KD-GS41
SPECIFICATION
AUDIO AMPLIFIER SECTION
Maximum Power Output Front/Rear 50 W per channel
Continuous Power Output (RMS) Front/Rear 19 W per channel into 4 Q 40 Hz to 20 000 Hz at no more than 0.8%
total harmonic distortion.
Load Impedance 4 Q (4 Q to 8 Q allowance)
Tone Control Range Bass :12 dB at 60 Hz
Middle 112 dB at 1 kHz
Treble :12 dB at 7.5 kHz
Frequency Response
40 HZ to 20 000 HZ
Signal-to-Noise-Ratio 70 dB
Line-Out Level/Impedance 2.5 V/20 k0 load (full scale)
Output Impedance 1 k9
Subwoofer-Out Level/impedance
2.5 V/2O k0 load (full scale)
Other Terminal
CD changerjack AUX (auxiliary) input jack Steering wheel remote input
Frequency Range
TUNER SECTION
FM 87.5 MHZ to 108.0 MHZ
AM (MW) 522 kHZ to 1 620 kHZ
(LW) 144 kHZ to 279 kHZ
FM Tuner Usable Sensitivity 11.3 dBf (1.0 LIV/75 Q)
50 dB Quieting Sensitivity 16.3 dBf (1.8 uV/75 0)
Alternate Channel Selectivity (400 kHz) 65 dB
Frequency Response 40 Hz to 15 000 HZ
Stereo Separation 30 dB
MW Tuner Sensitivity/Selectivity 20 uV/35 dB
LW Tuner Sensitivity 50 uV
CD PLAYER SECTION
Type Compact disc player
Signal Detection System
Non-contact optical pickup (semiconductor laser)
Number of Channels
2 channels (stereo)
Frequency Response
5 HZ to 20 000 HZ
Dynamic Range 96 dB
Signal-to-Noise Ratio 98 dB
Wow and Flutter Less than measurable limit
MP3 Decoding Format Max. Bit Rate 320 kbps
(MPEG1/2 Audio Layer 3)
WMA (Windows Media® Audio) Max. Bit Rate 320 kbps
Decoding Format
GENERAL
Power Requirement lOperating Voltage DC 144 V (11 V to 16 V allowance)
Grounding System
Negative ground
Allowable Operating Temperature
0°C to + 40°C
Dimensions (W x H X D) (approx)
Installation Size
182 mm><52 mmx 160 mm
Panel Size
188mmx58mmx13mm
Mass
1.4 kg (excluding accessories)
Design and specifications are subject to change without notice.
