE LA PRISE ET POUSSER
JUSQUAU FOND.
For Canada/pour le Canada
THIS DIGITAL APPARATUS DOES NOT EXCEED THE
CLASS B LIMITS FOR RADIO NOISE EMISSIONS FROM
DIGITAL APPARATUS AS SET OUT IN THE
INTERFERENCE-CAUSING EQUIPMENT STANDARD
ENTITLED ÒDIGITAL APPARATUS,Ó ICES-003 OF THE
DEPARTMENT OF COMMUNICATIONS.
CET APPAREIL NUMERIQUE RESPECTE LES LIMITES
DE BRUITS RADIOELECTRIQUES APPLICABLES AUX
APPAREILS NUMERIQUES DE CLASSE B PRESCRITES
DANS LA NORME SUR LE MATERIEL BROUILLEUR:
ÒAPPAREILS NUMERIQUESÓ, NMB-003 EDICTEE PAR
LE MINISTRE DES COMMUNICATIONS.
Caution Ñ POWER switch!
Disconnect the power plug to shut the power off completely.
The POWER switch in any position does not disconnect the
power source. The power can be remote controlled.
CAUTION
To reduce the risk of electrical shocks, fire, etc.:
1. Do not remove screws, covers or cabinet.
2. Do not expose this appliance to rain or moisture.1. PRODUIT LASER CLASSE 1
2.ATTENTION: Radiation laser invisible quand lÕappareil est
ouvert ou que le verrouillage est en panne ou dŽsactivŽ.
Eviter une exposition directe au rayon.
3.ATTENTION: Ne pas ouvrir le couvercle du dessus. Il nÕy a
aucune pice utilisable ˆ lÕintŽrieur. Laisser ˆ un personnel
qualifiŽ le soin de rŽparer votre appareil.
ATTENTION
Afin dÕŽviter tout risque dÕŽlectrocution, dÕincendie. etc.:
1. Ne pas enlever les vis ni les panneaux et ne pas ouvrir le
coffret de lÕappareil.
2. Ne pas exposer lÕappareil ˆ la pluie ni ˆ lÕhumiditŽ.
Attention Ñ Commutateur POWER!
DŽconnecter la fiche de secteur pour couper compltement
le courant. Le commutateur POWER ne coupe jamais
compltement la ligne de secteur, quelle que soit sa position.
Le courant peut tre tŽlŽcommandŽ.
XVD9000_p02-06.p652/27/01, 4:05 PM 3
Page 8
9 Connections
Connecting to a TV
You can also use the player by simply connecting it to a normal TV. To enjoy the advanced sound quality, connect the
audio output to specialist audio equipment. See pages 10, 11, and 12.
S-Video Signal
S-Video separates the luminance signal (Y) and color signal (C) of previous video signals. It achieves vivid images in
which color blur is rare.
PRODUCT COMPLIES WITH DHHS RULES
21 CFR SUBCHAPTER J IN EFFECT AT DATE
OF MANUFACTURE. JVC AMERICAS CORP.
1700 VALLEY ROAD
WAYNE, N.J. 07470
THIS DEVICE COMPLIES WITH PART 15
OF THE FCC RULES. OPERATION IS
SUBJECT TO THE FOLLOWING TWO
CONDITIONS: (1) THIS DEVICE MAY NOT
CAUSE HARMFUL INTERFERENCE, AND
(2) THIS DEVICE MUST ACCEPT ANY
INTERFERENCE RECEIVED, INCLUDING
INTERFERENCE THAT MAY CAUSE
UNDESIRED OPERATION.NUMBER LABEL
FRONT
REAR CENTER SUBWOOFER
AUDIO ANALOG OUTPUT
VICTOR COMPANY OF JAPAN,LIMITED MADE IN JAPAN Apparatus Claims of
U.S.Patent Nos.
4,631,603, 4,577,216,
4,819,098,and
4,907,093 licensed
for limited viewing
uses only.
Manufactured under license from DolbyLaboratories."Dolby", "MLP Lossless",and the double-D symbol are trademarks of Dolby Laboratories.Confidential Unpublished Works.Copyrights 1992-1998 Dolby Laboratories. All rights reserved. Manufactured under license from Digital Theeter Systeme,Inc.US Pat.
No.5,451,942 and other world-wide paterts lssued and pending. "DTS",
"DTS Digital Surround",are trademarks of Digital Theater System,Inc.
Copyrlght 1996 Digital Theater Systems,Inc.All Rights Reeerved.
LEFT
AUDIO DIGITAL OUTPUTPCM / STREAM COAXIAL OPTICAL RIGHT LEFT
RIGHT
AC IN PR PB VIDEOS-VIDEO YCOMPONENTVIDEO OUTPUT
WARNING: SHOCK HAZARD - DO NOT OPEN
AVIS: RISQUE DE CHOC ELECTRIQUE - NE PAS OUVRIR
DVD PLAYER
MODEL NO. XV-D9000
AC 120V ~ 60Hz 35WLISTED
4C43
VIDEO
EQUIPMENT
CAUTION RISK OF ELECTRIC SHOCK
DO NOT OPEN
Sound is output from
the TV speakers.To S-Video input terminals S Video cable
To video input terminals video cableConnect one of these
Audio cable
Main unit
To AUDIO LEFT input terminal
To AUDIO RIGHT input terminal TV
Connect this if your TV
has a S-Video input
terminal. You will get
better picture quality.
XVD9000_p07-14.p652/27/01, 4:05 PM 9
