Page 1
1-2
Safety Precautions
1. This design of this product contains special hardware and many circuits and components specially
for safety purposes. For continued protection, no changes should be made to the original design
unless authorized in writing by the manufacturer. Replacement parts must be identical to those
used in the original circuits. Services should be performed by qualified personnel only.
2. Alterations of the design or circuitry of the product should not be made. Any design alterations of
the product should not be made. Any design alterations or additions will void the manufacturer`s
warranty and will further relieve the manufacture of responsibility for personal injury or property
damage resulting therefrom.
3. Many electrical and mechanical parts in the products have special safety-related characteristics.
These characteristics are often not evident from visual inspection nor can the protection afforded
by them necessarily be obtained by using replacement components rated for higher voltage,
wattage, etc. Replacement parts which have these special safety characteristics are identified in
the Parts List of Service Manual. Electrical components having such features are identified by
shading on the schematics and by ( ) on the Parts List in the Service Manual. The use of a
substitute replacement which does not have the same safety characteristics as the recommended
replacement parts shown in the Parts List of Service Manual may create shock, fire, or other
hazards.
4. The leads in the products are routed and dressed with ties, clamps, tubings, barriers and the
like to be separated from live parts, high temperature parts, moving parts and/or sharp edges
for the prevention of electric shock and fire hazard. When service is required, the original lead
routing and dress should be observed, and it should be confirmed that they have been returned
to normal, after re-assembling.
5. Leakage currnet check (Electrical shock hazard testing)
After re-assembling the product, always perform an isolation check on the exposed metal parts
of the product (antenna terminals, knobs, metal cabinet, screw heads, headphone jack, control
shafts, etc.) to be sure the product is safe to operate without danger of electrical shock.
Do not use a line isolation transformer during this check.
Plug the AC line cord directly into the AC outlet. Using a "Leakage Current Tester", measure
the leakage current from each exposed metal parts of the cabinet , particularly any exposed
metal part having a return path to the chassis, to a known good earth ground. Any leakage
current must not exceed 0.5mA AC (r.m.s.)
Alternate check method
Plug the AC line cord directly into the AC outlet. Use an AC voltmeter having, 1,000 ohms
per volt or more sensitivity in the following manner. Connect a 1,500 10W resistor paralleled by
a 0.15 F AC-type capacitor between an exposed
metal part and a known good earth ground.
Measure the AC voltage across the resistor with the
AC voltmeter.
Move the resistor connection to eachexposed metal
part, particularly any exposed metal part having a
return path to the chassis, and meausre the AC
voltage across the resistor. Now, reverse the plug in
the AC outlet and repeat each measurement. voltage
measured Any must not exceed 0.75 V AC (r.m.s.).
This corresponds to 0.5 mA AC (r.m.s.).
Warning
1. This equipment has been designed and manufactured to meet international safety standards.
2. It is the legal responsibility of the repairer to ensure that these safety standards are maintained.
3. Repairs must be made in accordance with the relevant safety standards.
4. It is essential that safety critical components are replaced by approved parts.
5. If mains voltage selector is provided, check setting for local voltage.
Good earth groundPlace this
probe on
each exposed
metal part. AC VOLTMETER
(Having 1000
ohms/volts,
or more sensitivity)
1500 10W
0.15 F AC TYPE
!
CAUTION Burrs formed during molding may be left over on some parts of the chassis. Therefore,
pay attention to such burrs in the case of preforming repair of this system.
UX-G6/FS-6G
Page 2
1-3
UX-G6/FS-G6
Important for laser products
1.CLASS 1 LASER PRODUCT
2.DANGER : Invisible laser radiation when open and inter
lock failed or defeated. Avoid direct exposure to beam.
3.CAUTION : There are no serviceable parts inside the
Laser Unit. Do not disassemble the Laser Unit. Replace
the complete Laser Unit if it malfunctions.
4.CAUTION : The compact disc player uses invisible
laserradiation and is equipped with safety switches
whichprevent emission of radiation when the drawer is
open and the safety interlocks have failed or are de
feated. It is dangerous to defeat the safety switches.5.CAUTION : If safety switches malfunction, the laser is able
to function.
6.CAUTION : Use of controls, adjustments or performance of
procedures other than those specified herein may result in
hazardous radiation exposure.
VARNING : Osynlig laserstrålning är denna del är öppnad
och spårren är urkopplad. Betrakta ej strålen.
VARO : Avattaessa ja suojalukitus ohitettaessa olet
alttiina näkymättömälle lasersäteilylle.Älä katso
säteeseen.ADVARSEL : Usynlig laserstråling ved åbning , når
sikkerhedsafbrydere er ude af funktion. Undgå
udsættelse for stråling.
ADVARSEL : Usynlig laserstråling ved åpning,når
sikkerhetsbryteren er avslott. unngå utsettelse
for stråling.
REPRODUCTION AND POSITION OF LABELS
WARNING LABEL
DANGER : Invisibie laser radiation
when open and interlock or
defeated.
AVOID DIRECT EXPOSURE TO
BEAM (e) VARNING : Osynlig laserstrålning är
denna del är öppnad och spårren är
urkopplad. Betrakta ej strålen. (s) VARO : Avattaessa ja suojalukitus
ohitettaessa olet alttiina
näkymättömälle lasersäteilylle.Älä
katso säteeseen. (f) ADVARSEL :Usynlig laserstråling
ved åbning , når
sikkerhedsafbrydere er ude af
funktion. Undgå udsættelse for
stråling. (d)
CLASS 1
LASER PRODUCT
! CAUTION Please use enough caution not to
see the beam directly or touch it
in case of an adjustment or operation
check.
