Page 1
1-2 (No.MA244)
SPECIFICATION
Design and specification are subject to change without notice.
AUDIO AMPLIFIER SECTION
Maximum Power Output Front 50 W per channel
Rear 50 W per channel
Continuous Power Output
(RMS)Front 19 W per channel into 4
-„¦, 40 Hz to 20 000 Hz at no more than 0.8%
total harmonic distortion.
Rear 19 W per channel into 4
-„¦, 40 Hz to 20 000 Hz at no more than 0.8%
total harmonic distortion.
Load Impedance 4
-„¦ (4 -„¦ to 8 -„¦ allowance)
Equalizer Control Range Low ±12 dB (60 Hz, 80 Hz, 100 Hz, 120 Hz)
Mid ±12 dB
High ±12 dB (8 kHz, 10 kHz, 12 kHz, 15 kHz)
Frequency Response 40 Hz to 20 000 Hz
Signal-to-Noise Ratio 70 dB
Line-Out Level/Impedance 2.0 V/20 k
-„¦ load (full scale)
Output Impedance 1 k
-„¦
Other terminals CD changer, AUX (auxiliary) input jack
TUNER SECTION
Frequency Range FM 87.5 MHz to 108.0 MHz
AM 531 kHz to 1 602 kHz
[FM Tuner] Usable Sensitivity 11.3 dBf (1.0
µV/75 -„¦)
50 dB Quieting Sensitivity 16.3 dBf (1.8
µV/75 -„¦)
Alternate Channel Selectivity (400 kHz) 65 dB
Frequency Response 40 Hz to 15 000 Hz
Stereo Separation 30 dB
Capture Ratio 1.5 dB
[AM Tuner] Sensitivity 20
µV
Selectivity 35 dB
CD PLAYER SECTION
TypeCompact disc player
Signal Detection System Non-contact optical pickup (semiconductor laser)
Number of Channels 2 channels (stereo)
Frequency Response 5 Hz to 20 000 Hz
Dynamic Range 96 dB
Signal-to-Noise Ratio 98 dB
Wow and Flutter Less than measurable limit
MP3 Decoding Format (KW-TC411/KW-TC410 only) MPEG1/2 Audio Layer 3
Max. Bit Rate: 320 kbps
WMA (Windows Media® Audio) Decoding Format (KW-TC411/KW-TC410 only) Max. Bit Rate: 192 kbps
CASSETTE DECK SECTION
Wow and Flutter 0.1 % (WRMS)
Fast-Wind Time 100 sec. (C-60)
Frequency Response 30 Hz to 16 000 Hz (Normal tape)
Signal-to-Noise Ratio
(Normal tape)Dolby B NR ON 65 dB
Dolby B NR OFF 56 dB
Stereo Separation 40 dB
GENERAL
Power Requirement Operating Voltage DC 14.4 V (11 V to 16 V allowance)
Grounding System: Negative ground
Allowable Operating Temperature 0
°C to +40 °C
Dimensions (W
× H × D) Installation Size (approx.) 178 mm × 100 mm × 158 mm
Set Size (approx.) 178 mm
× 100 mm × 177 mm
Mass (approx.) 2.3 kg (excluding accessories)
Page 2
(No.MA244)1-3
SECTION 1
PRECAUTIONS
1.1 Safety Precautions
! Burrs formed during molding may be left over on some parts of the chassis. Therefore,
pay attention to such burrs in the case of preforming repair of this system.
! Please use enough caution not to see the beam directly or touch it in case of an
adjustment or operation check.
