MX-G500
1-2
1. This design of this product contains special hardware and many circuits and components specially for safety
purposes. For continued protection, no changes should be made to the original design unless authorized in
writing by the manufacturer. Replacement parts must be identical to those used in the original circuits. Services
should be performed by qualified personnel only.
2. Alterations of the design or circuitry of the product should not be made. Any design alterations of the product
should not be made. Any design alterations or additions will void the manufacturer`s warranty and will further
relieve the manufacture of responsibility for personal injury or property damage resulting therefrom.
3. Many electrical and mechanical parts in the products have special safety-related characteristics. These
characteristics are often not evident from visual inspection nor can the protection afforded by them necessarily
be obtained by using replacement components rated for higher voltage, wattage, etc. Replacement parts which
have these special safety characteristics are identified in the Parts List of Service Manual. Electrical
components having such features are identified by shading on the schematics and by ( ) on the Parts List in
the Service Manual. The use of a substitute replacement which does not have the same safety characteristics
as the recommended replacement parts shown in the Parts List of Service Manual may create shock, fire, or
other hazards.
4. The leads in the products are routed and dressed with ties, clamps, tubings, barriers and the like to be
separated from live parts, high temperature parts, moving parts and/or sharp edges for the prevention of
electric shock and fire hazard. When service is required, the original lead routing and dress should be
observed, and it should be confirmed that they have been returned to normal, after re-assembling.
5. Leakage currnet check (Electrical shock hazard testing)
After re-assembling the product, always perform an isolation check on the exposed metal parts of the product
(antenna terminals, knobs, metal cabinet, screw heads, headphone jack, control shafts, etc.) to be sure the
product is safe to operate without danger of electrical shock.
Do not use a line isolation transformer during this check.
Plug the AC line cord directly into the AC outlet. Using a "Leakage Current Tester", measure the leakage
current from each exposed metal parts of the cabinet, particularly any exposed metal part having a return
path to the chassis, to a known good earth ground. Any leakage current must not exceed 0.5mA AC (r.m.s.).
Alternate check method
Plug the AC line cord directly into the AC outlet. Use an AC voltmeter having, 1,000 ohms per volt or more
sensitivity in the following manner. Connect a 1,500 10W resistor paralleled by a 0.15 F AC-type capacitor
between an exposed metal part and a known good earth ground.
Measure the AC voltage across the resistor with the AC
voltmeter.
Move the resistor connection to each exposed metal part,
particularly any exposed metal part having a return path to
the chassis, and meausre the AC voltage across the resistor.
Now, reverse the plug in the AC outlet and repeat each
measurement. Voltage measured any must not exceed 0.75 V
AC (r.m.s.). This corresponds to 0.5 mA AC (r.m.s.).
1. This equipment has been designed and manufactured to meet international safety standards.
2. It is the legal responsibility of the repairer to ensure that these safety standards are maintained.
3. Repairs must be made in accordance with the relevant safety standards.
4. It is essential that safety critical components are replaced by approved parts.
5. If mains voltage selector is provided, check setting for local voltage.
Good earth groundPlace this
probe on
each exposed
metal part. AC VOLTMETER
(Having 1000
ohms/volts,
or more sensitivity)
1500 10W
0.15 F AC TYPE
!
Burrs formed during molding may
be left over on some parts of the
chassis. Therefore, pay attention to
such burrs in the case of
preforming repair of this system.
In regard with component parts appearing on the silk-screen printed side (parts side) of the PWB diagrams, the
parts that are printed over with black such as the resistor ( ), diode ( ) and ICP ( ) or identified by the " "
mark nearby are critical for safety.
(This regulation does not correspond to J and C version.)
Page 2
MX-G500
1-3
^
Importance administering point on the safety
Fuse board (Forward side)Power supply board (Forward side)
4A 125V
4A 125V
4A 125V
4A 125V
4A 125V
RFS5
RFS6
RFS7
RFS8RFS2
Caution: For continued protection against risk of fire,
replace only with same type 4A/125V for RFS2, RFS5,
RFS6, RFS7 and RFS8.
This symbol specifies type of fast operating fuse.
