Page 1
MX-DVA5
1-2
1. This design of this product contains special hardware and many circuits and components specially for safety
purposes. For continued protection, no changes should be made to the original design unless authorized in
writing by the manufacturer. Replacement parts must be identical to those used in the original circuits. Services
should be performed by qualified personnel only.
2. Alterations of the design or circuitry of the product should not be made. Any design alterations of the product
should not be made. Any design alterations or additions will void the manufacturer`s warranty and will further
relieve the manufacture of responsibility for personal injury or property damage resulting therefrom.
3. Many electrical and mechanical parts in the products have special safety-related characteristics. These
characteristics are often not evident from visual inspection nor can the protection afforded by them necessarily
be obtained by using replacement components rated for higher voltage, wattage, etc. Replacement parts which
have these special safety characteristics are identified in the Parts List of Service Manual. Electrical
components having such features are identified by shading on the schematics and by ( ) on the Parts List in
the Service Manual. The use of a substitute replacement which does not have the same safety characteristics
as the recommended replacement parts shown in the Parts List of Service Manual may create shock, fire, or
other hazards.
4. The leads in the products are routed and dressed with ties, clamps, tubings, barriers and the like to be
separated from live parts, high temperature parts, moving parts and/or sharp edges for the prevention of
electric shock and fire hazard. When service is required, the original lead routing and dress should be
observed, and it should be confirmed that they have been returned to normal, after re-assembling.
5. Leakage currnet check (Electrical shock hazard testing)
After re-assembling the product, always perform an isolation check on the exposed metal parts of the product
(antenna terminals, knobs, metal cabinet, screw heads, headphone jack, control shafts, etc.) to be sure the
product is safe to operate without danger of electrical shock.
Do not use a line isolation transformer during this check.
Plug the AC line cord directly into the AC outlet. Using a "Leakage Current Tester", measure the leakage
current from each exposed metal parts of the cabinet, particularly any exposed metal part having a return
path to the chassis, to a known good earth ground. Any leakage current must not exceed 0.5mA AC (r.m.s.).
Alternate check method
Plug the AC line cord directly into the AC outlet. Use an AC voltmeter having, 1,000 ohms per volt or more
sensitivity in the following manner. Connect a 1,500 10W resistor paralleled by a 0.15 F AC-type capacitor
between an exposed metal part and a known good earth ground.
Measure the AC voltage across the resistor with the AC
voltmeter.
Move the resistor connection to each exposed metal part,
particularly any exposed metal part having a return path to
the chassis, and meausre the AC voltage across the resistor.
Now, reverse the plug in the AC outlet and repeat each
measurement. Voltage measured any must not exceed 0.75 V
AC (r.m.s.). This corresponds to 0.5 mA AC (r.m.s.).
1. This equipment has been designed and manufactured to meet international safety standards.
2. It is the legal responsibility of the repairer to ensure that these safety standards are maintained.
3. Repairs must be made in accordance with the relevant safety standards.
4. It is essential that safety critical components are replaced by approved parts.
5. If mains voltage selector is provided, check setting for local voltage.
Good earth groundPlace this
probe on
each exposed
metal part. AC VOLTMETER
(Having 1000
ohms/volts,
or more sensitivity)
1500 10W
0.15 F AC TYPE
!
Burrs formed during molding may
be left over on some parts of the
chassis. Therefore, pay attention to
such burrs in the case of
preforming repair of this system.
In regard with component parts appearing on the silk-screen printed side (parts side) of the PWB diagrams, the
parts that are printed over with black such as the resistor ( ), diode ( ) and ICP ( ) or identified by the " "
mark nearby are critical for safety.
When replacing them, be sure to use the parts of the same type and rating as specified by the manufacturer.
(Except the J and C version)
Page 2
MX-DVA5
1-3
Important for laser products
1.CLASS 1 LASER PRODUCT
2.DANGER : Invisible laser radiation when open and inter
lock failed or defeated. Avoid direct exposure to beam.
3.CAUTION : There are no serviceable parts inside the
Laser Unit. Do not disassemble the Laser Unit. Replace
the complete Laser Unit if it malfunctions.
4.CAUTION : The compact disc player uses invisible
laserradiation and is equipped with safety switches
whichprevent emission of radiation when the drawer is
open and the safety interlocks have failed or are de
feated. It is dangerous to defeat the safety switches.5.CAUTION : If safety switches malfunction, the laser is able
to function.
6.CAUTION : Use of controls, adjustments or performance of
procedures other than those specified herein may result in
hazardous radiation exposure.
Reproduction and position of labels
WARNING LABEL
! CAUTIONPlease use enough caution not to
see the beam directly or touch it
in case of an adjustment or operation
check.
CLASS 1
LASER PRODUCT
Page 7
MX-DVA5
1-8
Prior to performing the following procedure, remove
the metal cover and the CD / DVD changer unit.
