Page 1
1-2 (No.MB160)
SPECIFICATION
Amplifier section-CA-MXGB6
Speaker section-SP-MXGB6
Design and specifications are subject to change without notice. Output Power SUBWOOFERS 170 W per channel, min. RMS, driven into 6 -„¦ at 63 Hz with no more than
10% total harmonic distortion.
MAIN SPEAKERS 80 W per channel, min. RMS, driven into 4 -„¦ at 1 kHz with no more than
10% total harmonic distortion.
Audio input sensitivity/Impedance
(at 1 kHz, measured at MAIN SPEAKERS)AUX:400 mV/50 k-„¦
Speakers/Impedance Subwoofers 6 -„¦ - 16 -„¦
Main speakers 4 -„¦ - 8 -„¦
Tuner FM tuning range 87.50 MHz - 108.00 MHz
AM tuning range 530 kHz - 1 710 kHz
CD player CD Capacity 3 CDs
Dynamic range 85 dB
Signal-to-noise ratio 85 dB
Cassette deck Frequency response Normal (type I) 50 Hz - 14 000 Hz
Wow and flutter 0.15% (WRMS)
General Power requirement AC 120 V , 60 Hz
Power consumption 230 W (at operation)
23.8 W (on standby)
Dimensions (approx.) 270 mm × 317 mm × 480 mm (W/H/D)
(10 11/16 in. × 12 1/2 in. × 18 15/16 in.)
Mass (approx.) 10.5 kg (23.2 lbs)
Type 3-way bass-reflex type
Speaker units Subwoofer 20 cm (7 7/8 in.) cone × 1
Main Woofer 12 cm (4 3/4 in.) cone × 1
Tweeter 5 cm (2 in.) cone × 1
Power handling capacity Subwoofer 170 W
Main speaker 80 W
Impedance Subwoofer 6 -„¦
Main speaker 4 -„¦
Frequency range Subwoofer 25 Hz - 100 Hz
Main speaker 100 Hz - 20 000 Hz
Sound pressure level Subwoofer 75 dB/W·m
Main speaker 82 dB/W·m
Dimensions (approx.) 233 mm × 456 mm × 360 mm (W/H/D)
(9 3/16 in. × 18 in. × 14 3/16 in.)
Mass (approx.) 6.6 kg (14.6 lbs) each
Page 2
(No.MB160)1-3 Amplifier section-CA-MXGB5
Speaker section-SP-MXGB5
Design and specifications are subject to change without notice. Output Power SUBWOOFERS 160 W per channel, min. RMS, driven into 6 -„¦ at 63 Hz with no more than
10% total harmonic distortion.
MAIN SPEAKERS 70 W per channel, min. RMS, driven into 4 -„¦ at 1 kHz with no more than
10% total harmonic distortion.
Audio input sensitivity/Impedance
(at 1 kHz, measured at MAIN SPEAKERS)AUX:400 mV/50 k-„¦
Speakers/Impedance Subwoofers 6 -„¦ - 16 -„¦
Main speakers 4 -„¦ - 8 -„¦
Tuner FM tuning range 87.50 MHz - 108.00 MHz
AM tuning range 530 kHz - 1 710 kHz
CD player CD Capacity 3 CDs
Dynamic range 85 dB
Signal-to-noise ratio 85 dB
Cassette deck Frequency response Normal (type I) 50 Hz - 14 000 Hz
Wow and flutter 0.15% (WRMS)
General Power requirement AC 120 V , 60 Hz
Power consumption 220 W (at operation)
23.3 W (on standby)
Dimensions (approx.) 270 mm × 317 mm × 480 mm (W/H/D)
(10 11/16 in. × 12 1/2 in. × 18 15/16 in.)
Mass (approx.) 10 kg (22.1 lbs)
Type 4-way bass-reflex type
Speaker units Subwoofer 16 cm (6 5/16 in.) cone × 1
Main Woofer 16 cm (6 5/16 in.) cone × 1
Tweeter 2 cm (13/16 in.) dome × 1
Midrange 5 cm (2 in.) cone × 1
Tweeter 2 cm (13/16 in.) dome × 1
Power handling capacity Subwoofer 160 W
Main speaker 70 W
Impedance Subwoofer 6 -„¦
Main speaker 4 -„¦
Frequency range Subwoofer 25 Hz - 90 Hz
Main speaker 90 Hz - 20 000 Hz
Sound pressure level Subwoofer 75 dB/W·m
Main speaker 86 dB/W·m
Dimensions (approx.) 302.5 mm × 325.5 mm × 345 mm (W/H/D)
(11 15/16 in. × 12 7/8 in. × 13 5/8 in.)
Mass (approx.) 6.6 kg (14.6 lbs) each
