Page 1
1-2 (No.MB630)
SPECIFICATION
Design and specifications are subject to change without notice. Amplifier section Output Power
5 W per channel min. RMS driven into 4 -„¦ at 1 kHz with no more than 10% total harmonic
distortion. (IEC268-3)
Speakers/Impedance 4 -„¦ - 8 -„¦
Tuner section FM tuning range 87.50 MHz - 108.00 MHz
AM (MW) tuning range 522 kHz - 1 629 kHz
CD player section Dynamic range 60 dB
Signal-to-noise ratio 60 dB
Wow and flutter Immeasurable
Cassette deck section Frequency response Normal (type I): 125 Hz - 8 kHz
Wow and flutter 0.35% (WRMS)
General Power requirement AC 230 V , 50 Hz
Power consumption 26 W (at operation)
0.9 W (on standby)
Dimensions (approx.) 141 mm × 211 mm × 216 mm (W/H/D)
Mass (approx.) 2.6 kg
Speakers Type 1-way Bass reflex
Speaker units 10 cm cone × 1
Impedance 4 -„¦
Dimensions (approx.) 136 mm × 212 mm × 178 mm (W/H/D)
Mass (approx.) 1.3 kg each