Remove the four screws I attaching the heat sink
cover on the back of the body. Remove the heat sink
cover.
Remove the four screws J attaching the heat sink,
amp. board and DVD power board to the rear panel
on the back of the body.
Remove the two screws K attaching the speaker
terminal to the rear panel on the back of the body.
Disconnect the card wire from connector ACW1 and
the harness from connector ACW2 on the amp.
board.
Disconnect the harness from connector LCW5 and
LCW4 on the DVD power board.
After moving the heat sink upward, remove the
claws. Then pull out the heat sink, amp. board and
DVD power board inward. 1.
2.
3.
4.
5.
6.
Removing the heat sink, amp. board and
DVD power board (See Fig.10 to 12)
Fig.8
Fig.9
Front panel assembly
G
E
Main board
H Joint b
Joint b
Joint cBottom side
Fig.10
Fig.11 Rear panel
Heat sink
cover
Heat sink
Speaker terminal Tuner terminal
KL I
I
J
J
Fig.12
ACW1
Rear panel
Amp. board
ACW2LCW5
LCW4 DVD power board
Page 11
MX-DVA5
1-12
Disconnect the card wire from connector RCW1 of
the CD /DVD servo board.
Turn the black loading pulley gear on the under side
of the CD / DVD changer unit in the direction of the
arrow and draw the CD / DVD tray toward the front
until it stops.
Disconnect the card wire from connector DCW1 of
the CD / DVD servo board on the upper side of the
CD / DVD changer unit.
Push down the two tray stoppers marked a and pull
out the CD / DVD tray. 1.
2.
3.
4.
Align the gear-cam with the gear-tray as shown fig.3,
then mount the CD / DVD tray.
When assembling the CD / DVD tray, take extreme
care not engage with gear - synchro. 1.
2.Prior to performing the following procedure, remove
the CD / DVD changer unit.
Removing the CD / DVD tray
(See Fig.1 to 3)
Reinstall the CD / DVD tray
(See Fig.4 and 5)
Fig.2Fig.1
Fig.3
Fig.4 Fig.5
Loading pulley
gear
CD / DVD tray
CD / DVD tray
CD / DVD tray
Gear-convertGear-convertGear-cam
Gear-tray
Gear-synchro
Gear-tray
Gear-trayGear-cam
timing point
CD / DVD tray
CD / DVD servo board
DCW1 a
(Tray stopper)
a (Tray stopper)
CD / DVD
servo board
RCW1
Page 41
MX-DVA5
H
AB C DE FG 12 3 45
2-2MX-DVA5
Standard schematic diagrams
SHEET 1/9
Main section
MAIN signal TUNER signal
TAPE REC. signal TAPE P.B. signal
CD signal
Parts are safety assurance parts.
When replacing those parts make
sure to use the specified one.
SHEET 2/8
PRE MAIN signal
Page 62
MX-DVA5
3-5
12
8
2
19
7
6
5
4
3
1
15
25
10
9
20
21
11
14
22
23
16
13
17
24
DVD changer mechanism assembly and parts list
Block No. M
M M 2
Tray stopper
DVD boardBase main
Page 65
MX-DVA5
3-8
Item
Parts number Parts nameArea
Electrical parts list(Main board)
Remarks
Block No. 01
A
AUX 3722-000377 JACK-RCA
CR 36 2001-000290CARBON RESISTOR
EC 1 2202-000148 C CAPACITOREC 2 2202-000817 C CAPACITOR
EC 3 2401-002180 E.CAPACITOR
EC 4 2401-002180 E.CAPACITOREC 5 2202-000797 C CAPACITOR
EC 6 2202-000809 C CAPACITOR
EC 7 2202-000797 C CAPACITOREC 8 2401-001889 E CAPACITOR
EC 9 2401-000907 E-CAPACITOR
EC 10 2401-001465 E.CAPACITOR
EC 11 2202-000854 C CAPACITOR
EC 12 2202-000797 C CAPACITOR
EC 15 2202-000797 C CAPACITOR
ECW 1 3711-001062CONNECTOR
ED 1 0401-000101DIODE
ED 2 0401-000101DIODE
EIC 1 1204-001730 IC
EQ 1 0501-000398TRANSISTOR C945
EQ 2 0504-000118TRANSISTOR R1003
EQ 3 0504-000118TRANSISTOR R1003
ER 2 2001-000522CARBON RESISTOR
