Page 1
1-2 (No.49871)
SPECIFICATION
Design and specifications are subject to change without notice.AUDIO AMPLIFIERSECTION
Maximum Power
Output Front 45W per channel
Rear 45W per channel
Continuous Power
Output (RMS) Front 17W per channel into 4
-„¦ , 40 Hz to 20000 Hz at no more than 0.8%
total harmonic distortion.
Rear 17W per channel into 4 -„¦ , 40 Hz to 20000 Hz at no more than 0.8%
total harmonic distortion.
Load Impedance 4 -„¦ (4 -„¦ to 8 -„¦ allowance)
Tone Control Range Bass ±10 dB at 100 Hz Treble ±10 dB at 10 kHz
Frequency Response 40 Hz to 20000 Hz
Signal-to-Noise Ratio 70 dB
Line-Out Level/Impedance 2.0 V/20 k -„¦ load (full scale)
Output Impedance 1 k -„¦
TUNER SECTION
Frequency Range FM 87.5 MHz to 108.0 MHz AM 531 kHz to 1602 kHz
[FM Tuner] Usable Sensitivity 11.3 dBf (1.0 uV/75 -„¦ )
50 dB Quieting Sensitivity 16.3 dBf (1.8 uV/75 -„¦ )
Alternate Channel Selectivity (400 kHz) 65 dB
Frequency Response 40 Hz to 15000 Hz
Stereo Separation 35 dB
Capture Ratio 1.5 dB
[AM Tuner] Sensitivity 20 uV Selectivity 35 dB CD PLAYER SECTION
Type Compact disc player
Signal Detection System Non-contact optical pickup (semiconductor laser)
Number of channels 2 channels (stereo)
Frequency Response 5 Hz to 20000 Hz
Dynamic Range 90 dB
Signal-to-Noise Ratio 95 dB
Wow and flutter Less than measurable limit GENERAL
Power Requirement Operating Voltage DC 14.4 V (11 V to 16 V allowance)
Grounding System Negative ground
Allowable Operating Temperature 0ºC to +40ºC
Dimensions
(W × H × D) Installation Size (approx.) 182 mm
× 52 mm × 150 mm
Panel size (approx.) 188 mm × 58 mm × 11 mm
Mass (approx.) 1.3 kg
Page 2
(No.49871)1-3
SECTION 1
PRECAUTION
1.1 Safety Precautions
! Burrs formed during molding may be left over on some parts of the chassi\
s. Therefore,
pay attention to such burrs in the case of preforming repair of this sys\
tem.
! Please use enough caution not to see the beam directly or touch it in ca\
se of an
adjustment or operation check.