Page 14
1-15
UX-G6/FS-G6
31
English
Troubleshooting
If you are having a problem with your system, check this list for a possible solution before calling for service.
If you cannot solve the problem from the hints given here, or the units has been physically damaged, call a qualified
person, such as your dealer, for service.
Symptom No sound is heard.
Poor radio reception.
Unable to record onto a tape.
The CD skips.
Unable to operate using the remote
control.
Loaded CD and tape cannot be
ejected.
The CD does not play.
Operations are disabled.
Possible Cause - Connections are incorrect, or
loose.
- Headphones are connected.
- Volume level is set to -“ -“.
- The antenna is not connected
correctly.
- The AM loop antenna is too close
to the units.
- The FM antenna is not properly
extended and positioned.
- You are using a tape without a
protect tab.
- Tape-type detection slots are
covered by foreign matters.
- The CD is dirty or scratched.
- The path between the remote
control and the remote sensor on
the front panel is blocked.
- The batteries have lost their
charge.
- The main AC power cord is not
plugged in.
- The system is under the recording
operations.
- The CD is upside down.
- The built-in microprocessor has
malfunctioned due to external
electrical interference.
Action - Check all connections and make
corrections (see pages 6 -“ 9).
- Disconnect the headphones (see
page 12).
- Adjust the volume again (see
page 12).
- Reconnect the antenna securely.
- Change the position and direction
of the AM loop antenna.
- Extend FM antenna to the best
reception position (see page 7).
- Cover the hole with adhesive tape
(see page 30).
- Remove the foreign matters.
- Clean or replace the CD (see page
29).
- Remove the obstruction.
- Replace the batteries (see page 6).
- Plug in the AC power plug.
- Stop the recording if required (see
pages 23).
- Put in the CD with the label side
up.
- Unplug the system then plug it
back in.
32
English
Specifications
Stereo Amplifier AX-UXG6Output power
48 W (24 W + 24 W) at 6 -„¦ (Max.)
Load impedance: 6 -„¦ (6 -„¦ to 16 -„¦ allowance)
Audio output level/Impedance (at 1 kHz):
Sub Woofer 800 mV/440 -„¦
Power requirement: [A] AC 110 V -“ 120 V/220 V
-“ 240 V
,
[B] AC 115 V/230 V
(adjustable with the voltage
selector), 50 Hz/60 Hz
Power consumption: [A] 59 W (at operation)
[B] 54 W (at operation)
2.0 W (on standby: with
Dimmer)
Dimensions (approx.): 182 mm x 81 mm x 313 mm
(W/H/D)
Mass (approx.): 3.8 kg
Compact Disc/ Tuner XT-UXG6Audio input sensitivity/Impedance (at 1 kHz):
AUX: 400 mV/47 k-„¦
[CD section]
Digital output: OPTICAL DIGITAL OUT
Wow and flutter: Immeasurable
[Tuner section]
FM tuning range: 87.50 MHz -“ 108.00 MHz
AM tuning range: 531 kHz -“ 1,710 kHz (at 9 kHz
channel spacing)
530 kHz -“ 1,710 kHz (at 10 kHz
channel spacing)
Dimensions (approx.): 181 mm x 81 mm x 313 mm
(W/H/D)
Mass (approx.): 1.9 kg
Cassette Deck TD-UXG6Frequency response :
Normal 30 Hz -“ 15,000 Hz
High position 30 Hz -“ 16,000 Hz
Wow and flutter: 0.1 % WRMS
Dimensions (approx.): 181 mm x 81 mm x 304 mm
(W/H/D)
Mass (approx.): 1.9 kg
Speaker System SP-UXG6Type: 2-way Bass-Reflex Type
Speaker unit: Woofer 11.5 cm Cone x 1
Tweeter 3.0 cm Balanced
Dome x 1
Impedance: 6 -„¦
Frequency range: 40 Hz -“ 20,000 Hz
Sound Pressure Level: 85.5 dB/W-m
Dimensions (approx.): 157 mm x 295 mm x 232 mm
(W/H/D)
Mass (approx.): 3.3 kg each
Supplied AccessoriesSee page 6.
Design and specifications are subject to change
without notice.
US and foreign patents licensed from Dolby
Laboratories Licensing Corporation.
Page 29
2-14
UX-G6/FS-G6
Removing the analog in/digital out board
and the relay board (See Fig.8 to 10)
- Prior to performing the following procedure,
remove the top cover, the rear panel and the
system control board.
1. Cut the tie band fixing the harness on the side of
the body. Disconnect the harness from connector
CN451 on the analog in/digital out board and
remove the screw G attaching the analog in/
digital out board.
2. Disconnect connector CN455, CN456 and
CN457 on the analog in/digital out board from the
connector on the main & CD servo board.
3. Disconnect connector CN443 on the relay board
from the connector on the main & CD servo
board.
Removing the tuner board (See Fig.11)
- Prior to performing the following procedure,
remove the top cover and the rear panel.
1. Disconnect CN506 on the system control board.
2. Remove the screw H attaching the tuner board.
Fig. 8
Fig. 9
Fig. 10
Fig. 11
CN451
Tie band Analog in/digital
out board
G
CN451
CN455
CN456
CN457 Analog in/digital
out board
Main & CD servo board
Relay board
Main & CD servo board CN443
CN506 H Tuner boardSystem control board
