Page 1
1-2 (No.MA165)
SPECIFICATION
for NORTHERN AMERICA version
AUDIO AMPLIFIER SECTION
Power Output 20 W RMS
× 4 Channels at 4 -„¦ and [< or =] 1% THD+N
Signal to Noise Ratio 80 dBA (reference: 1 W into 4
-„¦)
Load Impedance 4
-„¦ (4 -„¦ to 8 -„¦ allowance)
Equalizer Control Range Frequencies 60 Hz, 150 Hz, 400 Hz, 1 kHz, 2.5 kHz, 6.3 kHz, 15 kHz
Level ±10 dB
Line-In Level/Impedance 1.5 V/20 k
-„¦ load
Line-Out Level/Impedance 5.0 V/20 k
-„¦ load (full scale)
Output Impedance 1 k
-„¦
Subwoofer-Out Level/Impedance 2.0 V/20 k -„¦ load (full scale)
Color System NTSC
Video Input (composite) 1 Vp-p/75
-„¦
Video Output (composite) 1 Vp-p/75 -„¦
Other Terminals 2nd AUDIO OUT, DIGITAL OUT (optical), CD changer, Steering wheel re-
mote input (OE REMOTE)
TUNER SECTION
Frequency Range FM 87.5 MHz to 107.9 MHz (with channel interval set to 200 kHz)
87.5 MHz to 108.0 MHz (with channel interval set to 50 kHz)
AM 530 kHz to 1 710 kHz (with channel interval set to 10 kHz)
531 kHz to 1 602 kHz (with channel interval set to 9 kHz)
FM Tuner Usable Sensitivity 11.3 dBf (1.0
µV/75 -„¦)
50 dB Quieting Sensitivity 16.3 dBf (1.8
µV/75 -„¦)
Alternate Channel Selectivity (400 kHz) 65 dB
Frequency Response 40 Hz to 15 000 Hz
Stereo Separation 35 dB
Capture Ratio 1.5 dB
AM Tuner Sensitivity 20
µV
Selectivity 35 dB
DVD/CD PLAYER SECTION
Signal Detection System Non-contact optical pickup (semiconductor laser)
Number of Channels 2 channels (stereo)
Frequency Response DVD fs=48 kHz 16 Hz to 22 000 Hz
DVD fs=96 kHz 16 Hz to 44 000 Hz
VCD, CD, MP3, WMA 16 Hz to 20 000 Hz
Dynamic Range 93 dB
Signal-to-Noise Ratio 95 dB
Wow and Flutter Less than measurable limit
MP3 Max. Bit Rate 320 kbps
WMA (Windows Media Audio) Max. Bit Rate 192 kbps
MONITOR SECTION
Screen 3-inch liquid crystal panel
Number of Pixels 123 200 pixels
Drive Method TFT (Thin Film Transistor) active matrix format
Color system NTSC
GENERAL
Power Requirement Operating Voltage DC 14.4 V (11 V to 16 V allowance)
Grounding System Negative ground
Allowable Operating Temperature 0
° C to +40 ° C (32 ° F to 104 ° F)
Dimensions (W
× H × D) Installation Size (approx.) 182 mm × 52 mm × 160 mm (7-3/16" × 2-1/16" × 6-5/16")
Panel Size (approx.) 188 mm
× 58 mm × 18 mm (7-7/16" × 2-5/16" × 3/4")
Mass (approx.) 2.0 kg (4.5 lbs) (excluding accessories)
Page 2
(No.MA165)1-3 for EUROPE version
AUDIO AMPLIFIER SECTION
Maximum Power Output Front 50 W per channel
Rear 50 W per channel
Continuous Power Output (RMS) Front 20 W per channel into 4
-„¦, 40 Hz to 20 000 Hz at no more than 0.8% total
harmonic distortion.
Rear 20 W per channel into 4
-„¦, 40 Hz to 20 000 Hz at no more than 0.8% total
harmonic distortion.