ER 3 2001-000290CARBON RESISTORER 4 2001-000977CARBON RESISTOR
ER 5 2001-000522CARBON RESISTOR
ER 6 2001-000563CARBON RESISTORER 7 2001-000429CARBON RESISTOR
ER 8 2001-000734CARBON RESISTOR
ER 9 2001-000008CARBON RESISTORER 10 2001-000290CARBON RESISTOR
ER 11 2001-000734CARBON RESISTOR
ER 12 2001-000331CARBON RESISTORER 13 2001-000290CARBON RESISTOR
ER 14 2001-000319CARBON RESISTOR
ER 15 2001-000802CARBON RESISTOR
ER 16 2001-000034CARBON RESISTOR
ER 25 2001-000786CARBON RESISTOR
EZD 1 0403-000354 ZERNER DIODE
FC 9 2401-000419 E.0CAPACITOR
FC 11 2401-001975 E.0CAPACITOR
FC 15 2301-000361 C.CAPACITOR
FC 16 2301-000375 C.CAPACITOR
FC 17 2401-001954 E.CAPACITOR
FC 23 2401-000419 E.0CAPACITOR
FC 31 2401-000759 E.CAPACITOR
FC 32 2401-001954 E.CAPACITOR
FC 51 2202-000806 C.CAPACITORFC 52 2202-000806 C.CAPACITOR
FC 53 2401-001912 E.CAPACITOR
FC 54 2401-001912 E.CAPACITORFC 57 2401-001975 E.CAPACITOR
FCW 13708-000122CONNECTOR
FCW 23708-001094CONNECTORFCW 33708-000258CONNECTOR
FC1L2201-000368 C.CAPACITOR
FC1R2201-000368 C.CAPACITOR
FC10L 2301-000216 C.CAPACITOR
FC10R2301-000216 C.CAPACITOR
FC12L 2202-000781 C.CAPACITOR
FC12R2202-000781 C.CAPACITOR
FC13L 2202-000806 C.CAPACITOR
FC13R2201-000368 C.CAPACITOR
FC2L2401-001912 E.CAPACITOR
FC2R2401-001912 E.CAPACITOR
FC251 2401-001912 E.CAPACITORFC252 2401-001912 E.CAPACITOR
FC253 2401-001912 E.CAPACITOR
FC3L2401-001912 E.CAPACITORFC3R2401-001912 E.CAPACITOR
FC4L2401-001912 E.CAPACITOR
FC4R2401-001912 E.CAPACITORFC5L2401-001912 E.CAPACITOR
FC5R2401-001912 E.CAPACITOR
FC56L 2401-001912 E.CAPACITOR
FC56R2401-001912 E.CAPACITOR
FC57L 2201-000368 C.CAPACITOR
FC57R2201-000368 C.CAPACITOR
FC6L2401-002180 E.CAPACITOR
FC6R2401-002180 E.CAPACITOR
FC7L2401-001912 E.CAPACITOR
FC7R2401-001912 E.CAPACITOR
FC8L2301-000454 C.CAPACITOR
FC8R2301-000454 C.CAPACITOR
FC9L2301-000216 C.CAPACITOR
FC9R2301-000216 C.CAPACITOR
FD 2 0401-000101DIODEFD 3 0401-000101DIODE
FIC 1 1204-001776 IC
FIC 2 1201-000163 ICFIC 4 1201-000163 IC
FIC 5 1201-000163 IC
FQ 4 0501-000398TRANSISTOR C945 FQ 12 0504-000145TRANSISTOR R2003
FQ11L 0504-000122TRANSISTOR R1009
FQ11R 0504-000122TRANSISTOR R1009 FQ151 0504-000145TRANSISTOR R2003
FQ152 0504-000118TRANSISTOR R1003
FR 9 2001-000027CARBON RESISTOR
FR 18 2001-000515CARBON RESISTOR
FR 20 2001-000515CARBON RESISTOR
FR 21 2001-000864CARBON RESISTOR
FR 22 2001-000864CARBON RESISTOR
FR 23 2001-000773CARBON RESISTOR
FR 24 2001-000290CARBON RESISTOR
FR 25 2001-000429CARBON RESISTOR
FR 26 2001-000850CARBON RESISTOR
FR 28 2001-000645CARBON RESISTOR
FR 51 2001-000515CARBON RESISTOR
FR 52 2001-000786CARBON RESISTOR
FR 53 2001-000515CARBON RESISTORFR 54 2001-000786CARBON RESISTOR
FR 55 2001-000890CARBON RESISTOR
FR 56 2001-000411CARBON RESISTORFR 57 2001-000273CARBON RESISTOR
FR 58 2001-000273CARBON RESISTOR
FR 59 2001-000411CARBON RESISTORFR 61 2001-000429CARBON RESISTOR
FR 62 2001-000429CARBON RESISTOR
FR 81 2001-000786CARBON RESISTOR
FR 82 2001-000591CARBON RESISTOR
FR1L2001-000411CARBON RESISTOR
FR1R2001-000411CARBON RESISTOR
FR10L 2001-000429CARBON RESISTOR
FR10R2001-000429CARBON RESISTOR
FR11L 2001-000429CARBON RESISTOR
Item
Parts number Parts nameArea Remarks A
Page 83
MX-DVA5
3-26
Packing materials and accessories parts list
Block No. M
M M 5
Block No. M
M M 6
A7P6
P9A8 P8P7 P3
P5
P4
P2(A1 A9)
P1
