SPECIFICATION
KD-AR770/KD-G720
AUDIO AMPLIFIER SECTION
Power Output 20 W RMS
× 4 Channels at 4 -„¦ and [< or =] 1% THD+N
Signal to Noise Ratio 80 dBA (reference: 1 W into 4
-„¦)
Load Impedance 4
-„¦ (4 -„¦ to 8 -„¦ allowance)
Tone Control Range Bass ±10 dB at 100 Hz
Treble ±10 dB at 10 kHz
Frequency Response 40 Hz to 20 000 Hz
Line-Out Level/Impedance KD-AR770 4.0 V /20 k
-„¦ load (full scale)
KD-G720 2.5 V /20 k
-„¦ load (full scale)
Output Impedance 1 k
-„¦
Subwoofer-Out Level/Impedance 2.0 V /20 k -„¦ load (full scale)
Other Terminals CD changer
LINE IN plugs (only for KD-AR770)
TUNER SECTION
Frequency Range FM 87.5 MHz to 107.9 MHz (with channel interval set to 100 kHz or 200 kHz)
87.5 MHz to 108.0 MHz (with channel interval set to 50 kHz)
AM 530 kHz to 1 710 kHz
(with channel interval set to 10 kHz)
531 kHz to 1 602 kHz
(with channel interval set to 9 kHz)
FM Tuner Usable Sensitivity 11.3 dBf (1.0
µV/75 -„¦)
50 dB Quieting Sensitivity 16.3 dBf (1.8
µV/75 -„¦)
Alternate Channel Selectivity (400 kHz) 65 dB
Frequency Response 40 Hz to 15 000 Hz
Stereo Separation 35 dB
AM Tuner Sensitivity 20
µV
Selectivity 35 dB
CD PLAYER/USB MEMORY SECTION
Type Compact disc player
Signal Detection System Non-contact optical pickup (semiconductor laser)
Number of Channels 2 channels (stereo)
Frequency Response 5 Hz to 20 000 Hz
Dynamic Range 96 dB
Signal-to-Noise Ratio 98 dB
Wow and Flutter Less than measurable limit
MP3 Decoding Format MPEG1/2 Audio Layer 3
Max. Bit Rate : 320 kbps
WMA (Windows Media® Audio) Decoding Format Max. Bit Rate : 192 kbps
Playable USB memory Format FAT 12/16/32
Storage Less than 4 GB (1 partition type)
Playable Audio Format MP3/WMA
Max. Current Less than 500 mA
GENERAL
Power Requirement Operating Voltage DC 14.4 V (11 V to 16 V allowance)
Grounding System Negative ground
Allowable Operating Temperature 0
°C to +40 °C (32 °F to 104 °F)
Dimensions (W
× H × D) Installation Size (approx.) 182 mm × 52 mm × 152 mm (7-3/16" × 2-1/16" × 6")
Panel Size (approx.) 188 mm
× 58 mm × 11 mm (7-7/16" × 2-5/16" × 7/16")
Mass (approx.) 1.4 kg (3.1 lbs) (excluding accessories)
Page 2
(No.MA247)1-3 KD-G722/KD-G721
AUDIO AMPLIFIER SECTION
Maximum Power Output Front 50 W per channel
Rear 50 W per channel
Continuous Power Output (RMS) Front 19 W per channel into 4
-„¦, 40 Hz to 20 000 Hz at no more than 0.8% total
harmonic distortion.
Rear 19 W per channel into 4
-„¦, 40 Hz to 20 000 Hz at no more than 0.8% total
harmonic distortion.
Load Impedance 4
-„¦ (4 -„¦ to 8 -„¦ allowance)
Tone Control Range Bass ±10 dB at 100 Hz
Treble ±10 dB at 10 kHz
Frequency Response 40 Hz to 20 000 Hz
Signal-to-Noise Ratio 70 dB
Line-Out Level/Impedance 2.5 V/20 k
-„¦ load (full scale)
Output Impedance 1 k
-„¦
Subwoofer-Out Level/Impedance 2.0 V/20 k -„¦ load (full scale)
Other Terminals CD changer, Steering wheel remote input
TUNER SECTION
Frequency Range FM 87.5 MHz to 108.0 MHz
AM (MW) 522 kHz to 1 620 kHz
(LW) 144 kHz to 279 kHz
FM Tuner Usable Sensitivity 11.3 dBf (1.0
µV/75 -„¦)
50 dB Quieting Sensitivity 16.3 dBf (1.8
µV/75 -„¦)
Alternate Channel Selectivity (400 kHz) 65 dB
Frequency Response 40 Hz to 15 000 Hz
Stereo Separation 30 dB
MW Tuner Sensitivity 20
µV
Selectivity 35 dB
[LW Tuner] Sensitivity 50
µV
CD PLAYER/USB MEMORY SECTION
Type Compact disc player
Signal Detection System Non-contact optical pickup (semiconductor laser)
Number of Channels 2 channels (stereo)
Frequency Response 5 Hz to 20 000 Hz
Dynamic Range 96 dB
Signal-to-Noise Ratio 98 dB
Wow and Flutter Less than measurable limit
MP3 Decoding Format MPEG1/2 Audio Layer 3
Max. Bit Rate : 320 kbps
WMA (Windows Media® Audio) Decoding Format Max. Bit Rate : 192 kbps
Playable USB memory Format FAT 12/16/32
Storage Less than 4 GB (1 partition type)
Playable Audio Format MP3/WMA
Max. Current Less than 500 mA
GENERAL
Power Requirement Operating Voltage DC 14.4 V (11 V to 16 V allowance)
Grounding System Negative ground
Allowable Operating Temperature 0
°C to +40 °C
Dimensions (W
× H × D) Installation Size (approx.) 182 mm × 52 mm × 152 mm
Panel Size (approx.) 188 mm
× 58 mm × 11 mm
Mass (approx.) 1.4 kg (excluding accessories)