Precaution: Pour eviter risques de feux, remplacez le
fusible de surete de et RFS2, RFS5, RFS6, RFS7 et
RFS8 comme le meme type que 4A/125V.
Ce sont des fusibles suretes qui functionnes rapide.
Page 8
MX-G500
1-9
Disconnect the card wire from the connector UCW3,
UCW4, UCW5 and UCW6 on the FL display & system
control board.
Remove the six screws B attaching the FL display &
system control board.
Disconnect the card wire from the connector UCW2
on the FL display & system control board. 1.
2.
3.
Removing the FL display & system control
board (See Fig.1)
Disconnect the card wire from the connector UCW1
on the power / CD switch board.
Remove the five screws A attaching the power / CD
switch board. 1.
2.Prior to performing the following procedure, remove
the metal cover, the CD changer unit and the front
panel assembly.
Removing the power / CD switch board
(See Fig.1)
Prior to performing the following procedure, remove
the FL display & system control board.
Pull out the sound mode knob, volume knob and
subwoofer level knob from front side.
Remove the twelve screws C attaching the front key
switch board.
Remove the front board releasing the two tabs. 1.
2.
3.
Removing the front key switch board
(See Fig.2 and 3)
Prior to performing the following procedure remove
the FL display & system control board.
You can pull out the headphone jack board.
1.
Removing the headphone jack board
(See Fig.3)
Disconnect the card wire from the connector on the
mecha. board.
Remove the six screws D attaching the cassette
mechanism assembly. 1.
2.
Removing the cassette mechanism
assembly (See Fig.3)
Fig.1
Fig.2
Fig.3
Headphone
jack board
Mecha.
board
Cassette mechanism
assembly
A
B
B
C C
D D Power / CD switch board
Front panel assembly (inner side )
Front panel assembly (inner side )
FL diplay &
system control
board
Front key switch boardSound mode knob
Volume knob
Subwoofer level knobUCW1
UCW3
UCW4
UCW7
Tab
Tab
ConnectorUCW5
UCW6 UCW2
D(fixing the earth wire)
Page 31
MX-G500
1-32
LC72131(IC02) : PLL frequency synthesizer for electron alignment
12 10 9
8 7 6
2. Block diagram
54
15
193 13
CCB
I/F
1
20 16
17
18
11
1
2
Reference
Driver
Swallow
Counter
1/16,1/17 4bits
12bits
Programmable
Divider
Power
on
ResetData Shift Register & Latch Unlock
Detector Phase
Detector
Charge
Pump
Universal
Counter
1. Pin layout
1
2
3
4
5
6
7
8
9
1020
19
18
17
16
15
14
13
12
11XOUT
VSS
AOUT
AIN
PD
VDD
FMIN
AMIN
I02
IFIN XIN
CE
DI
CL
DO
BO1
BO2
BO3
BO4
I01
14
2
3.Pin function
Pin No.
1
13Local
oscillator
signal input Symbol
Functions Type Circuit configuration
AMINXtal OSC
FMIN
14
Serial data input : FMIN is selected when DVS is set to 1.
The input frequency range is from 10 to 160MHz.
The signal is passed through a built-in divide-by-two prescaler
and then supplied to the swallow counter.
A1 though the range of divisor setting is from
272 to 65, 535, the actual divisor is twice the setting since
there is also a built-in divide-by-two prescaler. XIN
XOUT
20Crystal resonator connection
(4.5MHz/7.2MHz)
Serial data input : AMIN is selected when DVS is set to 0.
Serial data input : When SNS is set to 1 :
The input frequency range is form 2 to 40MHz
The signal is supplied directly to the swallow counter.
The range of divisor setting is from 272 to
65, 535 and the actual divisor will be the value set.
Serial data input : When SNS is set to 0 :
The input frequency ranges is from 0.5 to 10MHz.
The signal is supplied directly to a 12-bit
programmable divider.
The range of divisor setting is from 4 to 4,095 and the
actual divisor will be the value set. Local
oscillator
signal input
2 CEChip enable Most be set high when serial data is input to the
LC72131M (DI ), or when serial data is output (DO). S
(1/2)
