Page 1
2
ENGLISH
How to forcibly eject a disc
If a disc cannot be recognized by the receiver
or cannot be ejected, ejects the disc as
follows.
NO EJECT? (or EJECT OK?) and
EMERGENCY EJECT? appear on the
monitor.
Press 5 / -ˆž repeatedly to select
EMERGENCY EJECT?, then press ENT.
- If this does not work, reset your receiver.
- Be careful not to drop the disc when it ejects.
How to reset your unit
This will reset the
microcomputer. Your preset
adjustments will also be
erased.
Thank you for purchasing a JVC product.Please read all instructions carefully
before operation, to ensure your complete
understanding and to obtain the best possible performance from the unit.
INFORMATION (For U.S.A.)
This equipment has been tested and found
to comply with the limits for a Class B digital
device, pursuant to Part 15 of the FCC
Rules. These limits are designed to provide
reasonable protection against harmful
interference in a residential installation.
This equipment generates, uses, and can
radiate radio frequency energy and, if not
installed and used in accordance with the
instructions, may cause harmful interference
to radio communications. However, there
is no guarantee that interference will not
occur in a particular installation. If this
equipment does cause harmful interference
to radio or television reception, which can
be determined by turning the equipment
off and on, the user is encouraged to try to
correct the interference by one or more of
the following measures:
-“ Reorient or relocate the receiving antenna.
-“ Increase the separation between the equipment and receiver.
-“ Connect the equipment into an outlet on a circuit different from that to which the
receiver is connected.
-“ Consult the dealer or an experienced radio/TV technician for help.
Temperature inside the car....
If you have parked the car for a long time in hot
or cold weather, wait until the temperature in
the car becomes normal before operating the
unit.
For safety....
- Do not raise the volume level too much, as
this will block outside sounds, making driving
dangerous.
- Stop the car before performing any complicated operations.
IMPORTANT FOR LASER PRODUCTS
1. CLASS 1 LASER PRODUCT
2. CAUTION: Do not open the top cover.
There are no user serviceable parts inside
the unit; leave all servicing to qualified
service personnel.
3. CAUTION: Visible and invisible laser
radiation when open and interlock failed or
defeated. Avoid direct exposure to beam.
Caution:
Changes or modifications not approved
by JVC could void the users authority to
operate the equipment.
AVX2EN_book.indb 2 AVX2EN_book.indb 2 06.1.25 6:19:44 PM
06.1.25 6:19:44 PM
Page 2
3
ENGLISH
Caution on volume setting:
Discs produce very little noise compared
with other sources. Lower the volume
before playing a disc to avoid damaging
the speakers by the sudden increase of the
output level.
Cautions on the monitor:
- The monitor built in this receiver has been produced with high precision, but
it may have some ineffective dots. This is
inevitable and is not malfunction.
- Do not expose the monitor to direct sunlight.
WARNINGS:
- DO NOT install any receiver in locations where;
-“ it may obstruct the steering wheel and gearshift lever operations, as this may
result in a traffic accident.
-“ it may obstruct the operation of safety devices such as air bags, as this may
result in a fatal accident.
-“ it may obstruct visibility.
- DO NOT operate any receiver while manipulating the steering wheel, as this
may result in a traffic accident.
- The driver must not watch the monitor while driving.
If the driver watches the monitor while
driving, it may lead to carelessness and
cause an accident.
- The driver must not put on the headphones while driving. It is dangerous to shut off the
outside sounds while driving.
- If you need to operate the receiver while driving, be sure to look ahead carefully or
you may be involved in a traffic accident.
- If the parking brake is not engaged, Parking Brake flashes on the monitor,
and no playback picture will be shown.
-“ This warning appears only when the parking brake wire is connected to the
parking brake system built in the car
(refer to the Installation/Connection
Manual).
This product incorporates copyright
protection technology that is protected
by U.S. patents and other intellectual
property rights. Use of this copyright
protection technology must be authorized
by Macrovision, and is intended for home
and other limited viewing uses only unless
otherwise authorized by Macrovision.
Reverse engineering or disassembly is
prohibited.
Characters shown on the monitor
The following characters will be used
to show the various information on the
monitor.
- You can also use the following characters to assign titles (see page 41).
space
space space
Upper and lower cases
Numbers and symbols
AVX2EN_book.indb 3 AVX2EN_book.indb 3 06.1.25 6:19:44 PM
06.1.25 6:19:44 PM
Page 5
6
ENGLISH
SRCD
MENU
7 / BACK
KD-AVX2
DISP A
ENT
BAND
ASPECT
1
7
2 58
9 p
qe
4
r
t
y
u
i
6
w
3
1 (standby/on attenuator) button
2 - +/-“ (volume +/-“) button
- SRC (source) button
- DISP (D: display) button
3 Remote Sensor
4 Monitor
5 - 5 (up) / -ˆž (down) buttons
-
4/¢ buttons
6 MENU button
7 ASPECT (A) button
8
(angle) button
9 0 (eject) button
p Reset button
q - BAND button
- BACK button
- 7 (stop) button
w - ENT (enter) button
- 3 (play) button
e
(control panel release) button
Monitor indications
r Source indicator
t Main display
y Clock display
Also indicates volume level when adjusting volume.
u Status indicators
i Alert information area Also indicates volume level bar when adjusting volume.
Parts identification
Monitor
indications
Ex.:
Source screen on
JPEG playback
Control panel
AVX2EN_book.indb 6 AVX2EN_book.indb 6 06.1.25 6:19:47 PM
06.1.25 6:19:47 PM
Page 48
49
ENGLISH Playing an external component
You can connect an external component to
LINE IN plug and VIDEO IN plug on the rear,
or to the CD changer jack on the rear using the
KS-U57 Line Input Adapter (not supplied) or
KS-U58 AUX Input Adapter (not supplied).
- For connection, see Installation/Connection Manual (separate volume).
1
AV-IN: For selecting the external component connected to the LINE
IN and/or VIDEO IN.
- To change the setting of AV INPUT, see page 38.
EXT-IN: For selecting the external component connected to the CD
changer jack on the rear.
- If EXT-IN does not appear, see page 38 and select the external input (EXT-IN).
2 Turn on the connected component
and start playing the source.
SRC
DDIS
P
EXT-IN AV-IN
External component
operations 3 Adjust the volume.
4 Adjust the equalizer as you want. (See
pages 38.)
SRC D