Load Impedance 4
-„¦ (4 -„¦ to 8 -„¦ allowance)
Equalizer Control Range Frequencies 60 Hz, 150 Hz, 400 Hz, 1 kHz, 2.5 kHz, 6.3 kHz, 15 kHz
Level ±10 dB
Signal-to-Noise Ratio 70 dB
Line-In Level/Impedance 1.5 V/20 k
-„¦ load
Line-Out Level/Impedance 5.0 V/20 k
-„¦ load (full scale)
Output Impedance 1 k
-„¦
Subwoofer-Out Level/Impedance 2.0 V/20 k -„¦ load (full scale)
Color System PAL
Video Input (composite) 1 Vp-p/75
-„¦
Video Output (composite) 1 Vp-p/75 -„¦
Other Terminals 2nd AUDIO OUT, DIGITAL OUT (optical), CD changer, Steering wheel re-
mote input (OE REMOTE)
TUNER SECTION
Frequency Range FM 87.5 MHz to 108.0 MHz
AM (MW) 522 kHz to 1 620 kHz
(LW) 144 kHz to 279 kHz
FM Tuner Usable Sensitivity 11.3 dBf (1.0
µV/75 -„¦)
50 dB Quieting Sensitivity 16.3 dBf (1.8
µV/75 -„¦)
Alternate Channel Selectivity (400 kHz) 65 dB
Frequency Response 40 Hz to 15 000 Hz
Stereo Separation 35 dB
Capture Ratio 1.5 dB
MW Tuner Sensitivity 20
µV
Selectivity 35 dB
LW Tuner Sensitivity 50
µV
DVD/CD PLAYER SECTION
Signal Detection System Non-contact optical pickup (semiconductor laser)
Number of Channels 2 channels (stereo)
Frequency Response DVD fs=48 kHz 16 Hz to 22 000 Hz
DVD fs=96 kHz 16 Hz to 44 000 Hz
VCD, CD 16 Hz to 20 000 Hz
Dynamic Range 93 dB
Signal-to-Noise Ratio 95 dB
Wow and Flutter Less than measurable limit
MP3 Max. Bit Rate 320 kbps
WMA (Windows Media Audio) Max. Bit Rate 192 kbps
MONITOR SECTION
Screen 3-inch liquid crystal panel
Number of Pixels 123 200 pixels
Drive Method TFT (Thin Film Transistor) active matrix format
Color System PAL
GENERAL
Power Requirement Operating Voltage DC 14.4 V (11 V to 16 V allowance)
Grounding System Negative ground
Allowable Operating Temperature 0
°C to +40 °C
Dimensions (W
× H × D) Installation Size (approx.) 182 mm × 52 mm × 160 mm
Panel Size (approx.) 188 mm
× 58 mm × 18 mm
Mass (approx.) 2.0 kg (excluding accessories)
Page 34
(No.MA165)1-35 4.6.6 Running mode
4.6.7 Writing method for micon ROM correction
Indication
RUNNING1 MECHA
RUNNING2 MECHA
RUNNING3 DVD
RUNNING4 DVD
RUNNING5 DVD
RUNNING6 DVD
RUNNING7 DVD
RUNNING8 DVD
Explanation
Door mecha running1
Door mecha running1
DVD+Door mecha running1
DVD+Door mecha running2
DVD+Door mecha running3
DVD+Door mecha running4
DVD+Door mecha running5
DVD+Door mecha running6
Operation contents of 1 cycle
Panel close Panel open
Panel close Panel open Panel detach position
Panel angle 3 position Panel angle 1 position
Panel angle 2 position
Loading Eject Wait for 5 seconds+Door open/close
Loading Eject Wait for 5 seconds+Door open/close
Loading Playback Eject Wait for 5 seconds+Door open/close
Loading Playback Eject Wait for 5 seconds+Door open/close
Loading Playback Eject Wait for 5 seconds+Door open/close
Loading Playback Eject Wait for 5 seconds+Door open/close
In mecha error
-
-
Stop
Retry
Stop
Retry
Stop
Retry
In disc error
-
-
-
-
Stop
Stop
Retry
Retry
SDRAM inspection
-
-
-
-
Execution
Execution
Non-execution
Non-execution
Cancellation of running1,2 : Press the [EJECT] key
In running 1,2 cancellation, a door does not stop at the position and moves to a panel open position.
Cancellation of running3 to 8 : Press the [POWER] key
The number of count and an error cord are displayed in running.
Playback contents in a running mode
CD
The first track is played for 30 seconds. The last track is played for 30 seconds.
(The last truck is played in the case of less than till the last for 30 seconds.)
DVD
2layer disc
Title 1 (the L0 layer internal circumference) is played for 30 seconds. Title 12 (L0 layer circumference) is played for 30 seconds.
Title 24 (L1 layer internal circumference) is played for 30 seconds.
1layer disc
First chapter of title 1 is played for 30 seconds. The last chapter of title 1 is played for 30 seconds.
For main ROM correction and panel ROM correction, prepare two pieces of disc.
(Do not put both data in one piece of disk.)
Insert the disc which ROM correction data were written in at.
Folder name : ROM Correction
File name : Please Wait
Folder name : ROM Correction
File name : OK 1940 (Indication is different by ROM correction IC.)
If OK is displayed, ROM correction is completion. Disc is ejected automatically.
Pull the power supply cord and wait more than 30 seconds. (Even reset is possible.)
Switch on the main body again and confirm a version.
Confirmation method of a version
Keep this state more than 2 seconds while continuing pressing the [DISP] button, [VOLUME+] button and
[EJECT] button sequentially to enter this set in service mode 3.
Select the service mode and press the [OK] button.
Select the version and press the [OK] button.
ROM correction is completion if displayed on a screen as follows.
PANEL : panel ROM correction
MAIN : main ROM correction
ROM correction version
PANEL V [V001]
When it was confirmed a version without reset, a part of [V001] is displayed in [E001].
When a ROM collection is not completed even if writing of EEPROM is completed, this indication appears.
Movement of this case is movement before the ROM collection.
